AND JAW PUSHER................4 FIG. 3 DETAIL ILLUSTRATION OF SUCTION ADJUSTMENT AND CLEAN UP THE SAFETY CAP............5 FIG. 4 DETAIL ILLUSTRATION OF OIL TANK PLUG....... 7 FIG. 5 COMPONENTS OF ST-66166V RIVET-PULL TOOL..... 9...
TOOL SPECIFICATIONS Technical Data Model Of Tool…………………………..……… ST-66166V Dimensions……………………………………... 12” X 12.2” X 4.29” (Length X Height X Width) (305mm X 310mm X109mm) Weight…………………………..………..4.05 lbs [1.84 Kgs] Air Inlet………………………………………… 1/4” NPT Recommended Operating Pressure………...… 95 to 100 psi [6.7 to 7.02kg/cm2] Air Consumption………………...….
GENERAL DESCRIPTION The ST-66166V Rivet-Pull Tool illustrated in Fig. 1 with its pneumat i c hydraulic system provides an efficient, lightweight, powerful, and quiet tool for rivet nut installation. It is designed to provide long life and trouble free services.
SAFETY INSTRUCTIONS DANGER Read this manual and understand all safety instructions before operating the tool. If you have any questions, please contact authorized representatives. Never allow the use of flammable gases (oxygen) as a power source for the tool. Use filtered, lubricated, and regulated compressed air only.
OPERATION INSTRUCTIONS A. To prepare ST-66166V 1. Following the steps below to install the desired nosepiece: a. Loosen and remove the nosepiece (Index 37 in Figs. 2 & 5), then set up the desired nosepiece (Index 37~37-2 in Figs. 2 & 5) on frame head as shown in Fig.
Page 7
B. To operate ST-66166V a. Open the shutoff valve, let the air enter the ST-66166V rivet-pull tool. When use the ST-66166V rivet-pull tool, the shutoff valve must be in the ✂ open state, otherwise there was no suction to inhale the rivet.
Maintenance The maintenance required when the tool of ST-66166V pulling strength were become lower, it is only necessary to add ISO VG46 oil or similar grade oil into the hydraulic system., the operation steps as below: 1. Unscrew and remove the front head (Index 38)Turn the tool upside down and well fixed, then use spanner remove No.1 parts.
TROUBLESHOOTING Stop using the tool immediately if any of the following problems occur. Any repairs or replacements must be done by a qualified person or an authorized service center only. PROBLEM CAUSE REMEDY The differen t rivets need to change the compared nosepiece, jaw and jaw pusher.
3/8” (10 mm) 80 dB(A) due to risk of Air Pressure 85~95 psi (6~6.7 bar) impaired Uncertainty Uncertainty hearing! ² K= 1.5 m/s K= 3dB Net Weight 3.96 lbs (1.8 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-66166V-S-1301C-C1F...
Page 11
ST-66166V 1/4"(6.4MM) AIR HYDRAULIC RIVETER ST-66166V-P-2402G-C1...
Page 12
ST-66166V 1/4"(6.4MM) AIR HYDRAULIC RIVETER PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 66166V-01 Cylinder Cap 66166V-37 Nosepiece 1/4" (Φ6.3mm) 66166V-02 Rubber Botton 37-1 66166V-37-1 Nosepiece 7/32" (Φ5.5) 66166V-03 Air Cylinder Body 37-2 66166V-37-2 Nosepiece 3/16" (Φ4.8mm) 66166V-04...
Page 13
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment: 1/4"(6.4MM) AIR HYDRAULIC RIVETER Model/ Serial No.:ST-66166V to which this declaration applies, complies with these normative documents: Machinery Directive: 2006/42/EC ...
Page 14
RIVETER Original instructions SUMAKE Industrial Co. Ltd.
Page 15
The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
Page 16
Safety precautions for repetitive motions hazards 1. When using a power tool, the operator may experience discomfort in the hands, arms, shoulders, neck, or other parts of the body. 2. While using a power tool, the operator should adopt a comfortable posture. Maintain secure footing and avoid awkward or off-balanced postures.
Page 17
General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE 10W-20 (ISO Viscosity Grade 46/32) Hydraulic Oil at the air inlet. Also, every 3 to 4 hours of operation, oiling is necessary. Twist Teflon thread tape to ensure a proper seal air inlet. Then tighten the air coupler into air tool.
