GV-Face Recognition Camera
GV-VD8700
GV-FD8700-FR
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
User's Manual
VD8700-UM-B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-FD8700-FR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-FD8700-FR

Summary of Contents for GeoVision GV-FD8700-FR

  • Page 1 GV-Face Recognition Camera User’s Manual GV-VD8700 GV-FD8700-FR Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. VD8700-UM-B...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Welcome to the GV-Face Recognition Camera User’s Manual. The instructions will guide you through the installation and use of the camera. This Manual is designed for the following models: Model Model Number IR Vandal Proof IP Dome GV-VD8700 IR Fixed IP Dome GV-FD8700-FR...

  • Page 4: Table Of Contents

    Contents Note for Connecting to GV-DVR / NVR / VMS............vi Note for Recording ....................vii Note for Installing Camera Outdoor ..............viii Optional Accessories ....................ix Chapter 1 Introduction................... 1 1.1 System Requirements.....................3 1.2 Packing List ......................4 1.2.1 GV-VD8700....................4 1.2.2 GV-FR8700-FR ...................6 1.3 Overview.........................7 1.4 Installing the Camera ....................9 1.4.1 GV-VD8700....................9...
  • Page 5 4.1.5 Text Overlay ....................39 4.2 Event and Alerts....................40 4.2.1 Face Recognition ..................40 4.2.2 Tampering Alarm ..................41 4.2.3 Motion Detection ..................42 4.2.4 I/O Control ....................43 4.2.4.1 Input Settings................43 4.2.4.2 Output Settings................44 4.2.5 E-mail......................45 4.2.6 Event Manager..................46 4.3 Network ........................
  • Page 6 5.6.5 Trigger Area ....................81 Chapter 6 Recording and Playback ..............82 6.1 Playback Using the Memory Card................. 82 Chapter 7 Advanced Applications ..............83 7.1 Upgrading System Firmware................. 83 7.1.1 Using the Web Interface................83 7.1.2 Using the GV-IP Device Utility ..............84 7.2 Restoring to Factory Default Settings..............
  • Page 7 Regulatory Notices FCC Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 8: Note For Connecting To Gv-Dvr / Nvr / Vms

    Naming Definition GeoVision Analog and Digital Video Recording Software. The GV-DVR / NVR GV-DVR also refers to GV-Multicam System or GV-Hybrid DVR. GV-VMS GeoVision Video Management System for IP cameras. Note for Connecting to GV-DVR / NVR / VMS The camera is designed to work with and record on GV-DVR / NVR / VMS, a video management system.

  • Page 9: Note For Recording

    Note for Recording 1. By default, the recording function is disabled. Configure the function in the camera’s Web interface to record alarm events to the memory card inserted in the camera upon disconnection from GV-DVR / NVR / VMS. See 4.4.3 Tools for details. 2.

  • Page 10: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the camera outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 11: Optional Accessories

    Optional Accessories Optional devices can expand your camera’s capabilities and versatility. Contact our sales representatives for more information. Device Description GV-Mount Accessories provide a comprehensive lineup of accessories for installing the camera on ceiling, wall corner GV-Mount Accessories and pole. For details, see GV-Mount Accessories Installation Guide.

  • Page 12: Chapter 1 Introduction

    GV-VD8700 is designed for outdoors, with IK10 vandal resistance and IP66 ingress protection while GV-FD8700-FR is intended for indoors. Both cameras support H.265 video codec to achieve better compression ratio while maintaining high-quality pictures at reduced network bandwidths.
  • Page 13 Getting Started Features:  1/2.5” progressive scan low lux CMOS  Min. illumination at 0.04 lux  Triple streams from H.265 and H.264  Up to 30 fps at 3840 x 2160  Megapixel varifocal lens  P-iris lens for auto iris control ...

