Summary of Contents for Colorlight X2s

  • Page 1 X2s/X4s Controller...

  • Page 2: Table Of Contents

    Content Safety Information ................................1 1 Overview ....................................2 1.1 Overview .................................... 2 1.2 Structure .................................... 2 2 Operation Instructions ..............................4 2.1 Signal Connection ................................. 4 2.2 Power On ..................................4 2.3 Software Control ................................5 2.3.1 Sending Device Settings..........................6 3 LCD Operation Instruction ............................

  • Page 3: Safety Information

    Safety Information To prevent personal injury and to protect the device from damage, read and follow these safety precautions. ⚫ Do not remove the cover To avoid personal injury, do not remove the top cover. ⚫ Only use the power supply and accessories specified by the manufacturer The operating voltage of this product is 100V-240V AC.

  • Page 4: Overview

    1 Overview 1.1 Overview X2s/X4s is a professional LED display controller possessing powerful video signal receiving and processing capacity. It supports multiple signal inputs, of which the resolution is up to 1920×1200 pixels. It allows seamless switching between video sources and arbitrary scaling and cropping of signal images.
  • Page 5 USB IN, connecting to PC for debugging USB OUT, for cascading with the next controller AUDIO Audio input HDMI/DVI1/DVI2 Support resolution up to 1920×1200@60Hz Gigabit Ethernet Outputs X2s—2×RJ45 Gigabit Ethernet ports X4s—4×RJ45 Gigabit Ethernet ports Other Specifications Operating Temperature: -20℃~60℃ Anti-static design, low EMI radiation...

  • Page 6: Operation Instructions

    2 Operation Instructions The following are operation instructions taking the X4s controller as an example. 2.1 Signal Connection 2.2 Power On Press the power switch on the front panel, and the device will be turned on and enter the self-test status, and then all the button lights will light up in sequence until booting successfully.

  • Page 7: Software Control

    2.3 Software Control 1. Open LEDVISION software，click Control > LED Screen Settings, or click to enter the LED Screen Settings window. The authorized password is “168”. 2. Click Sending Device > Sender > Detect Senders > Detect Receivers > Detect All Receivers.

  • Page 8: Sending Device Settings

    2.3.1 Sending Device Settings The setting of sending device contains three aspects: Video Source Settings, Control Area and Other. 1.Video Source Settings ① Signal Source Selection When the input of signal source of the X4s controller is normal, the information of input signals obtained by the software can be displayed in the upper-right corner of the Video Source Settings page.
  • Page 9 ② Main Image Output In the canvas area, select the image that you want to scale up or down, and set the row starting point(X), column starting point(Y), width and height in the Main area, or drag the frame of the selected window to scale up or down the image. Note: A.
  • Page 10 ③ Cropping and EDID Select a signal source in the upper-left corner of the page, and then click the cropping icon of the selected signal on the upper-right side of the page to enter the cropping setting window. In the cropping setting window, select the Enable check box, and set the row starting point(X), column starting point(Y), width and height in the Cropping Settings area.
  • Page 11 ④ Saving and Recalling Preset Parameters Click Save as Preset, select an item, modify the name of the preset, and then click OK. Click Recall from Preset, and select the preset that you want to load. 2.Control Area On the Control Area page, you can manually adjust the control area of Ethernet ports.
  • Page 12 3.Other A. Better Graylevel On Low Brightness: Improving the display effect at low brightness. B. Mapping from Sender: Adopting the mapping saved in the sender C. Device Name: Entering the name of the sender D. Temperature: Displaying the operation temperature of the device E.

  • Page 13: Lcd Operation Instruction

    3 LCD Operation Instruction 3.1 Operation Instructions（X4s） Knob/OK: ➢ In the main interface, press the knob/OK to enter the operation menu. ➢ On the operation menu, rotate the knob to scroll to a menu item, press the knob/OK to select the item or enter its submenu. ➢...

  • Page 14: Menu Operation

    Menu Operation Press the knob/OK to enter the operation menu, which includes 9 operation items: Display Setting, EDID Setting, Cropping Setting, Output Area, Preset Setting, Output Shift, Tile Mapping, Language and System Setting. 3.3.1 Display Setting Rotate the knob and select Display Setting to enter the Display Setting submenu. 1.

  • Page 15: Edid Setting

    3. CCT: Press the knob/OK to turn on or off Enable. If Enable is turned on, you can rotate the knob to change the value of color temperature（range: 2000-10000）, or select Reset to Default to reset the value of color temperature as 6500. 4.

  • Page 16: Cropping Setting

    In the EDID setting submenu of HDMI, DVI1 or DVI2, you can rotate the knob and select a conventional resolution to save the selected resolution to the sender, or select Custom and set the width, height and frame rate, and then select Save to save the setting to the sender.

  • Page 17: Output Area

    3.3.4 Output Area Rotate the knob and select Output Area to enter the Output Area submenu, in which you can view and set the row starting point, column starting point, and the width and height of the output image. Finally select Save. 3.3.5 Preset Setting Rotate the knob and select Preset Setting to enter the Preset Setting submenu.

  • Page 18: Output Shift

    3.3.6 Output Shift Rotate the knob and select Output Shift to enter the Output Shift submenu. Output shift contains two selections: Whole and By Port. On the submenu of Whole, you can rotate the knob to set the row starting point (X) and the column starting point (Y) of the whole image and save the setting;...

  • Page 19: Tile Mapping

    3.3.7 Tile Mapping Rotate the knob and select Tile Mapping to enter the Tile Mapping submenu. In the submenu, press the knob/OK to set the sender as the connection source. Then select Set by Port to enter the submenu, in which you can choose the Ethernet port from 1 to 4 that needs setting mapping, and set the row offset value(X) and column offset value(Y) of the port, and the width, height, row number, column number and link type of the corresponding cabinets.
