5 Diagrams and nomenclature

5.1 HSP 588 Wiring diagram nomenclature

No. Code
1 02000658
2 02E01551
3 02001907
4 02003100
5A 02E04530
5A
5B 02E04530
5B
6 02003102
7 02E05143
7 02E05495
8 02000280
9 02001422
10 02001422
11 02001420
12
13
14 02001420
15 02000310
16 02002346
17 02002346
18 02000313
19 02003958
20 02004328
21 02003568
22 02002304
23 02000313
24 02000313
25 02004136
26 02004138
28 02001421
29
34 02E03889
02E03888
35 02E03880
02E03911
02E03912
60 02000658
61 02000658
J1 02E01734
J2 02009105
J3 02009105
J4 02009107
(■) = by request
Use and maintenance manual
Components description
110V secondary circuit (2A) fuse
30V secondary (6.3A) fuse
24V secondary (4A) fuse
Printed circuit card
24V AC/DC 1NO/NC relay-movement 1
24V AC/DC 1NO/NC relay-movement 2
Transformer (140VA)
Inverter moving cart (VF-S15 4015 400V-1,5kW-TOSHIBA)
Inverter moving cart (VF-S15 2015 220V-1,5kW-TOSHIBA)
Main switch
Striking plate ascent waiting time potentiometer
Travelling head return potentiometer
Lamp switch
AUTOMATIC / ADJUSTMENT selector
Cutting pushbuttons micro-interrupter s
Push-button for travelling head displacement from right to left
Push-button for travelling head displacement from left to right
Cutting stroke-end micro-interrupter
220/380V 50Hz pump motor
Three-phase motor 1HP 1400 RPM with splined shaft and servo fun
Travelling head motor fan (24V AC)
Lamp
Travelling head left stroke-end micro-interrupter
Travelling head right stroke end micro-interrupter
Cutting stroke-end positioning electro-valve coil
Cutting electro-valve coil
Cut-counting device switch (■)
Cut-counting device (■)
380/415V travelling
220/240V travelling head motor thermal relay (■)
550V pump motor thermal rely (■)
380/415V pump motor thermal rely (■)
220/240V pump motor thermal rely (■)
Transformer 2A primary circuit fuse
Transformer 2A primary circuit fuse
10 pins card connector
5 pins card connector
4 pins card connector
8 pins card connector
head motor thermal relay (■)
