Instruction Manual for the
E-S 1100 / E-S 1102 Series
Featuring
! Warning !
Read all instructions before beginning installation or use
of this gate operator.
This operator exerts a high level of force.
Exercise caution at all times and stay clear of the system
during operation.
Manufactured by

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Estate Swing E-S 1100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for FAAC Estate Swing E-S 1100 Series

Summary of Contents for FAAC Estate Swing E-S 1100 Series

  • Page 1 Instruction Manual for the E-S 1100 / E-S 1102 Series Featuring ! Warning ! Read all instructions before beginning installation or use of this gate operator. This operator exerts a high level of force. Exercise caution at all times and stay clear of the system during operation.
  • Page 2 For non-EU countries, to obtain an adequate level of safety, the standards mentioned above must be observed, in addition to national legal regulations. FAAC is not responsible for failure to observe Good Technique in the construction of the closing elements to be motorized, of for any deformation that may occur during use.
  • Page 3 A vehicular gate opener (or system) intended for use in a home of one -to-four single family dwelling, or a garage or parking area associated therewith. The FAAC Estate Swing automated system was designed and built for controlling vehicle access. Do not use for any other purpose.

  • Page 4: Table Of Contents

    Estate Swing The table of contents are listed to assist you locating a desired section. We do how- ever strongly suggest studying every page of the instruction manual before at- tempting installation. SECTION: Review of specifications, warnings, parts, and tools Specifications of the Estate Swing and Components System Overview &...
  • Page 5 Estate Swing The table of contents are listed to assist you locating a desired section. We do how- ever strongly suggest studying every page of the instruction manual before at- tempting installation. SECTION: Diagnostics & Troubleshooting Simple Diagnostics Troubleshooting 7.2-.6 Logic Summaries and Flow Charts 7.7-.8 Alternate Mounting and Programming...
  • Page 6 Estate Swing MODEL Estate Swing Power Supply 115V AC/ 12V DC Rated Absorbed Power (W) Max Static Force (N) 1700 1.25 Load-free linear speed (in./sec.) Rod effective stroke (in.) Use frequency (cycles/hour) Max. 15 Consecutive cycles on charged battery Battery recharge time 10 min.
  • Page 7 Estate Swing Standard System 1,2 Estate Swing Operator 3 Photocells (not included) Overview and Safety 4 Master control board 5 Slave control board Zones 6 Push button opening device (not included) 7 Receiver extension (not included) 8 12Vdc flashing lamp (not included) 9 Positive stop The system display to the right is a 10 AC transformer...

  • Page 8: Estate Swing Parts List

    Estate Swing Estate Swing Parts List Master or Single Operator Slave Operator (If Applicable) A. Control Box A. Control Box B. Operator Arm B. Operator Arm C. Gate Mount Bracket C. Gate Mount Bracket D. Post Mount Brackets D. Post Mount Brackets E.
  • Page 9 Estate Swing Power Drill Crescent Wrench 3/8”, 1/4”, Drill Bits Hacksaw Flat Head Screwdriver Phillips Head Screwdriver Tape Measure Level Wire Strippers C-clamps Other items that may be needed prior to commencing installation. Bolded items are necessary to all applications. Start and stop post, bracket or door stop.

  • Page 10: Control Board Layout

    Estate Swing Control Board Layouts ATTENTION: Study the control board and read this section thoroughly before attempting to operate your gate opener. Warnings: Before attempting any job on the control board (connections, maintenance), turn off electrical power and unplug the support battery. Install a surge protector upstream of your opener, the opener is not power surge proof nor will power surge damage be covered under warrantee.

  • Page 11: Important: Charging Battery Prior To Use

    Estate Swing IMPORTANT: Charging Battery Prior to Use Before beginning any electrical stages of installation we highly recommend charg- ing the battery on the control board for 12 hours. This can be done anywhere there is an outlet available. Fig 1 1.
  • Page 12 Estate Swing For a Dual gate opener unit, charge the slave board by wiring it to the master board terminal strip. [terminal 6 of the master must connect with the right side of J2 on the slave and terminal 15 of the master must connect with the left side of the slave] (fig 3) NEVER CONNECT POWER FROM ANY SOURCE DIRECTLY TO THE SLAVE BOARD.

