Summary of Contents for Westermo Ibex-1510 Series
- Page 1 Ibex-1510 Series EN 50155 Wi-Fi Access Point...
-
Page 2: Table Of Contents
4.5. Cooling ................18 4.6. Replacement of Product ............18 5. Specifications ................20 5.1. Interface Specifications ............20 5.2. Type Tests and Environmental Conditions ......... 22 6. Abbreviations and Terms ............... 24 7. Revision Notes ................26 Ibex-1510 Series... -
Page 3: General Information
Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Safety And Regulations
No personal injury Minor damage to the order to avoid misuse of product the product, confusion or misunderstanding NOTICE Used for highlighting general, No personal injury Minor damage to the but important information product NOTE Table 1. Warning levels Ibex-1510 Series... -
Page 5: Safety Information
Before energising and connecting communication cables to the product, ensure a protective earthing conductor is first connected to the protective earthing terminal (only valid for metallic housings). Westermo recommends a cross-sectional area of at least 4 mm Note that this product can be connected to two different power sources. - Page 6 CABLE TEMPERATURE RATING FOR FIELD TERMINAL WIRES There may be a requirement on the minimum temperature rating of the cable to be connected to the field wiring terminals, see chapter Interface Specifications. Ibex-1510 Series...
-
Page 7: Care Recommendations
If the product is not working properly, contact the place of purchase, the nearest Westermo distributor office or Westermo technical support. NOTE Devices not used shall be kept in the factory sealed moisture barrier bag. -
Page 8: Compliance Information
• ETSI EN 300 440, 5.8GHz, Short Range Devices • IEEE802.11, Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) Specifications Safety • EN/IEC 61010-1, Safety requirements for electrical equipment for measurement, control, and laboratory use • EN 45545-2, Fire protection on railway vehicles Ibex-1510 Series... -
Page 9: Simplified Declaration Of Conformity
2.5.2. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. Figure 2. The European Conformity and the UK Conformity Assessment markings... -
Page 10: Product Description
TCMS network. Figure 3. Ibex-1510 block diagram The Westermo configuration management tool, WeConfig, can be used for discovery and basic configuration and maintenance. The configuration can be done locally or remotely via SNMP or via WebGUI/API. -
Page 11: Available Models
2.5 Gigabit Ethernet port X1 (PoE) Power input DC Protective earth terminal Frontside label Warning symbol for surface temperatures above +60°C Antenna ports A1 - A2 (2.4 GHz / 5 GHz) Product family label Table 3. Location of interface ports Ibex-1510 Series... -
Page 12: Interface Ports View
Table 5. M12 A-coded 4-pin male power connector according to IEC 61076-2-101 3.4.2. Ethernet Ports The product includes two Ethernet ports X1 and X2 which supports auto-negotiated 10 Mbit/s, 100 Mbit/s, 1000 Mbit/s and 2500 Mbit/s operation. Automatic MDI/MDIX crossover is supported for 10BASE-T, 100BASE-T, 1000BASE-T and 2500BASE-T operation. Ibex-1510 Series... -
Page 13: Antenna Ports
The antenna connectors are identified on the product with A1 and A2. A1 and A2 are used for WLAN communication. At least A1 must be connected to an external WLAN antenna. The antenna configuration is made through the software interface. Ibex-1510 Series... -
Page 14: Led Indicators
Ethernet status for X1 port Ethernet status for X2 port Table 8. LED indicators NOTE The power status LED is green if both input power sources are available. The LED lights up red if only one power input source is provided. Ibex-1510 Series... -
Page 15: Dimensions
NOTE Refer to management guide for detailed LED status indication. 3.6. Dimensions Dimensions are stated in mm and are regardless of variants. 195.4 20.5 24.5 25.0 111.4 Figure 5. Dimensional drawing Ibex-1510 Series... -
Page 16: Installation
For outdoor installation, consider additional protection against sun radiation, dust and dirt to optimize ambient temperature range. NOTE Unused connectors must be covered by a protective cap (delivered with the product), tightened to the specified torque in order to fulfill the specified ingress protection code. Ibex-1510 Series... -
Page 17: Factory Reset
4.4. Connection of Cables Recommended tightening torque for the M12 connectors is 0.6 Nm. All M12 connections are screw connections. When connecting the power cable, ensure that the pins are connected correctly before tightening the power cable to the unit. Ibex-1510 Series... -
Page 18: Cooling
The operating conditions shall be ensured so that the normal operation does not cause temperature alarms. Improve installation conditions or RF parameters in case of any temperature alarms. 4.6. Replacement of Product The device cannot be repaired. In case of a malfunction, it must be replaced. Ibex-1510 Series... - Page 19 MTTR (Mean Time To Repair), i.e. time for replacement of product is: < 10 minutes. HOT SURFACE Be aware that the surface of this product may become hot. When it is operated at high temperatures, the external surface may exceed Touch Temperature Limit according to the product's relevant electrical safety standard. Ibex-1510 Series...
-
Page 20: Specifications
10 Mbit/s, 100 Mbit/s, 1000 Mbit/s, 2500 Mbit/s manual or auto Duplex Full or half, manual or auto Transmission range Up to 100 m with CAT5e cable or better Cabling Shielded cable CAT5e or better is recommended Conductive chassis Ibex-1510 Series... - Page 21 NOTICE Unused antenna port must be terminated with 50 Ohm terminations. NOTICE To avoid damages on the antenna interfaces, ensure that the far end side of the antenna cable and/or the antenna itself is connected to protective earth. Ibex-1510 Series...
-
Page 22: Type Tests And Environmental Conditions
Ethernet ports Insulation resistance EN 50155 Power port (DC) > 100 MOhm to all other ports Dielectric strength EN 50155 Power port (DC) 2200 VDC, 60 s to all other ports Table 9. EMC and electrical conditions Ibex-1510 Series... - Page 23 The power and Ethernet cables need to be fastened 200 mm or closer to the unit. The same recommendation applies to the Antenna cables. Provided all connectors are connected with IP66 cabling or fitted with protective caps (delivered with the unit) and tightened to the specified torque Table 10. Environmental and mechanical conditions Ibex-1510 Series...
-
Page 24: Abbreviations And Terms
Light Emitting Diode MIMO Multiple Input, Multiple Output MTBF Mean Time between Failure MTTR Mean Time to Repair Operation Quick Response Radio Frequency Serial Number SNMP Simple Network Management Protocol Telephone Network Voltage WebAPI Web Application Programming Interface Ibex-1510 Series... - Page 25 Abbreviation Description WebGUI Web Graphical User Interface WeConfig Westermo Configuration Tool WEEE Waste Electrical and Electronics Equipment Wi-Fi Wireless Fidelity WLAN Wireless Local Area Network Table 11. Abbreviations and terms Ibex-1510 Series...
-
Page 26: Revision Notes
7. Revision Notes Revision Date Change description Rev. A 2024-02 First revision Ibex-1510 Series... - Page 27 Westermo • Metallverksgatan 6, SE-721 30 Västerås, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com 6628-2220 REV. A 2024 02 @ Westermo Network Technologies AB, Sweden...
