Summary of Contents for Congatec conga-SMX8-Plus
- Page 1 Sample Distribution Set for congatec SMARC 2.1 Development Quick Start Guide Revision 1.0 Copyright © 2021 congatec GmbH SX8P_SDS_q10 Arrow.com. Downloaded from...
- Page 2 In no event shall congatec GmbH be liable for any This quick start guide provides information about the contents of the incidental, consequential, special, or exemplary damages, whether based conga-SMX8-Plus sample distribution set and how to set it up.
- Page 3 GmbH, our products, or our website. congatec GmbH shall in no event be liable to the end user for collateral or consequential damages of any kind. congatec shall not otherwise be liable Certification for loss, damage or expense directly or indirectly arising from the use of the product or from any other cause.
- Page 4 The pinout description lists which signals of the NXP i.MX 8M Plus Quad processor are routed to the SMARC connector. Sample Distribution Set Use the link below to directly download the conga-SMX8-Plus pinout as an Excel file: The following items are included in the sample distribution set: https://git.congatec.com/arm-nxp/imx8-family/doc/cgtimx8_pinlist/-/raw/...
- Page 5 2. HDMI is the default video output. LVDS output currently requires device tree updates and recompilation. 3. Refer to section 2.1 "Building the Image" to build the image first. 4. To enable serial downloader mode, set jumper X45 to position 2-3. Copyright © 2021 congatec GmbH SX8P_SDS_q10 Arrow.com. Downloaded from...
- Page 6 Software Boot Process The conga-SMX8-Plus boot process starts at Power On Reset (POR), where the hardware reset logic forces the ARM core to begin execution. The Building the Image on-chip boot ROM loads the bootloader. To build the Linux operating system image for the conga-SMX8-Plus, follow...
- Page 7 Defines the startup command of the bootloader, i.e. how the system performs the boot process. speed up the boot process significantly, install the root filesystem onto the onboard eMMC device. In case of questions, contact congatec technical fdt_file "imx8mp-cgtsx8p.dtb" The device tree blob, might be exchanged in order to enhance functionality.
