- Page 1 Ibex-RT-220 Series EN 50155 WLAN 2x2 Client/Bridge/Access Point...
-
Page 2: Table Of Contents
Ibex-RT-220 Series User Guide Contents General Information ......................4 Legal Information ......................4 About This Guide ......................4 Software Tools ....................... 4 License and Copyright for Included FLOSS ................ 4 Safety and Regulations......................5 Warning Levels ....................... 5 Safety Information......................6 Care Recommendations .................... - Page 3 Ibex-RT-220 Series User Guide Westermo Network Technologies...
-
Page 4: General Information
Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 5: Safety And Regulations
Ibex-RT-220 Series User Guide 2 Safety and Regulations 2.1 Warning Levels Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially... -
Page 6: Safety Information
For Ibex products, outdoor installation is allowed. During installation, ensure a protective earthing conductor is first connected to the protective earthing terminal. Westermo recommends a cross-sectional area of at least 4 mm Upon removal of the product, ensure that the protective earthing conductor is disconnected last. - Page 7 Ibex-RT-220 Series User Guide WARNING – RADIO PRODUCTS Observe the usage limitations of radio products at filling stations, in chemical plants, in systems with explosives or potentially explosives locations. The devices may not be used in airplanes. Exercise particular caution near personal medical aids, such as pacemakers and hearing aids.
-
Page 8: Care Recommendations
If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo technical support. -
Page 9: Compliance Information
Ibex-RT-220 Series User Guide 2.5 Compliance Information REGULATORY NOTICE Any changes or modifications shall be approved by the party responsible for compliance. If not, users could void the user's authority to operate the equipment. Country code and antenna gain needs to be set properly for correct functionality in the installed country. -
Page 10: United States - Fcc
Ibex-RT-220 Series User Guide 2.5.2 United States - FCC The enclosed device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (i.) this device may not cause harmful interference and (ii.) this device must accept any interference received, including interference that may cause undesired operation. -
Page 11: Europe - Simplified Declaration Of Conformity
This product contains the IC Certification numbers 9301A-103902DT50 2.5.5 Europe - Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full EU declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. -
Page 12: Product Description
Ethernet Figure 3 Ibex-RT-220-LV / Ibex-RT-220-HV block diagram The Westermo configuration management tool, WeConfig, can be used for discovery and basic configuration and maintenance. The configuration can be done via SNMP or via WebGUI. The status information is available in local LED status indicators, and through SNMP/WebGUI. -
Page 13: Hardware Overview
Ibex-RT-220 Series User Guide 3.3 Hardware Overview 3.3.1 Front Side View Description LED indicators 100BASE-T Ethernet ports X1 and X2 Protective earth terminal Power input DC Front side label Warning symbol for surface temperatures above +60°C Antenna ports A1 and A2 Figure 4 Location of interface ports and LED indicators 3.3.2 Front Side Label... -
Page 14: Rear Side Label
Ibex-RT-220 Series User Guide Description Remarks QR code The data matrix is: AAAA-AAAARR-1-VV-SSSSSSSS-YYWW AAAA-AAAA = Article number RR = Region code VV = Product revision SSSSSSSS = Serial number YY = Manufacturing Year WW = Manufacturing Week Manufacturing date The Date Format is: YYWW... -
Page 15: Connector Information
Ibex-RT-220 Series User Guide Description Antenna 1000Base-T Grounding point Power Figure 7 View to interface ports 3.4 Connector Information 3.4.1 Power Input Connection M12 A-coded 4-pin male power connector according to IEC 61076-2-101 Marking Position Direction Description Positive terminal Negative terminal... -
