Figure 13. X-Stm32Mp-Gnss2 Schematic Diagram (2 Of 8) - ST X-STM32MP-GNSS2 Getting Started

Figure 13.
3V3
R1
1K
S B1 S B2 S B3
Ope n Ope n Ope n
NM NM NM
R5 R6 R7
22K 22K 22K
NM NM NM
FIDUCIAL1 FIDUCIAL2
Mouting hole _3.2mm drill 1
Fiducia l Fiducia l
FIDUCIAL3
Mouting hole _3.2mm drill 1
Fiducia l
STMicroelectronics and/or its licensors do not warrant the accuracy or
completeness of this specification or any information contained
therein. STMicroelectronics and/or its licensors do not warrant that
this design will meet the specifications, will be suitable for your
application or fit for any particular purpose, or will operate in an
implementation. STMicroelectronics and/or its licensors do not warrant
that the design is production worthy. You should completely validate
and test your design implementation to confirm the system
functionality for your application.
X-STM32MP-GNSS2 schematic diagram (2 of 8)
3V3
C1
R2 R3 R4
100nF
U1
1 8 1K 3.9K 3.9K
E0 VCC
2 7
E1 WC
3 6
E2 S CL
4 5
VS S S DA
M24C32-RMN6TP J R1
J 1 S HUNT 2.54 mm.
1
2
3
HEADER1X3
Jumper
EEPROM (WC)
1-2 WRITE_ENABLE
2-3 (DEFAULT) WRITE_DISABLE
J 2
J 3
1 Mouting hole _3.2mm drill
1
Mouting hole _3.2mm drill
J 4 J 5
EEP ROM_ID_S C
EEP ROM_ID_S D
2mm
17mm
Camera Slot
