Summary of Contents for Advantech SKY-MXM-2000A
- Page 1 User Manual SKY-MXM-2000A ® MXM 3.1 Type A NVIDIA ® Quadro Embedded 2000 Ada with DP 1.4a...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
- Page 3 Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
- Page 4 It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the SKY-MXM-2000A, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.
-
Page 5: Table Of Contents
Graphics Options ................3 1.3.7 Physical..................3 1.3.8 Environment................. 3 Block Diagram................... 4 Board Dimensions..................4 SKY-MXM-2000A Connector Pin Definition ..........5 Safety Precautions ..................6 Chapter System Requirements......7 Power Sequencing ..................8 Figure 2.1 Power Sequencing ............. 8 Table 2.1: Signals Exempted from ..........8 Input Voltage Requirements.............. - Page 6 SKY-MXM-2000A User Manual...
-
Page 7: Chapter 1 Hardware Configuration
Chapter Hardware Configuration... -
Page 8: Introduction
Introduction As an NVIDIA Elite Partner, Advantech provides MXM GPU cards featuring NVIDIA's embedded GPUs, tailored for image processing and Edge AI acceleration in manu- facturing, medical, and gaming sectors. Based on NVIDIA's latest architectures, Advantech MXM GPUs offer cutting-edge technologies, ensuring high-performance computing and responsive capabilities while minimizing latency. -
Page 9: Display Support And Options
Shader Model 8.9 OpenCL™ 3.0 OpenGL 4.6 Vulkan 1.3 1.3.6 Graphics Options The SKY-MXM-2000A supports 3 x DP 1.4a, with display options port as shown below. MXM Port DP_A DP_B DP_C Advantech Link A Link B Link C... -
Page 10: Block Diagram
IFPA DP_A: Display Port NVIDIA IFPB DP_B: Display Port Quadro RTX 2000 Ada IFPC DP_C: Display Port (reserved) IFPD DP_D: Display Port Board Dimensions Unit: mm 82.00 3.50 46.00 23.00 23.50 2.05 ±0.15 12.52 3.00 29.00 1.20 SKY-MXM-2000A User Manual... -
Page 11: Sky-Mxm-2000A Connector Pin Definition
SKY-MXM-2000A Connector Pin Definition Pin Signal Name Signal Name Signal Name Signal Name PWR_SRC PWR_SRC PEX_RX1# PEX_TX1# PEX_RX1 PEX_TX1 PRSNT_R# RSVD PEX_RX0# PEX_TX0# PWR_GOOD PEX_RX0 PEX_TX0 PWR_EN PEX_REF- RSVD PEX_CLK_REQ# CLK# PEX_REFCLK 156 PEX_RST# RSVD RSVD RSVD RSVD RSVD RSVD... -
Page 12: Safety Precautions
MXM GPU card. Modern electronic devices are very sensitive to static electric discharges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components on a static-dissipative sur- face or in a static-shielded bag when they are not in the chassis. SKY-MXM-2000A User Manual... -
Page 13: Chapter 2 System Requirements
Chapter System Requirements... -
Page 14: Power Sequencing
Input voltage to the GPU must strictly follow the ranges listed in the below table (ref- erence to GND). Operating outside the required voltage range will cause permanent damage to the Table 2.2: Input Voltage Requirements Power Rail Min. Typ. Max. PWR_SRC 6.5V 7-20V 4.7V 5.3V 3.1V 3.3V 3.5V SKY-MXM-2000A User Manual... -
Page 15: Module Power Down And Power Up
Figure 2.3 Reset Sequencing Note! In order to reduce boot time, a system that monitors the PWR_GOOD signal, is allowed to violate the TPVPERL specification as long as the TPERST-PG timing is still met. SKY-MXM-2000A User Manual... -
Page 16: Dual-Mode Displayport Configuration
100 kΩ pull-downs on both AUX_N and AUX_P placed near the GPU A DP-AUX device used to short-out the capacitor and level shift when a DP to HDMI dongle is detected. Figure 2.4 AUX in Dual Mode SKY-MXM-2000A User Manual... -
Page 17: Hdmi On Dp Interface
PCB design to meet the display validation criteria and/or EMI compliance. The DDC output requires a level shifter circuit because the IFPx_AUX lines are not 3.3 V tolerant. SKY-MXM-2000A User Manual... -
Page 18: Mechanical And Environmental Specifications
PCB strain of 500 μstrains or below. – The strain rate is too high (5000 μstrains/second) during the PCA operations. For PCB thickness less than 1,0mm, the max. allowable strain shall follow IPC 9704. SKY-MXM-2000A User Manual... -
Page 19: Gpu Thermal Policy
(Base Clock) under the total board power level. System BIOS Requirements Before you install the MXM module, please make sure your system BIOS is config- ured with the following settings: CSM Support [Disabled] Above 4G Decoding [Enabled] SKY-MXM-2000A User Manual... - Page 20 Note! Option names may vary depending on system architecture. SKY-MXM-2000A User Manual...
- Page 21 SKY-MXM-2000A User Manual...
- Page 22 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...