  • Page 14: System Requirements

    1.1 System Requirements To access the Web interface of the camera, make sure the connected network is stable and use one of the following Web browsers:  Microsoft Internet Explorer 11 or later  Google Chrome Note: When using Google Chrome browser, only H.264 video codec is supported and there has a live view delay of 2~5 seconds.

  • Page 15: Packing List

    Getting Started 1.2 Packing List 1.2.1 GV-VD8700   Screw Anchor x 4 GV-VD8700 Camera   Audio Wire x 2 Screw x 4   RJ-45 Connector I/O Cable  Installation Sticker  Waterproof Rubber Sets (for RJ-45 Cat.5 and DC12V / for RJ-45 Cat. 6) Cat.6 Cat.5 (Ø...
  • Page 16  Ruler  8 GB Micro SD Card (MLC, SDHC, Class 10) (The Micro SD Card is preinstalled and formatted in the camera)  Download Guide  Warranty Card Note: You can run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter and plastic PG21 conduit connector with a self-prepared 1/2’’...

  • Page 17: Gv-Fr8700-Fr

    Getting Started 1.2.2 GV-FD8700-FR   Torx Wrench GV-FR8700-FR Camera   Screw Anchor x 3 Screw x 3   Installation Sticker I/O Cable   Audio Wire x 2 8 GB Micro SD Card (MLC, SDHC, Class 10) (The Micro SD Card is...

  • Page 18: Overview

    1.3 Overview Figure 1-1...
  • Page 19 Connects to a built-in microphone to record sound. For Built-in Microphone details, see 1.5 Connecting the Camera. Connectors Note: Not available for GV-FD8700-FR. Waterproofs the audio / I/O wires. Conduit Connector Note: Not available for GV-FD8700- Contains a micro-SD card (SD/SDHC/SD XC/UHS­I, Class...

  • Page 20: Installing The Camera

    .4 Installing th e Ca mera This section introduces the standard installations of the cameras. Note: For optimal face recognition results, follow recommended guidelines to install the camera. For details, see 5.3 Ideal Camera Position. You can also install the camera to ceilings, wall corners (concave or convex), and poles using optional mounting kits.
  • Page 21 Getting Started Optionally remove the cables that attach the built-in microphone to the camera to assist with installation. Cables for built-in microphone Figure 1-3 Remove the back plat e with the supplied torx wrench and remove the safety lock with a Philips screwdriver.
  • Page 22 Unplug the conduit connector inside the housing and disintegrate the connector. You should have 3 parts: Figure 1-6 Thread the audio wires and I/O wires through the conduit entry and then through parts 1, 2, and 3 of the conduit connector. Tip: To make the threading easier, it is recommended to thread the wires in the order described in Step 4-C.
  • Page 23 Getting Started If you use cat 5 Ethernet cable, there are 5 holes each labeled with its diameter. Remove th plugs and push the wires to the corresponding hole listed below: Plug Figure 1-7 3.2 mm: Audio 1.9 mm: DIDO Figure 1-8 IMPORTANT: Use the supplied ruler and leave at least 14 cm of I/O wires and 10 cm of audio...
  • Page 24 If you use cat 6 Ethernet cable, thread the DC 12V wires through the conduit connector. Refer the following figure for the corresponding holes and their diameter 3.2 mm: Audio 1.9 mm: DIDO 1.9mm: DC 12V Figure 1-9 IMPORTANT: Leave more than 10 cm of power wires between their connectors on the camera and the conduit connector.
  • Page 25 Getting Started Thread an Ethernet cable (the end with no RJ-45 connector) and the optional power adapter wires from the back panel through the conduit connector. Figure 1-11 IMPORTANT: Use the supplied ruler and leave about 14 cm of the Ethernet cable between the connector the camera and the conduit connector.
  • Page 26 Sort out the wires at the back. You can have the wires come out from positions A and B or from C. Figure 1-12 Secure the back plate to the ceiling. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces.
  • Page 27 Getting Started Secure the camera to the desired location. Secure the safety lock to the camera with the screw you removed from the back plate in Step 2. Safety lock Figure 1-14 Thread all the wires into the ceiling and connect them. Secure the camera to the back plate with the supplied torx wrench.
  • Page 28 11. Adjust the angle, focus and zoom of the camera. Pan Adjustment Tilt Adjustment Rotational Adjustment Zoom Adjustment Focus Adjustment Loosen the screw Loosen the screw Figure 1-15...

