- Page 1 CLASSIC MGT550 ® Marine Cuber Installation and Operation Instructions Ice Machine Products A Tradition of Excellence In Ice Equipment.
- Page 2 INSTALLATION AND OPERATION INSTRUCTIONS FOR MARINE CLASSIC MGT550 SERIES ICE CUBERS KOLD-DRAFT ® ® CHECK FOR FREIGHT DAMAGE BEFORE PROCEEDING: Even though damage to the carton may not have been evident, check for hidden damage and contact freight carrier immediately if necessary to file a claim.
- Page 3 2. Level the bin with adjusters on legs, or by shimming if the bin is to be sealed to the floor. If gaps due to shims are greater than 1/8 inch, install a cove molding around the bin bottom. Seal the bin or molding to the floor with NSF Certified RTV sealant (Dow-Corning RTV 732 or equal).
- Page 4 8. Install the drain pan. Route the drain tube assembly through the rear of the cuber, and clamp the tubing to the drain pan nipple. 9. Route the bin thermostat capillary tube down the right front corner of the frame, along the front rail, under the right side drain pan flange, through the bulb tube holder and down into the bin.
- Page 5 INSTALLATION SPECIFICATIONS FUSE / HACR MINIMUM BREAKER SIZE WATER ICE MAKER CONDENSER ELECTRICAL CIRCUIT (AMPS) INLET SIZE DRAIN SIZE COOLANT (FPT) MODEL SUPPLY AMPACITY NORMAL MAXIMUM (FPT) (ID) SUPPLY DISCHARGE MGT551W 115/60/1 17.9 MGT554W 208-230/60/1 14.3 READ THE FOLLOWING NOTES CAREFULLY PRIOR TO MAKING CONNECTIONS CAUTION: RISK OF PROPERTY DAMAGE, EQUIPMENT FAILURE, OR FIRE.
- Page 6 Liquid condenser coolant pressure drop: Condenser coolant pressure drop may reach 20 psig during peak load with 85°F. coolant temperature at recommended refrigerant high-side pressure. The condenser coolant (water) regulating valve may require adjustment due to variations in the coolant supply characteristics to provide optimum efficiency.
-
Page 7: Start-Up Instructions
PARAMETER MODEL NUMBER GT55X C/HK Water fill level (Top of tank to level in control tube) 3 5/8" 2 3/4" Approximate cycle time, min. 15.5 31/24 7.7/7.1 Approximate harvest weight, lb. Refrigerant Charge, Oz. (R-404a) Liq. cooled: START-UP INSTRUCTIONS WATER LEVELS, CYCLE TIMES, AND REFRIGERANT CHARGES * Values are for Air-cooled model at 90°F. - Page 8 5. Be sure that pump hoses are connected, then put about one pint of clean tap water into the circulation system to lubricate the pump seal. 6. Move the "ICE-OFF-WASH" switch to the right "WASH" position and observe the water fill cycle and the pump running. If all water distributor holes do not produce full streams and the appearance of air is evident in the tube, pinch the plastic tube connected to the water solenoid valve outlet while water is running until the streams are full all the way across the distributor tube.
- Page 9 Clean up splashes or spillage immediately. Follow these instructions exactly. Ice Cuber Cleaning Instructions 1. Mix 1 bag of KOLD-DRAFT ice machine cleaner (55R-01000) in two (2) quarts of clean, warm water (180°F. MAX.) for each evaporator/water plate assembly to be cleaned.
- Page 10 10. While the cleaning and sanitizing solutions are circulating, clean, rinse, and sanitize all accessible parts of the ice-making compartment of the cuber with clean cloths. Use a cleaning solution of 8 tablespoons (1/2 cup) baking soda per gallon of warm water, and a sanitizing solution of no less than 1 teaspoonful (5 ml) 5-1/4% sodium hypochlorite per quart of clean water.
