4.
OPERATING CONTROLS
LED INDICATOR:
The single blue LED indicator will flash when Nomad
Alpha is switched on
When it is flashing red and blue, Nomad Alpha is in
pairing mode.
LED BATTERY INDICATOR
The battery LED indicator will flash from one to four
LEDs to indicate Nomad Alpha is charging. The lights
will stop flashing once Nomad Alpha is fully charged.
4 blue lights on:
Battery 100%
3 blue lights on:
Battery 75%
2 blue lights on:
Battery 50%
1 blue light on:
Battery 25%
1 red light on:
Battery requires
recharge
POWERBANK
Nomad Alpha comes with a USB-A output port, which
is capable of supplying up to 5V⎓2.4A. The main
power switch must be turned on to use this feature.
Whilst charging another device, the LED battery
indicator lights will indicate how much charge is
remaining in the speaker's powerbank.
8
5.
SPECIFICATIONS
• Dimensions: 280x 141x 151mm
• Unit weight: 1.9kg
• Output power: RMS 40W
• S/N ratio: 85db +/- 3db
• Frequency range: 90Hz - 20 kHz
• USB-C input: 5V⎓3A (15W), 9V⎓3A (18W),
12V⎓2.5A (30W), 15V⎓2A (30W)
• USB-A output: 5V⎓2.4A (12W)
• Battery capacity: 15,600mAh
• Playtime: Up to 10 hours at 75% volume
• Charging time: Approximately 8-10 hours
• Function: Bluetooth/ UNISYNC/ Aux-in/
Microphone/ USB-C input/ USB-A power output/
LED flashlight/ Wireless charging pad
• Bluetooth version: 5.1
• Drop proof to 2 metres
• Waterproof IP67
• Shock proof
• Operating temperature: -100C to 550C
9