  • Page 29: Gv-Fr8700-Fr

    Figure 1-16 1.4.2 GV-FD8700-FR The camera is designed for indoors. With the standard package, you can install the c on the ceiling or the wall. Before installation, make sure the installing site is shielded from rain moisture.
  • Page 30 Place the installation sticker where you want to install it, and make 3 marks on the ceiling or the wall for screw anchors Figure 1-18 Drill the marks and insert the screw anchors. Connect the ca mera to n etwork and power. For details, see 1.5 Connecting the Camera. Secure the camera to the ceiling or the wall with the supplied screws.

  • Page 31: Connecting The Camera

    Getting Started 1.5 Connecting the Camera Figure 1-20 Use a standard network cable to connect the camera to your network. Optionally connect an external microphone. Connect power using one of the following methods:  Plug the power adapter to the power port. ...

  • Page 32: I/O Connector

    1.6 I/O Connector The camera supports one digital input and one digital output of dry contact. Supplied I/O Cable Function Green Digital Output Black White Digital Input For details on how to enable an installed I/O device, see 4.2.4 I/O Control.

  • Page 33: Chapter 2 Getting Started

    IP address to avoid IP address conflict with other GeoVision IP devices on the same LAN. To change the IP address, see 2.2 Changing the IP Address later in this chapter.

  • Page 34: Changing The Static Ip Address

    Find the Mac Address of the camera to see its IP address. Figure 2-1 2.2 Changing the Static IP Address Whe the DHCP server on your network is unavailable or disabled, the camera can be accessed by the default IP 192.168.0.10. To modify the static IP address, log in the We interface to access the network setting page.
  • Page 35 Getting Started IMPORTANT: Use the dynamic DNS Service to obtain a domain name linked to the camera’s changing IP address before you start using the dynamic IP address. For details on Dynamic IP Address, see 4.3.2 Advanced TCP/IP and 4.3.1 LAN Configuration. If Dynamic IP Address is enabled and you cannot access the camera, you may have to reset it to the factory default settings and perform the network settings again.

  • Page 36: Accessing Your Surveillance Images

    2.3 Accessing Your Surveillance Images Two types of users are allowed to log on to the camera: Administrator and Guest. The Administrator has full access to all system configurations, while the Guest can only access the live view and network status. Once the camera is connected to the network, follow these steps to access your surveillance images: 1.

  • Page 37: Configuring The Basics

    Figure 2-4 Note: To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a once-only installat ion of GeoVision’s ActiveX component onto your computer. 2.3 Configuring the Basics Once you have logged in to the camera, you are ready to configure some of its primary settings through the Web interface: ...

  • Page 38: Chapter 3 Accessing The Live View

    Chapter 3 Accessing the Live View 3.1 The Live View Window This section introduces the features of the Live View window and Network Status on the main page. Figure 3-1 No. Name Function Play Plays live video. Stop Stops playing video. Takes a snapshot of live video.
  • Page 39 Accessing the Live View On the Live View window, right-click the image to have these options:  Snapshot: Takes a snapshot of live videos.  Full Screen: Switches to full screen view.  PIP: Enables an inset window for a close-up view on the Pop-up Menu video.

  • Page 40: The Control Panel Of The Live View Window

    3.2 The Control Panel of the Live View Window The control panel is on the right side of the Live View window. You can adjust the settings of the following functions on the control panel. Note these settings are only accessible for Administrator.
  • Page 41 Accessing the Live View  Shutter Speed: Shutter speed controls the amount of light entering the image sensor and directly impacts the quality of image presentation. A slower shutter speed allows higher light exposure, which creates a brighter overall image and brings out background details, but blurs moving objects.

