DL8) right trolley displacement output led: this led lights up when the printed circuit card feeds the
remote control reverser coil (N.5) for trolley displacement to right;
left trolley displacement output led: this led lights up when the printed circuit card feeds the
DL9)
remote control reverser coil (N.5) for trolley displacement to left;
DL10) cutting electro-valve output led: its lighting up indicates the feeding of the electro-valve coil
(N.26);
DL11) cutting stroke-end positioning electro-valve output led: this led has to light up when the printed
circuit card feeds the cutting stroke-end positioning electro-valve coil (N. 25) with the selector (N.14) on
ADJUSTMENT position;
DL12) cutting stroke-end signal led: this led has to light up when the striking plate reaches the stroke-end
position;
DL13) ADJUSTMENT-AUTOMATIC switch led: this led lights up when the selector (N.14) is on
ADJUSTMENT position.

5.3 AL 81-82 Wiring diagram nomenclature

No. Code
1 02002287
2 02002448
02002449
3 02001346
02001347
02001348
02001349
02001350
02001351
4 02001357
5 02001385
6 02002287
7 02002448
02002449
8 02001346
02001347
02001348
02001349
02001350
02001351
9 01010162
10 02001341
11 02001341
12 02001423
13 02001423
Use and maintenance manual
Part description
Remote control reverser for material feeding in/back motor
1/1.6A - 380/440V thermal relay for material feeding in/back motor
(optional)
1.6/2.5A - 220/240V thermal relay for material feeding in/back motor
(optional)
220/380V 50Hz material feeding in/back motor
260/450V 50Hz material feeding in/back motor
240/420V 50Hz material feeding in/back motor
220/380V 60Hz material feeding in/back motor
250/440V 60Hz material feeding in/back motor
320/550V 60Hz material feeding in/back motor
Foot treadle for material feeding in
Feeder plug
Remote control reverser for rolls opening/closing motor
1/1.6A - 380/440V thermal relay for rolls opening/closing motor (optional)
1.6/2.5A - 220/240V thermal relay for rolls opening/closing motor (optional)
220/380V 50Hz rolls opening/closing motor
260/450V 50Hz rolls opening/closing motor
240/420V 50Hz rolls opening/closing motor
220/380V 60Hz rolls opening/closing motor
250/440V 60Hz rolls opening/closing motor
320/550V 60Hz rolls opening/closing motor
Feeder tap
Rolls opening stroke-end micro-interrupter
Rolls closing stroke-end micro-interrupter
Rolls opening/closing swicth
Rolls opening/closing swicth
pag. 39