  • Page 13: Important: 5" X 5" Setback

    Estate Swing IMPORTANT: 5” x 5” Setback The 5” x 5” is a very important requirement to be aware of during installation of the post mounting bracket. The 5” x 5” setback allows the operator arm to achieve appropriate and equal leverage during opening and closing cycles. The purpose of this page is to clarify and show examples of the 5”x5”...

  • Page 14: Installation Of Mounting Hardware And Arm

    Estate Swing Installation of Mounting Hardware and Arm Examples of stops 1. Set up closed stop points for your gate. The closed stop points can be a plate on the end of the gate that comes in contact with an adjacent post or an industrial door stop.
  • Page 15 Estate Swing 4. Measure the 5”x5” setback that was elaborated on in the beginning of this section. 5. Using the rear hole on the “tear” shaped bracket, drill a 5/16” diameter hole in the “L” shaped bracket. 6. Inset the 5/16” bolt in the drilled rear hole. Tighten the nuts on both bolts and leave the combined brackets clamped to the post.
  • Page 16 Estate Swing 8. Insert the bracket bushing into the gate mounting bracket. Inside the black bushing you will see a small bump, this bump must be facing away from the post to prevent binding. 5 Counter Clockwise turns from end. 9.
  • Page 17 Estate Swing 8. Insert the threaded rear fitting into the already clamped post mounting bracket. 9. Position the gate mounting bracket on a cross member of the gate suitable for supporting the arm and bracket with the gate in the FULL CLOSED POSITION pressed firmly against the closed stop.
  • Page 18 Estate Swing 12. Remove the operator arm from the brackets. Leaving the brack- ets clamped in place mark your holes. If you are bolting your brack- ets in place, remove the mounting brackets and drill the marked holes using a power drill with a 3/8” drill bit for the post and 1/4” drill bit for the gate.

  • Page 19: Finding Location And Mounting

    Estate Swing Finding Location and Mounting Control Box The control box must be mounted near your actuator arm. The wire on the back of the actuator arm cannot be shortened or lengthened. Keep you control box in a location at least 3 feet off the ground to avoid water buildup.
  • Page 20 Estate Swing For Your Convenience The green numbered terminal strip at the bottom of the control board is easily re- moved for wiring. Simply pull straight down on the terminal strip to remove it from the board. It will slide right off. Slide it back on when you are finished with your wiring connections.

  • Page 21: Installing Temporary Safety Jumpers

    Estate Swing Installing Temporary Safety Jumpers For your opener to function properly a few connections must be made prior to the learning process. Accessories should NOT be installed until after the learn- ing process is completed. Using the provided jumper wire, connect the normally closed safety terminals (terminals 3, 4, and 5) to one of the negative terminals (terminals 12, 13, 14, or 15).

  • Page 22: Actuator Arm And Dual Power Connections

    Estate Swing Actuator and Dual Power Connections Caution! Do not r ever se polar ity of the wires connecting the Master and Slave board. This will cause permanent damage to both boards and void your warrantee. Caution! Slave Board Power— On the slave board it is used as communication with the master board and powering from the master board.

  • Page 23: Power

    Estate Swing Power 1. The Estate Swing (Master Unit if Dual Operator) comes with 1) AC transformer. The AC transformer supplied has 4 screw terminals, use the center 2 terminals to attach your low voltage wire (polarity is not relevant). You may locate the transformer up to 1000’...

  • Page 24: Programming Gate Movement Variables

    Estate Swing Programming Gate Movement Variables Using the following procedures you can change factory settings such as auto close, speed, force, delays and more. Begin the programming process by pressing P1. Pressing P1 se- lects A,B,C,D or E. A, B, C, D and E correspond with the varia- bles in the chart on the following page.