  • Page 42: Snapshot Of A Live Video

    3.3 Snapshot of a Live Video To take a snapshot of live video, follow these steps: 1. Click the Snapshot button (No. 3, Figure 3-2). The Save As dialog box appears. 2. Specify Save in, type the File name and select JPEG or BMP as Save as Type. You may also choose to display the camera name and/or the date, the text color and image quality of the snapshot.

  • Page 43: Picture-In-Picture View

    Accessing the Live View 3.5 Picture-in-Picture View The full screen mode provides a particular type of close-up view: Picture-in-Picture (PIP). With the Picture-in-Picture (PIP) view, you can zoom in on the video to get a close-up view. Navigation box Inset window Figure 3-3 1.

  • Page 44: Chapter 4 Administrator Mode

    Chapter 4 Administrator Mode The Administrator can access and configure the camera over the network. The configuration categories include: Audio & Video Settings, Event and Alerts, Network and Management. Figure 4-1 Corresponding Sections for Configuration Menu Find the topic of interest by referring to the indicated section. 4.1.1 Video Settings 4.1.2 Audio Settings 4.1 Audio &...

  • Page 45: Audio & Video Settings

    Administrator Mode 4.1 Audio & Video Settings The camera supports three streams, Streaming 1, Streaming 2, and Streaming 3, which allow separate codec and resolution settings for a single video transmission. In a bandwidth-limited network, such as mobile phone surveillance, this multi-stream feature allows you to view live video in lower resolution and codec (Streaming 2 / Streaming 3), and record in highest resolution 3840 x 2160 and codec H.265 (Streaming 1) at the same time.
  • Page 46 [Video Format] Select either H.265 or H.264 as codec type. [Resolution] Configure the resolution. The supported resolutions are listed below: Streams Ratio Supported Resolution 3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 720 Streaming 1 16:9 1280 x 720, 640 x 360 Streaming 2 Streaming 3 640 x 360...

  • Page 47: Audio Settings

    Built-in Microphone or External Microphone as the source of audio input. Figure 4-3 Note: 1. GV-FD8700-FR is not equipped with built-in microphone. 2. The microphone input interface only works with external microphone with power supply. For details, see 1.5 Connecting the Camera.

  • Page 48: Rtsp

    4.1.3 RTSP The RTSP enables video and audio streaming to your 3G-enabled mobile phone. The RTSP streaming is enabled by default. Figure 4-4 [Enable Audio] Turns audio streaming on or off. [Authentication] The ID and password of the camera are required to access the camera through RTSP connections.

  • Page 49: Privacy Mask

    Administrator Mode 4.1.4 Privacy Mask You can use the Privacy Mask to block out sensitive areas on live view and recorded clips. This feature is ideal for scenes with displays, keyboard sequences (e.g. passwords), and for anywhere else you don’t want sensitive information visible. Figure 4-5 1.

  • Page 50: Text Overlay

    4.1.5 Text Overlay The Text Overlay allows you to overlay the camera name and date & time on the camera view. Up to 33 characters can be created on one camera view. The overlaid text will be saved in the recordings.

  • Page 51: Event And Alerts

    Administrator Mode 4.2 Event and Alerts For the events of motion detection, tampering alarm or I/O trigger and face groups, the Administrator can set up triggered actions to send a snapshot by e-mail and / or activate an output device. To have above triggered actions, you must also set the following features: ...

  • Page 52: Tampering Alarm

    4.2.2 Tampering Alarm Tampering Alarm is used to detect whether a camera is being physically tampered. An alarm can be generated when the camera is moved, covered up, or out of focus. The alarm types include output triggers and email alerts. Figure 4-7 Select the Enable option.

