4.2 Control pannel

The control panel, located on the left side of the machine, includes other electric controls:
Fig. 2
(A) main switch
(C) switch for feeding in and moving back the material (■)
(D)
potentiometer for travelling head return displacement
(E) lamp switch
(F) cut-counter switch (○)
(Q)cut-counter device (optional)
(T) potentiometer for striking plate ascent waiting time
(U) selector for feeding rolls opening and closing (■)
only for machine equipped with feeder
■=
only for machine equipped with cut-counter
○=
