SKY-MXM-A500
MXM 3.1 Type A NVIDIA
Startup Manual

Packing List

Before you begin installing your card, please make sure that
the following items have been shipped:
1. SKY-MXM-A500 GPU card x 1
2. China RoHS Doc x 1
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: www.
adobe.com/Products/acrobat/readstep2.html
(Acrobat is a trademark of Adobe).

Standard Functions

Processor System
• GPU: NVIDIA
Quadro
®
• Graphics architecture: NVIDIA
• CUDA parallel-processing cores: 2048 CUDA
• GPU base/boost clock: 652 MHz / 1597 MHz
• FP32 performance: 6.54 TFLOPS
• Bus: MXM3.1, PCI Express Gen3 x4 support
• Max power consumption: 35W
Memory
• Technology: GDDR6 4GB memory
• Interface width: 64-bit
• Bandwidth: 112 GB/s
Physical
• Dimensions: 82 (W) x 70 (D) mm
• Form factor: MXM 3.1 Type A

Environment

• Operating: 0 ~ 55 °C
(Depending on CPU and cooler solution)
• Non-operating: -40 °C ~ 85 °C
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the SKY-MXM-A500 series Rev. A1.
Part No. 2041A50000
Printed in China
A500
®
Ampere™ GA107-910
®
1st Edition
March 2023
Quadro
®
®
Standard Functions (Cont.)

Operating Systems

• Microsoft: Windows 10/11, 64-bit
• Linux: Linux Drivers, 64 bit
• Software support:
- CUDA toolkit 8.0 and higher
- CUDA compute version 6.1 and higher
- OpenCL™ 1.2
- DirectX
- OpenGL 4.5
- Vulcan 1.0
• Display port: Headless design, no display function

Graphics Options

The SKY-MXM-A500 has a headless design without a
display function.

GPU Thermal Policy

cores
®
The GPU Core Clock throttles at temperatures (Tj) higher
than those listed in the below table, which lists the throttling
temperatures and behavior. Thermal throttling is necessary
to ensure that the hottest temperature on the die does not
exceed the threshold temperature for prolonged periods of
time.
Parameter
Thermal Resistance (Junc-
tion to Case, RJC)
Thermal Resistance (Junc-
tion to PCB Board, RJB)
GPU Shutdown Tempera-
ture (OVERT)*
GPU Slowdown Tempera-
ture (THERM_ALERT)**
GPU Maximum Operating
Temperature***
GPU Target Temperature
Notes:
*OVERT assertion results in an 87.5% (÷8) hardware clock
slowdown.
**THERM_ALERT assertion results in a 50% (÷2) hardware
clock slowdown.
***The GPU maximum operating temperature is the maxi-
mum GPU temperature at which the GPU is guaranteed to
operate at the target performance (Base Clock) under the
total board power level.
Embedded A500
12
®
SKY-MXM-A500
0.042
2.38
100
98
89
87
SKY-MXM-A500 Startup Manual 1
Units
°C/W
°C/W
°C
°C
°C
°C