  • Page 53: Motion Detection

    Administrator Mode 4.2.3 Motion Detection Motion detection is used to generate an alarm whenever movement occurs in the video image. You can configure up to 4 areas with different sensitivity values for motion detection. Set up at least one area to enable this function. Figure 4-8 Select the desired sensitivity under Sensitivity.

  • Page 54: I/O Control

    4.2.4 I/O Control After installing the I/O device, you need to enable the I/O settings on the camera. For installing the I/O device on the camera, see 1.6 I/O Connector. 4.2.4.1 Input Settings To activate the sensor input, select Enable. Figure 4-9 ...

  • Page 55: Output Settings

    Administrator Mode 4.2.4.2 Output Settings Select Enable to start the output device. Figure 4-10  Name: Name the output in the Name field.  Normal State: Choose the output signal that best suits your device: Open Circuit (N/O) and Grounded Circuit (N/C). ...

  • Page 56: E-Mail

    4.2.5 E-mail After an event is triggered, the camera can send an e-mail to a remote user containing a snapshot. IMPORTANT: To send e-mail alert upon motion, be sure to set up the detection area on the Motion Detection page. For details, see 4.2.3 Motion Detection. Figure 4-11 To enable the e-mail functions: 1.

  • Page 57: Event Manager

    Administrator Mode 4.2.6 Event Manager You can set up the connection to GV-FWC Server and integrate 3 -party software through Http settings. Figure 4-12 [Settings] After setting up HTTP Event and/or GV-FWC in their separate pages under the Event Manager, you need to enable their functions here to activate the connection. [Send events when faces in the selected group(s) detected] Send the events to GV-FWC Server or 3 -party software when any face of the selected groups is detected.

  • Page 58: Network

    4.3 Network The Network section includes some basic but important network configurations that enable the camera to be connected to a TCP/IP network. 4.3.1 LAN Configuration According to your network environment, select between Static IP address or Dynamic IP address. Figure 4-13 [LAN Configuration] ...
  • Page 59 Administrator Mode [Network Status Information] In this tab, you can view the current network status. Figure 4-14...

  • Page 60: Advanced Tcp/Ip

    DHCP Server or ISP (in xDSL connection) has changed. Before enabling the DDNS function, the Administrator should apply for a Host Name from the DDNS service provider’s website. There are 2 providers listed in the camera: GeoVision GVDIP or DynDNS.org.
  • Page 61 GeoVision DDNS V2 and obtain a host name. Figure 4-16 3. Type the Host Name used to link to the camera. For the users of GeoVision DDNS Server, it is unnecessary to fill the field because the system will detect the host name automatically.
  • Page 62 [HTTP Port Settings] The HTTP port enables connecting the camera to the Web. For security integration, the Administrator can hide the server from the general HTTP port by changing the default HTTP port of 80 to a different port number within the range of 1024 through 65535. Figure 4-17 [HTTPS Settings] By enabling the Hypertext Transfer Protocol Secure (HTTPS) settings, you can access the...

  • Page 63: Ip Filter

    Administrator Mode 4.3.3 IP Filter The Administrator can set IP filtering to grant or restrict access to the camera. Note that you can only set up 4 filter entries for the camera. Figure 4-19 To enable the IP Filter function: 1.

  • Page 64: Management

    4.4 Management The Management section includes the settings of date, time and user account. You can also view the firmware version and execute certain system operations. 4.4.1 Date and Time The date and time settings are used for date and time stamps on the image. Figure 4-20 [Date &...

  • Page 65: User Account

    Administrator Mode 4.4.2 User Account You can change the login name and password of Administrator and the Guest user accounts. Figure 4-21...

  • Page 66: Tools

    4.4.3 Tools This section allows you to execute certain system operations and view the firmware version. Figure 4-22 [Device Settings] You can reboot the camera, restore the camera to its factory default settings, or import / export the system settings. ...
  • Page 67 Administrator Mode  Disconnection Record: Select On to enable the service.  Video Time Interval (minutes): Choose the duration time between 1, 2, 3, 4, or 5 minutes. When the recording starts once the camera is disconnected from GV-DVR / NVR / VMS, the camera will record videos for the specified time period.

