2.4

Pressure sensor ILPS22QS

The ILPS22QS
barometer, supporting dual full-scale up to user-selectable 4060 hPa. An embedded Qvar (electric charge
variation detection) channel can be enabled for sensing in applications such as tap, double tap, long press, and
L/R - R/L swipe.
The ILPS22QS
SPI interfaces from the sensing element to the application and supports 1.2 V digital interface as well.
The ILPS22QS
Pressure to reach the sensing element.
Order code
Package
Operating voltage
UM3283 - Rev 1
Features
Package
Operating voltage
Figure 7.
is an ultracompact piezoresistive absolute pressure sensor, which functions as a digital output
comprises a sensing element and an IC interface, which communicates over I²C, MIPI I3CSM or
is available in a full-mold, holed LGA package (HLGA). The package is holed to allow external
Table 6.
Features
Description
LGA-14L
1.71 V to 3.6 V
ISM330DHCXTR circuit
ILPS22QSTR details
ILPS22QSTR
HLGA-10L
1.71 V to 3.6 V
UM3283
Component description
Description
page 7/29
