• AUX power connector
CAUTION! Alveo data center accelerator cards are designed to be installed into a data center server,
where controlled air flow provides direct cooling. If the cooling enclosure is removed from the card and the
card is powered-up, external fan cooling airflow MUST be applied to prevent over-temperature shut-down
and possible damage to the card electronics. Removing the cooling enclosure voids the board warranty.
For card specifications, dimensions, list of card features, and block diagram, see Alveo U55C Data
Center Accelerator Cards Data Sheet (DS978) for additional information about airflow
requirements.

Card Utilities

For more information on user commands, please refer to xbutil.
For more information on host commands, please refer to xbmgmt.
Note: Utility command line help can always be obtained using the --help option.
UG1468 (v1.0) November 23, 2021
Alveo U55C Data Center Accelerator Card Installation Guide
Figure 1: Alveo U55C Compute Adaptor