  • Page 68: External Storage Settings

    4.4.4 External Storage Settings You can view the memory card information in this page. Format the memory card before using it for the first time. After being formatted, the memory card will be ready to use. To insert or remove a SD card, see 1.3 Overview. Figure 4-23 [Tools] ...

  • Page 69: System Log

    Administrator Mode 4.4.5 System Log The log contains dump data that is used by service personnel for analyzing problems. Figure 4-24 Clear: Click Clear to delete all system logs.  Download: Click Download to download all system logs to your computer. ...

  • Page 70: Chapter 5 Face Recognition

    Chapter 5 Face Recognition GV-VD8700 and GV-FD8700-FR can detect for and identify persons’ faces from its predefined database. Upon successful recognition, the name of the person identified is displayed on the live view while the related data are recorded into the camera as a recognition event, as exemplified by the figure below.

  • Page 71: Features

    Face Recongition 5.1 Features  Store up to 10,000 face data entries  Recognize up to 10 faces simultaneously  Maximum recognition distance of 4 meters (13.12 ft)  Minimum recognition time of 2 seconds  Output alarm trigger through face group settings ...

  • Page 72: Installation Flowchart

    5.2 Installation Flowchart Follow the step-by-step guide to set up face recognition and refer to the relevant sections if needed. Figure 5-2...

  • Page 73: Ideal Camera Position

    Face Recongition 5.3 Ideal Camera Position Face recognition works best when the camera is properly aligned with the face of the recognition target. When installing the camera, make sure to take the relevant environmental factors into account, such as height, distance, focus and range, to achieve optimal recognition results.
  • Page 74  Focus: A large depth of field not only ensures an appropriate image size for the faces of the recognition targets, but also allows them to stay in focus for a longer period of time, thereby increasing the recognition accuracy. Calibrate the lens at the telephoto end for effective recognition at its optimal recognition distance of 4 m (13.12 ft).

  • Page 75: Adjusting Illumination

    Face Recongition 5.4 Adjusting Illumination After installing the camera properly, it is required to adjust the environment’s lighting since the recognition process may vary depending on the illumination. Follow the guidelines below to set up the environment’s lighting according to Daytime, Nighttime and Low Illumination (WDR) recognition needs.

  • Page 76: Nighttime

    5.4.2 Nighttime If you found recognition results to be less optimal at night, you can use extra IR LED tubes as a lighting aid for the camera or create extra face data under IR LED illumination. Both methods can be applied to achieve optimal face recognition results at night. Figure 5-6 ...

  • Page 77: Low Illumination (Wdr)

    Face Recongition 5.4.3 Low Illumination (WDR) Intense lighting contrast in an environment may cause ineffective recognition results. In this case, there are two ways to compensate for recognition accuracy:  Apply Wide Dynamic Range (WDR) or Back Light Compensation (BLC): By default, the WDR function is enabled.

  • Page 78: Enrolling Face Data

    5.5 Enrolling Face Data After the camera and the environment’s lighting are set, it is required to create the face data by adding photos of the persons to be recognized into the Face Database of the camera. To enroll Face Data: Click System Settings.
  • Page 79 Face Recongition Fill out the following information: Figure 5-10  Name: Type a desired name for the person.  Organization: Type a desired organization name for the person.  Group: Select from a list of three groups in which the person shall be categorized under.
  • Page 80 Note: The group settings can be used to trigger output alarms on the camera, and on the VMS through a GV-I/O Box. For related settings, see 5.6.5 Trigger Area in the manual and Configuring Face Setting, Chapter 3, GV-VMS User’s Manual respectively. It is possible to create two face data with identical names in the database.