  • Page 25: Gate Movement Variables Led Chart

    Estate Swing Gate Movement Variables LED Chart Variable LED Definitions Function Function Function Logic — Logic flow chart found on page 18,19 1= A (Automatic - automatically closes the gate depending on the set pause time. It is the most common setting) 2= S (Safety - designed for higher control and accelerated levels of safety, also automatically closes the gate) 3= AP (Stepped Automatic - is very similar to automatic (A) but...
  • Page 26 Estate Swing NOTE: Before beginning the one touch learning procedure be sure to have full open and full closed stop points* set up. These will let your gate know wher e to stop dur ing the lear ning process. Make sure that the leaf or leaves are in the full closed position against the stop points. Check your arm to be sure the gate mount pin is 3 turns from the physical end point of the arm If using an E-S1102 dual operator, both the master and slave arc distance must be the same to use 1 touch programming.
  • Page 27 Estate Swing Wait for the operator or operators to reach the opening stops. The learning procedure has finished. Press P1 once more to exit the learning mode before attempting to operate the open- Single Leaf or leafs will move from closed to open Dual You may now test your gate opener with your transmitter.

  • Page 28: 433 Plug-In Receiver

    Estate Swing Estate Swing 433 Plug-in Receiver 1. With the red plug already inside the control box, run the grey receiver wire out of the box through one of the water tight connections. 2. Find a location for the receiver box on the gate post or a fence post that is within the length of the receiver wire.
  • Page 29 Estate Swing Estate Swing 433 Plug-in Receiver (cont.) 5. Plug the white clip inside the control box into the control board. The groove in the white clip should snap into the guide on the 5 prong connector. (Fig 1) 6. The red power light should come on the receiver. (Fig 2) Fig.

  • Page 30: Simple Diagnostics

    Estate Swing Simple Diagnostics Diagnostics using the Power light on your Master Control Board. The P light has a diagnostic function. There are 4 statuses. 1. Steady light indicating main power is ON and the battery is charged 2. Flashing slowly (lights every second) indicates no main power but the battery is charged.

  • Page 31: Troubleshooting

    3, 4, and 5 are not connected to negative terminals the gate opener will not function. Secondary safety devices are always recommended by Gate Crafters and FAAC, if you choose to only use the in- herent obstruction sensing featured in the Estate Swing control board you must connect terminals 3, 4, 5 to a negative terminal (12, 13, 14, or 15).
  • Page 32 Estate Swing If the power LED (P) is flashing slowly. This means your main power is not on, the battery is low and absorbing too much of the main power, or the main power was plugged in for less than 5 minutes. Be sure before installation the battery is charged for 12 hours.
  • Page 33 Estate Swing Try removing the opener arm from the gate mounting bracket. Run the cycle with the arm off the gate. If the opener no longer stops during cycle, check your gate for levelness, greased hinges, and weight/length ratios. Note: moving your gate from the end by hand may seem very easy.
  • Page 34 Estate Swing If the Front Mount Bolt breaks. This piece is designed to break under stress to prevent costly damage to your operator arm. This piece is easy and cheap to replace thus saving you the time, money and frustration of ex- amining the entire arm for damage and possibly replacing an entire arm.
  • Page 35 Estate Swing If you call in for technical support or warranty support: before any control board or motor will be permitted to be sent in for testing or warranty you will be required to e-mail digital photos to the technician. This is done in your best interest to save unnecessary shipping expenses and time lost.

