3.2 Troubleshooting

1) TROUBLE: Actuating the control pushbuttons (I+L2 or O+L1)) of the machine the travelling head
does not to move:
a) check if the stroke-end adjusting handwheel (code 02001743, table. 6) has loosened: in such a case
repeat the stroke-end adjustment; check, furthermore, the stroke-end micro-interrupter efficiency (code
02000313, table. 6);
b) check the micro-interrupter s of the travelling head displacement pushbuttons (code 02002346,
table. 6);
c) check inside the electrical equipment, the travelling head motor remote control reverse (code
02E03865, table. 12);
d) check the 4A fuse of the 24V secondary (code 02001907, table. 12);
e) replace the printed circuit card (code 02003100, table. 12).
2) TROUBLE: Actuating simultaneously the cutting pushbuttons the machine does not cut:
a) check if the stroke-end adjusting handwheel (code 02001743, table. 6) has loosened: in such a case
repeat the stroke-end adjustment;
b) check the micro-interrupter s of the cutting pushbuttons (code 02000310, table. 6);
c) check the 4A fuse (code 02001907, table. 12);
d) check the cutting electro-valve (code 02003048, table. 9);
f) check the correct functioning of the pump (for 50 Hz motor: code 02003066; for 60 Hz motor: code
02003083, table. 8).
Use and maintenance manual pag. 21