  • Page 81: Photo Requirements

    Face Recongition 5.5.1 Photo Requirements For face recognition to work, it is required for the photos to meet the following criteria:  Each photo should consist of only one face.  Size of the face in the photo is around 120 ~ 150 pixels. ...
  • Page 82 More photos with different variations and under different lighting conditions can increase the recognition performance. It is recommended to include at least a front view (close view and distant view), a tilted-left view, a tilted-right view, and a 20 degree view from above view per face ID.
  • Page 83 Face Recongition Using Snapshots If for any reason standard portrait photos cannot be taken, you can increase the recognition performance by using snapshots taken from the surveillance site. Possible scenarios may include:  Nighttime Recognition: where the installation site may not be subjected to IR LED enrollment conveniently.

  • Page 84: Face Recognition Basic Settings

    5.6 Face Recognition Basic Settings 5.6.1 Settings After the camera is installed, select Enable to activate face recognition and click Apply. Figure 5-14 [Confidence Level] Select the confidence level for different precision requirements.  At level 50, the camera identifies similar faces from the face database when a person passes by.
  • Page 85 Face Recongition [Export Face Database] Export the face database of the camera into a zip file and save it on your PC, to be backed up or used for other cameras. [Import Face Database] Import a face database into the camera. [Group Management] Click to edit the name of the existing face groups, or click to add a face group.

  • Page 86: License

    5.6.2 License The license key is programmed by default. When the license key is programmed properly, the settings page will show Face recognition license activated. Figure 5-15...

  • Page 87: Management

    Face Recongition 5.6.3 Management In the Management section, you can enroll, review, search and edit the enrollment data of a specific entity, including pictures and name. Figure 5-16 [Filter Name] Type Name and click Search to retrieve the face data of a particular person. [Add new record] Click to create new face data.

  • Page 88: Events

    5.6.4 Events In the Events section, you can search the face event log, enroll faces and synchronize with face databases of other cameras. The camera keeps the events for 7 days or up to 160,000 events. After reaching either the 7 days or the 160,000 events quota, the oldest event is recycled.
  • Page 89 Face Recongition To locate specific events, select Advanced Search. The search field appears. Figure 5-18  Filter Name: Type the name of the person to filter for the person’s recognition events.  Filter Group: Select among VIP, Normal and Welcomed from the drop-down list to show the event log of all persons who belong to that group.

  • Page 90: Enrolling Faces

    To update and show query results periodically, select Auto Polling. Type the time interval in minutes in the next field. See Figure 5-18. Note: The actual event time may vary depending on your computer’s clock. When using the Search function, the results will include all entries containing the keyword searched for, unless further specified.

  • Page 91: Synchronizing Face Databases

    Face Recongition 5. To insert the new face into an existing record, click INSERT INTO EXIST REC at the top bar to open the following dialog box and search the name for the face. Figure 5-21 5.6.4.3 Synchronizing Face Databases You can synchronize the face databases of more than one camera.

  • Page 92: Trigger Area

    5.6.5 Trigger Area You can specify an area of interest to trigger face recognition, and an output device if a person from the selected groups appears on the live view and/or if the person fails to be recognized from the database. Figure 5-23 [Trigger Area] Select Full to fill the entire screen or select Customize to define an area of interest to trigger face recognition and/or an output device.

  • Page 93: Chapter 6 Recording And Playback

    Recording and Playback Chapter 6 Recording and Playback The camera can only record video and audio to the camera’s memory card upon disconnecting from GV-DVR / NVR / VMS. To do so, make sure that the micro-SD card is inserted into the memory card slot (No.15, Figure 1-2), formatted (see 4.4.4 External Storage) and enable the Disconnection Record function.

  • Page 94: Chapter 7 Advanced Applications

    Chapter 7 Advanced Applications This chapter introduces advanced applications. 7.1 Upgrading System Firmware GeoVision periodically updates the latest firmware to the company website. You can update the camera’s firmware through the Web interface or GV-IP Device Utility. 7.1.1 Using the Web Interface On the top bar, go to System Settings.

