Summary of Contents for Westermo Ibex-RT-610 Series
- Page 1 Ibex-RT-610 Series EN 50155 WLAN 802.11ac Dual Concurrent Access Point...
-
Page 2: Table Of Contents
Ibex-RT-610 Series User Guide Contents General Information ........................3 Legal Information ........................3 About This Guide ........................3 Software Tools ......................... 3 License and Copyright for Included FLOSS ................3 Safety and Regulations ........................4 Warning Levels ........................4 Safety Information ........................5 Care Recommendations ...................... -
Page 3: General Information
Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Safety And Regulations
Ibex-RT-610 Series User Guide 2 Safety and Regulations 2.1 Warning Levels Warning signs are provided to prevent personal injury and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially... -
Page 5: Safety Information
For Ibex products outdoor installation is allowed. During installation, ensure a protective earthing conductor is first connected to the protective earthing terminal. Westermo recommends a cross-sectional area of at least 4 mm Upon removal of the product, ensure that the protective earthing conductor is disconnected last. - Page 6 Ibex-RT-610 Series User Guide WARNING – RADIO PRODUCTS Observe the usage limitations of radio products at filling stations, in chemical plants, in systems with explosives or potentially explosives locations. The devices may not be used in airplanes. Exercise particular caution near personal medical aids, such as pacemakers and hearing aids.
-
Page 7: Care Recommendations
If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo technical support. -
Page 8: Agency Approvals And Standards Compliance
Ibex-RT-610 Series User Guide 2.5.1 Agency Approvals and Standards Compliance Type Approval/Compliance • Climate EN 50155, class OT4, Railway applications – Electronic equipment used on rolling stock • EN 50125-3, Railway applications – Environmental conditions for equipment, Part 3: Equipment for signalling and telecommunications •... -
Page 9: United States - Fcc
Ibex-RT-610 Series User Guide 2.5.2 United States - FCC The enclosed device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (i.) this device may not cause harmful interference and (ii.) this device must accept any interference received, including interference that may cause undesired operation. -
Page 10: Europe - Simplified Declaration Of Conformity
This product contains the IC Certification numbers 7849A-WLE600VX and 7849A- WLE1216V520. 2.5.5 Europe - Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. -
Page 11: Product Description
5GHz) Figure 3 Ibex-RT-610-LV / Ibex-RT-610-HV block diagram The Westermo configuration management tool, WeConfig, can be used for discovery and basic configuration and maintenance. The configuration can be done via SNMP or via WebGUI. The status information is available in local LED status indicators, and through SNMP/WebGUI. -
Page 12: Hardware Overview
Ibex-RT-610 Series User Guide 3.3 Hardware Overview 3.3.1 Front Side View Description Description Gigabit Ethernet ports X1 and X2 Protective earth terminal Power input DC Front side label Warning symbol for surface Antenna ports A1-A4, B1-B2 temperatures above +60°C LED indicators Figure 4 Location of interface ports and LED indicators 3.3.2 Front Side Label... -
Page 13: Rear Side Label
Ibex-RT-610 Series User Guide Figure 5 Front side label content 3.3.3 Rear Side Label C O M P L I A N T Figure 6 Rear side label content 3.3.4 Interface Ports View Description Description Antennas 1000Base-T Grounding point Power Figure 7 View to interface ports 3.4 Connector Information... -
Page 14: Ethernet Ports
Ibex-RT-610 Series User Guide NOTE If device is powered by PoE, the protective dust cap which is part of the delivery must be closed to protect the power interface from water or dust ingress. 3.4.2 Ethernet Ports The product includes two Ethernet ports X1 and X2 which supports auto-negotiated 10 Mbit/s, 100 Mbit/s and 1000 Mbit/s operation. -
Page 15: Antenna Ports
