Sumake ST-24001 Quick Start Manual

SUMAKE
Specification:
Blow Per Min
Piston Diameter
Piston Stroke
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
Air Riveting Hammer
(Piston Type)
ST-24001
3,960 b.p.m.
3/5" (15.24 mm)
1-4/7" (40 mm)
14 CFM (396 L/min)
7-1/10" (180 mm)
1/4" (6.35mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.2 lbs (1.0 kg)

Noise and Vibration:

Vibration
EN ISO 28927-10
Sound Pressure Level
Load:
< 2.5 m/s²
Sound power level
Uncertainty
K= 1.5 m/s
²
Noise
EN ISO 15744
Please always
load: 93 dB(A)
protector at
environment
load: 104 dB(A) noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
ST-24001-S-2308B-FYF
Remark
wear ear
hearing!
