YOODA 15LEU/L Series Instructions Manual

www.sukcesgroup.pl
Non-compliance with the specification might cause risk for life or health and can determine proper work of the blinds.
We strongly recommend to comply with the specification.

1. General information

15 LEU/L tubular motor with radio receiver and battery
antenna
charging socket
LED diode
programming button
PROGRAMMING BUTTON FUNCTIONS:
1. Pressing the programming button briefly for approximately 1 second controls the drive step by step.
2. Pressing the programming button for 2 secons enters the motor into the transmitter programming mode.
3. Pressing the programming button for 6 seconds activates the function of blocking the radio signal. To deactivate the
function, briefly press the programming button on the motor head or disconnect motor power.
4. Pressing the programming button for 10 seconds changes work motor direction.
5. Pressing the programming button for 14 seconds deletes the motor memory and restores the factory settings.
NAPĘDY SERII 15LEU/L
battery
limit switches system
head visible from
the other side
LEU/L type motors wit two way equipped with a radio receiver
are wireless and can be controlled with a remote. They are
designed for automation of blinds. They have electronic limit
switches which are programmed by the remote control. Built-in
battery makes it easy to mount the motor without having
power supply. LEU/L series tubular motors are compatible
with all YOODA brand devices.
Radio receiver memory:
up to 20 transmitters
Power supply:
USB DC 5 V 2 A
Operating temperature:
from -10°C to 55°C
Protection degree:
IP 40
Load:
2,5 kg
radio receiver,
1
motor gear
