Cautions To prevent personal injury and equipment damage, read and follow the safety precautions below. Power safety Please do not squeeze the power cord and equipment with heavy objects. The device must use a grounded power supply. There are live parts in the device, non-professionals are not allowed to disassemble the device without ...
Signal: Input source information. Media: Media playback function buttons. Mode: Select a preset. Power button Switch On / Off. the equipment shown in the picture is for reference only. * This picture takes X20m LED video controller as an example, and...
1.2 Rear panel Control RJ45 port, connect to a switch for accessing local area network. RS232 RJ11 port(6p6c), connect to third-party device. USB IN USB2.0 Type B port, connect to a PC for debugging or cascading input. USB OUT USB2.0 Type A port, as cascading output. Audio ...
Page 6
1× DP1.2 port. Maximum 4096×2160@60Hz, Minimum 800×600@60Hz, Maximum pixel clock 600MHz. - Maximum 8192 (8192×1080@60Hz) in width. - Maximum 8192 (1080×8192@60Hz) in height. DP 1.2 Support independent EDID settings, using EDID V1.3 standard. Support audio input. ...
Page 7
Support redundant backup. Power MAINS INPUT AC100-240V, 50 / 60Hz, connect to AC power supply, built-in fuse. the equipment shown in the picture is for reference only. * This picture takes X20m LED video controller as an example, and...
Optical port output: When selecting the optical port output, the optical port is first connected to the optical fiber transceiver (purchase separately), then connected to the LED display screen through the Network. cable. the equipment shown in the picture is for reference only. * This picture takes X20m LED video controller as an example, and...
3 Software operation LEDVISION software to configure the screen and set up Please use Colorlight's the device. - Please make sure the LED screens were set up with correct receiver cards parameters. - Before setting the parameters, ensure that the hardware is connected correctly, which means the sender and all receiver cards can be detected via software.
- Input Interface displays current input ports, when an interface has signal input, it will display (green light). Drag and drop a signal source from the input interface into the canvas on the right, it will display corresponding source window. - Right-click a source window and in the pop-up menu, switch the source of the window, set the layer position and window size as required.
3.6 General settings In the Device View, select the equipment (click on the picture other than input / output area), you can set up Sync Signal Settings, Test Mode, Precise Color Management, 3D Settings(optional), Audio Settings and Other Settings. 3.7 Preset and Tour Enter the Canvas View to set the input source and click Save Preset.
