INSTALLATION INSTRUCTIONS
5
5.1
Insert Camlocks (I) in holes in Set Shelf (D), Rear Hanging Cleats (E) and Toe Kick (F) with arrow pointing
toward Cam Post opening. Be sure Camlocks engage Cam Posts, and are fully seated in Shelf, Cleats and
Toe Kick.
5.2
Tighten Camlocks (I) clockwise to lock.
5.3
Repeat steps 2 through 5 using Left Side Panel (A2) and Right Side Panel (B2).
ASSEMBLY AND
VANITY, 193619
D
E
I
E
I
I
ARROW TOWARD
CAM POST OPENING
I
I
