AirLive SOHO Live Series Quick Setup Manual

EN
Quick Setup Guide
Live-16E
16x 10/100Mbps RJ45
Live-8E
8x 10/100Mbps RJ45
Live-5E
5x 10/100Mbps RJ45
Installation Steps
Figure A

Live Ethernet Switch

10/100Mbps
Live-5E, Live-8E, Live-16E
Power
Power

LED DEFINITIONS

Green ON
Power
Green OFF
Green ON
Link/Act
Green OFF

Installation Step:

1. Remove the switch and accessories from the package.
2. Connect power to the switch. Make sure that "Power" LED is on.
3. Check the Port LED indicator status. When a device is connected
the port will light up.
4. For more product information visit www.airlive.com.

Declaration of Conformity

We, Manufacturer/Importer
AirLive Technology Corporation
4F, No.132, Lane 235, Baoqian Rd., Xindian Dist.,
New Taipei City 23145, Taiwan
Declare that the product
SOHO Live Series Switch
Live-5E, Live-8E, Live-16E, Live-5GT, Live-8GT
is in conformity with
In accordance with 2014/30/EU and 2014/35/EU Directive
Clause
(EMC)
■ EN 55032:2015+A11:2020
■ EN 55035:2017+A11:2020
■ EN 61000-3-3:2013+A2:2021+AC:2022-01
■ EN IEC 61000-3-2:2019+A1:2021
(LVD)
■ EN IEC 62368-1:2020/A11:2020
Conformity with
In accordance with RoHS Directive 2011/65/EU Annex II amending
Annex (EU)2015/863 and amending Annex (EU)2017/2102
■ CE marking
Manufacturer/Importer / po ter
Name : A van Rossem Position/ Title : Product Manager
Place : Taiwan
AirLive Technology Corporation declares that this device
is in compliance with the essential requirements and
other relevant provisions of directive 2014/30/EU, 2014/35/EU
Live Ethernet Switch
10/100Mbps
Live-5E, Live-8E, Live-16E
Power is on and normal.
The switch is not receiving power.
Link connected.
Link disconnect
Date : October 2023