Ibex-RT-610 Series User Guide 3.4.3 Antenna Ports The antenna connectors are identified on the product with A1 to A4 and B1 to B2. QMA industrial standard connector is used. A1 to A4 are used for WLAN Wave 2 communication at 5 GHz. At least A1 must be connected to an external WLAN antenna if Wave 2 module is used. -
Page 16: Factory Reset Procedure
Ibex-RT-610 Series User Guide 3.6.1 Factory Reset Procedure Step Description Plug the factory reset adapter to one of the Ethernet interfaces Power the product Wait until factory reset adapter is detected. This is indicated by solid ORANGE OPR LED and RED ERR LED... -
Page 17: Dimensions
Ibex-RT-610 Series User Guide 3.7 Dimensions Dimensions are stated in mm and are regardless variants. Figure 8 Dimensional drawing Westermo Network Technologies... -
Page 18: Installation
Ibex-RT-610 Series User Guide 4 Installation 4.1 Mounting The product is fixed with the four fixing points located at the corners of the product. M5 or M6 screws are used for the fixation of the product. The screws are tightened with min. 3.0 Nm (fixing screw ISO 898/1, quality class 8.8). -
Page 19: Connection Of Cables
Ibex-RT-610 Series User Guide Figure 9 Earth connection NOTICE Do not use equipment without protective earth connection. 4.3 Connection of Cables Recommended tightening torque for the M12 connectors is 0.6 Nm. All M12 connections are screw connections. When connecting the power cable, ensure that the pins are connected correctly before tightening the power cable to the unit. - Page 20 Ibex-RT-610 Series User Guide Figure 10 Installation with natural convection airflow When operating the device at high ambient temperatures, it is recommended to mount the device to a metallic base plate to improve the heat dissipation. The base plate increases the surface to spread the heat.
-
Page 21: Replacement Of Product
Ibex-RT-610 Series User Guide NOTICE Limited air flow is rising the device temperature and may lower the upper limit of the operating temperature range. NOTICE Temperature is dependent on the operational parameters, like RF output power, amount of traffic. NOTICE This product has integrated temperature sensors for monitoring the internal device temperatures. -
Page 22: Specifications
Ibex-RT-610 Series User Guide 5 Specifications 5.1 Interface Specifications DC, Power port Ibex-RT-610-LV Ibex-RT-610-HV Connector M12 A-coded male Rated voltage 24 VDC, Class III 72 to 110 VDC, Class I Operating voltage 16 to 30 VDC 50 to 138 VDC Rated current 0.6 A... - Page 23 Ibex-RT-610 Series User Guide NOTICE To avoid damages on the Ethernet interfaces, ensure that the far end side of the Ethernet cable shield itself is connected to protective earth. Antenna WLAN (A1..A4, B1..B2) Connector QMA female Direction Transmit and receive...
-
Page 24: Type Tests And Environmental Conditions
Ibex-RT-610 Series User Guide 5.2 Type Tests and Environmental Conditions Environmental Basic Description Test levels phenomena standard EN 61000-4-2 Enclosure Contact: ±6 kV Air: ±8 kV Fast transients EN 61000-4-4 DC power port ± 4 kV, direct coupling Ethernet ports ±... - Page 25 Ibex-RT-610 Series User Guide Environmental Basic Description Test levels phenomena standard Temperatures EN 60068-2-1 Operational -40 to +70°C (-40 to +158°F) EN 60068-2-2 Storage and -55 to +85°C (-67 to +185°F) EN 60068-2-14 transport Humidity EN 60068-2-30 Operational 5-95% relative humidity...
-
Page 26: Abbreviations And Terms
Ibex-RT-610 Series User Guide 6 Abbreviations and Terms Abbreviation Description Amplitude Modulation AREMA American Railway Engineering and Maintenance-of-Way Association American Wire Gauge BPSK Binary Phase Shift Keying CAT5e Category 5 Enhanced Cable Conformité Européenne Central Processing Unit Direct Current Electromagnetic Compatibility... -
Page 27: Revision Notes
Ibex-RT-610 Series User Guide 7 Revision Notes Revision Date Rev. C 2021-05 2.5.5 Europe – Simplified Declaration of Conformity updated text and figure, 4.2 Earth connection updated, Figures 4, 7, 8 and 9 updated Rev. B 2020-10 Updated illustrations Rev. A... - Page 28 REV. C 6623-2290 2021-05 Westermo Network Technologies AB, Sweden...