  • Page 95: Using The Gv-Ip Device Utility

    Advanced Applications 7.1.2 Using the GV-IP Device Utility The IP Device Utility provides another way to upgrade the firmware. Note the computer used to upgrade firmware must be under the network of the camera. Download and install the GV-IP Device Utility from our Website. Double-click the GV-IP Device Utility icon created on your desktop.
  • Page 96 Click the Firmware Upgrade tab. This dialog box appears. Figure 7-4 Click the Browse button to locate the firmware file (.img) saved at your local computer. Type Password, and click Upgrade to start the upgrade.

  • Page 97: Restoring To Factory Default Settings

    Advanced Applications 7.2 Restoring to Factory Default Settings If for any reason the camera is not responding correctly, you can reset it to its factory default setting by using the camera’s Web interface or by operating directly on the camera. 7.2.1 Using the Web Interface On the Web interface, go to System Settings.

  • Page 98: Chapter 8 Dvr / Nvr / Vms Configurations

    The camera supports up to 8 streams of connection.  When the camera is connected to IE browser or GeoVision CMS applications, it takes up 1 stream when it is connected to GV-DVR / NVR / VMS, it takes up 2 streams.

  • Page 99: Setting Up Ip Cameras On Gv-Dvr / Nvr

    DVR / NVR / VMS Configurations 8.1 Setting Up IP Cameras on GV-DVR / NVR Follow the steps below to manually connect your camera to GV-DVR / NVR. Note: The following instructions are based on GV-DVR / NVR V8.7.4.0 software and user interfaces.
  • Page 100 Click OK. This dialog box appears. Figure 8-4 Click OK to add the camera to the connection list. Click the listed camera and select Display position to map the IP camera to channel on the GV-DVR / NVR. Figure 8-5 The Status column now should display “Connected”.

  • Page 101: Customizing Camera Settings On Gv-Dvr / Nvr

    DVR / NVR / VMS Configurations 8.1.1 Customizing Camera Settings on GV-DVR / NVR After the camera is connected and assigned with a display channel, you can configure the camera’s settings such as frame rate, codec type and resolution. Right-click the camera to see the following list of options: Figure 8-6 ...
  • Page 102  Frames to keep in live view buffer: Specifies the number of frames to keep in the live view buffer.  Recording Codec Format: Specifies whether to record in standard or GeoVision type of H.264 / H.265 codec.  ONVIF Settings: Adjusts the camera’s video settings when connecting through ONVIF...

  • Page 103: Setting Up Ip Cameras On Gv-Vms

    DVR / NVR / VMS Configurations 8.2 Setting Up IP Cameras on GV-VMS Follow the steps and conform the integration specification below to manually connect your camera to GV-VMS.  When applying Face Recognition, one camera can only be connected to one GV-VMS host at a time.
  • Page 104 Double-click the camera and type its User name and Password. Figure 8-8 Click OK. This dialog box appears. Figure 8-9 Click OK to add the ca mera to the list. To connect the added camera, click the box besides the ID column. Upon successful connection, the Status icon shows green, with the video resolution and bit rate being displayed in the correspondent columns.

  • Page 105: Chapter 9 Smart Device Connection

    Chapter 9 Smart Device Connection You can access the live view and play back recordings on your mobile devices using the mobile app GV-Eye. For details on system requirements, installation and setup, visit our website.

  • Page 106: Appendix

    The camera supports RTSP protocol for both video and audio streaming. For RTSP command, enter: rtsp://<IP of the GV-VD8700:8554/<CH No.>.sdp rtsp://<IP of the GV-FD8700-FR:8554/<CH No.>.sdp For example, rtsp://192.168.3.111:8554/CH001.sdp Note: Only VLC and QuickTime players are supported for streaming video via RTSP protocol.

This manual is also suitable for:

Gv-vd8700