  • Page 36: Logic Summaries And Flow Charts

    Estate Swing Logic Summaries and Flow Charts Logic A - Logic A (automatic) is the most common setting. It automatically closes the gate depending on the set pause time. This logic must be used in conjunction with the accessories: Free Exit Sensor and Gate Timer. Gate Status Result of Termi- Result of Termi-...
  • Page 37 Estate Swing Logic Summaries and Flow Charts (cont) Logic AP - Logic AP (stepped automatic) is ver y similar to automatic (A) but has a higher amount of safety. It has an increased amount of motion stop points. Gate Status Result of Termi- Result of Termi- Result of Termi-...
  • Page 38 Estate Swing Push-to-Open Operation Push-to-Open operation is a gate opener design with the arm on the inside of the gate and the arm pushes the gate open away from the property, r ather than pulling it in towards the property as in standard operation. Push-to-Open is useful for properties with inclining driveways, a lack of space for opener arm placement or opening (i.e.
  • Page 39 Estate Swing 2. First clamp the “L” shaped post mounting bracket to the post. The two rectangle shaped holes should be against the post. 3. Line up the center hole on the “tear” shaped post mounting bracket with the hole on the on the “L” shaped bracket. Insert the 3/8”x1” bolt and loosely affix the nut and washer.
  • Page 40 Estate Swing 7. Move the pin to the far inside position on the operator arm. Do this by turning the manual re- lease key in the front lock hole counter-clockwise until it reaches the rear stop position. Extend the operator pin in this manner ONLY. Any other method may damage the arm. NOTE: The front stop position IS NOT THE FULL CLOSED POSITION, it is the common point of reference for counting manual 8.
  • Page 41 Estate Swing 10. Insert the threaded rear fitting into the already clamped post mounting bracket. 11. Position the gate mounting bracket on a cross member of the gate suitable for supporting the arm and bracket with the gate in the FULL CLOSED POSITION pressed firmly against the closed stop.
  • Page 42 Estate Swing 14. After properly affixing the mounting brackets insert the arm fittings into the mounting brackets. Using the provided nut and washer on the bottom of the threaded rear fitting at- tach the arm to the post mounting bracket. Insert the arm in the brackets Wiring for PTO Operator Arm(s)
  • Page 43 Estate Swing Complete Start/Stop Learning Process If the learning process was completed using the simple one touch process this process can be by- passed. This procedure is used to define the deceleration and stop points of the operator or operators. The procedure differs depending whether it is single leaf or double leaf.
  • Page 44 Estate Swing Let the leaf make contact with the full open stop With open stop, let the gate point. The opener will then stop and reverse direc- make contact, don’t press P2 tions. OR if not using open stops 2 alt.) Press P2 to stop the openers opening mo- tion and reverse the motion of the gate.
  • Page 45 Estate Swing Procedure for dual leaf gates While the 5 LEDs are lit steadily, hold down P2 for about 3 seconds. The Press for 3 operator will start the maneuver process. Second Using P2, Briefly press the button once for each of the following motion transitions: Press P2 to teach leaf 1 opening deceleration starting point.
  • Page 46 Estate Swing Press P2 to teach leaf 2 opening decelera- tion starting point. With open stops, let the gate Let the leaf make contact with the full make contact, don’t press P2 open stop point. The opener will then stop and reverse directions.
  • Page 47 Estate Swing Let the leaf 2 make contact with the full closed stop point. Leaf 1 will begin closing. Press P2 to teach leaf 1 closing decelera- tion starting point. Let the leaf 1 make contact with the full closed stop point. Press to exit the learning mode.

  • Page 48: Accessory Terminals

    Estate Swing Accessory Terminals Normally Closed connections must be made for proper gate opener function. The full accessory board is only found on the master control board. J1—Terminal Board for Master Card Terminals 1 - “Open/Close Function” This is a normally open terminal where by any device (i.e. push button, keypad, receiver) which, by closing a contact, provides an opening and/or clos- ing pulse for both gate leaves (if there is only one leaf, it will control the one leaf).
  • Page 49 Estate Swing J1—Terminal Board for Master Card (cont.) Terminals (cont.) 5 - “Closing Safety Device” This is a normally closed terminal where by any device (i.e. photocells, sensitive edge, magnetic loops) which, if there is an obstacle in the area they protect during closing, reverses gate direction to opening. If the closing safety devices are tripped when the gate is open, they prevent the leaf movement.

  • Page 50: Photocell & Safety Device Guide

    Estate Swing Photocell & Safety Device Guide Before connecting the photocells (or other devices) we advise you to select the type of operation according to the movement zone to be protected. Opening Safety Devices: They operate only during the gate opening movement and, therefore, they are suitable for protecting the zone between the...
  • Page 51 Estate Swing...
  • Page 52 Estate Swing Accessories Wiring The manufacturer instructions that come with your accessory should have markings for wires or terminals to connect to the gate opener. Please look for terminals named below in the instructions for the accessory. Keypads, Receivers: Normally Open (NO) or Input (INP) or Relay of entry device = #1 ter minal on gate opener control board.
  • Page 53 Estate Swing Accessories Wiring Photo Eye, Safety Edge, Safety Loop: Normally Closed (NC) of safety device = #5 ter minal on gate opener contr ol boar d. Common (COM) or Ground (GND) of safety device = #14 ter minal on gate opener contr ol board.