Page 16: Antenna Ports
Ibex-RT-220 Series User Guide PoE connection on X2 (Ibex-RT-220-LV only) Position Device mode A Device mode B Table 6 Ethernet X2 PoE connection NOTE PoE is supported on X2 for the LV product variant only. NOTE If the Ethernet function is not used, the protective dust cap which is part of the delivery must be closed to protect the interface from water or dust ingress. -
Page 17: Factory Reset
Ibex-RT-220 Series User Guide NOTE Refer to management guide for detailed LED status indication. 3.6 Factory Reset To reset the product into factory default settings, a reset adapter is needed which is plugged into one of the Ethernet ports X1 or X2 during startup. -
Page 18: Installation
Ibex-RT-220 Series User Guide Figure 8 Dimensional drawing 4 Installation 4.1 Mounting The product is fixed with the four fixing points located at the corners of the product. M5 or M6 screws are used for the fixation of the product. The screws are tightened with min. 3.0 Nm (fixing screw ISO 898/1, quality class 8.8). -
Page 19: Earth Connection
Ibex-RT-220 Series User Guide 4.2 Earth Connection For correct function, the earth connection at the grounding point needs to be properly connected to a solid ground. An M5 grounding screw at the housing is used for grounding. A short wire with a cross section of at least 4 mm shall be used. - Page 20 Ibex-RT-220 Series User Guide Figure 10 Installation with reduced natural convection airflow Figure 11 Installation with natural convection airflow When operating the device at high ambient temperatures, it is recommended to mount the device to a metallic base plate to improve the heat dissipation. The base plate increases the surface to spread the heat.
-
Page 21: Replacement Of Product
Ibex-RT-220 Series User Guide NOTICE Limited air flow is rising the device temperature and may lower the upper limit of the operating temperature range. NOTICE Temperature is dependent on the operational parameters, like RF output power, amount of traffic. NOTICE This product has integrated temperature sensors for monitoring the internal device temperatures. -
Page 22: Specifications
Ibex-RT-220 Series User Guide 5 Specifications 5.1 Interface Specifications DC, Power port Ibex-RT-220-LV Ibex-RT-220-HV Connector M12 A-coded male Rated voltage 24 VDC 72 to 110 VDC Operating voltage 16 to 30 VDC 50 to 138 VDC Rated current 0.6 A 0.2 A... - Page 23 Ibex-RT-220 Series User Guide NOTICE To avoid damages on the Ethernet interfaces, ensure that the far end side of the Ethernet cable shield itself is connected to protective earth. Antenna WLAN (A1, A2) Connector QMA female Direction Transmit and receive...
-
Page 24: Type Tests And Environmental Conditions
Ibex-RT-220 Series User Guide 5.2 Type Tests and Environmental Conditions Environmental Basic Description Test levels phenomena standard EN 61000-4-2 Enclosure Contact: ±6 kV Air: ±8 kV Fast transients EN 61000-4-4 DC power port ± 2 kV, direct coupling Ethernet ports ±... - Page 25 Ibex-RT-220 Series User Guide Environmental Basic Description Test levels phenomena standard Temperatures EN 60068-2-1 Operational -40 to +70°C (-40 to +158°F) EN 60068-2-2 Storage and -55 to +85°C (-67 to +185°F) EN 60068-2-14 transport Humidity EN 60068-2-30 Operational 5-95% relative humidity...
-
Page 26: Abbreviations And Terms
Ibex-RT-220 Series User Guide 6 Abbreviations and Terms Abbreviation Description Amplitude Modulation AREMA American Railway Engineering and Maintenance-of-Way Association American Wire Gauge CAT5e Category 5 Enhanced Cable Conformité Européenne Central Processing Unit Direct Current Electromagnetic Compatibility European Standard Error Electro Static Discharge... -
Page 27: Revision Notes
Ibex-RT-220 Series User Guide 7 Revision Notes Revision Date Rev. B 2021-04 Product illustrations updated to blue, text in illustrations removed, Westermo address updated, chapter 2.5.5 updated Westermo Network Technologies... - Page 28 REV. B 6623-2240 2021-04 Westermo Network Technologies AB, Sweden...
