Congatec conga-JC370 User Manual

Juke sbc, 8th generation intel core i7, i5, i3 and celeron single chip ultra low tdp u-series soc
Table of Contents

Advertisement

Quick Links

conga-JC370 Juke SBC
8th Generation Intel Core i7, i5, i3 and Celeron Single Chip Ultra Low TDP U-Series SoC
User's Guide
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the conga-JC370 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Congatec conga-JC370

  • Page 1 Juke SBC 8th Generation Intel Core i7, i5, i3 and Celeron Single Chip Ultra Low TDP U-Series SoC User's Guide Revision 1.0...
  • Page 2 Corrected the signal name of pins 69 and 71 in section 5.2.4 “M.2 Key M Socket” • Updated table 8 “Power Consumption Values” • Added BIOS MLF information to 7 “BIOS Setup Description” • Deleted section 8 “Industry Specifications” • Official release Copyright © 2019 congatec AG JCWLm10 2/55...
  • Page 3 In no event shall congatec AG be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in connection with this user’s guide or any other information...
  • Page 4 Copyright © 2019, congatec AG. All rights reserved. All text, pictures and graphics are protected by copyrights. No copying is permitted without written permission from congatec AG. congatec AG has made every attempt to ensure that the information in this document is accurate yet the information contained within is supplied “as-is”.
  • Page 5 (c) arising from course of performance, course of dealing, or usage of trade. congatec AG shall in no event be liable to the end user for collateral or consequential damages of any kind. congatec shall not otherwise be liable for loss, damage or expense directly or indirectly arising from the use of the product or from any other cause.
  • Page 6 Technical Support congatec AG technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and implemented. We request that you first visit our website at www.congatec.com for the latest documentation, utilities and drivers, which have been made available to assist you.
  • Page 7: Table Of Contents

    Case-open Intrusion Connector ..........49 5.2.1 Mini Card Socket ..............26 External BIOS Flash ..............49 5.2.2 M.2 Key B Socket ..............27 congatec Board Controller (cBC) ..........50 5.2.3 M.2 Key E Socket ..............29 6.4.1 Fan Control ................50 5.2.4 M.2 Key M Socket ..............
  • Page 8 BIOS Versions................54 6.5.5 OEM DXE Driver ..............51 Updating the BIOS ..............55 congatec Battery Management Interface ........ 52 Supported Flash Devices ............55 API Support (CGOS) ..............52 Thermal and Voltage Monitoring ..........52 Copyright © 2019 congatec AG...
  • Page 9 List of Tables Table 1 conga-JC370 Variants .............. 11 Table 37 X3 Pinout Description .............. 49 Table 2 Cooling ..................11 Table 38 X37 Pinout Description ............49 Table 3 Cables ..................12 Table 4 Adapters .................. 12 Table 5 Power Supply ................
  • Page 10: Introduction

    The conga-JC370 is a Single Board Computer with 3.5” form factor. The conga-JC370 features the 8th Generation Intel Core UE-Series processors. With 15 W base TDP, the SBC offers Ultra Low Power boards with high computing performance and outstanding graphics.
  • Page 11: Options Information

    1.2.1 Options Information The conga-JC370 is currently available in four variants. The table below show the different configurations available. Table 1 conga-JC370 Variants Part-No. 054001 054002 054003 054005 Processor Intel ® Core™ i7-8665UE Intel ® Core™ i5-8365UE Intel ® Core™ i3-8145UE Intel ®...
  • Page 12: Table 3 Cables

    Power supply (90 W, 19 V @ 4.74 A) 10000146 FSP090-DIEBN2, Plug 7.4 x 5.1 x 12.5 mm Power cable adapter 14000266 7.4 x 5 mm female connector to MiniFIT 2 x 2 connector Copyright © 2019 congatec AG JCWLm10 12/55...
  • Page 13: Specification

    Core™ i7,i5, i3 and Celeron Single Chip Ultra Low TDP Processors ® Memory Two memory sockets (located on the top side of the conga-JC370). Supports SO-DIMM non-ECC DDR4 modules Data rates up to 2400 MT/s Maximum 64 GB capacity (32 GB each)
  • Page 14: Supported Operating Systems

    Other Features Thermal and voltage monitoring CMOS Battery congatec standard BIOS (also possible to boot from an external BIOS flash) BIOS AMI Aptio V UEFI 2.6 firmware ® 32 MB serial SPI flash with congatec Embedded BIOS features Power ACPI 4.0 compliant with battery support. Also supports Suspend to RAM (S3) and Intel AMT 11.
  • Page 15: Supply Voltage Power

    SBC is powered by 12 V SBC is powered by 12 V Note 1. The fan and SATA drives were powered externally. 2. All other peripherals except the LCD monitor were disconnected before measurement. Copyright © 2019 congatec AG JCWLm10 15/55...
  • Page 16: Supply Voltage Battery Power

    Table 8 Power Consumption Values The table below provides additional information about the conga-JC370 power consumption. The values are recorded at various operating mode. Part Memory BIOS OS (64 bit) Current (Amp.) Size Rev. Rev. Variant Cores Freq. /Max. Turbo S0: Min S0: Max S0: Peak S3...
  • Page 17: Environmental Specifications

    Operation: 0° to 60°C Storage: -20° to +70°C Humidity Operation: 10% to 90% Storage: 5% to 95% Note The above operating temperatures must be strictly adhered to at all times. Humidity specifications are for non-condensing conditions. Copyright © 2019 congatec AG JCWLm10 17/55...
  • Page 18: Block Diagram

    PECI MNGMT LPC UART RS232/422/485 2x RS232 congatec Legend CAN Controller Board Optional Controller GPIO 0-7 Generation MNGMT/GPIO 8-15 External I/O Internal I/O Front Panel SMB/I2C FAN 4-Pin RTC Battery Socket DC-In 12-24V Copyright © 2019 congatec AG JCWLm10 18/55...
  • Page 19: Cooling Solution

    Cooling Solution The conga-JC370 supports the cooling solutions listed in the table below. The dimensions of the cooling solutions are shown in the sub-sections. All measurements are in millimeters. Table 10 Cooling Solution Variants Cooling Solution Part No. Description 054050 Active cooling solution with integrated heat pipes and 2.7 mm bore-hole standoffs...
  • Page 20: Csa Dimensions

    CSA Dimensions 133.9 27.3 32.35 67.6 M2.5 x 8 mm threaded standoff for threaded version ø2.7 x 8 mm 0.05 non-threaded standoff for borehole version Copyright © 2019 congatec AG JCWLm10 20/55...
  • Page 21: Csp Dimensions

    CSP Dimensions 133.9 26.3 67.6 32.35 M2.5 x 8 mm threaded standoff for threaded version ø2.7 x 8 mm 0.05 non-threaded standoff for borehole version Copyright © 2019 congatec AG JCWLm10 21/55...
  • Page 22: Hsp Dimensions

    HSP Dimensions 133.9 32.35 67.6 M2.5 x 8 mm threaded standoff for threaded version ø2.7 x 8 mm non-threaded standoff for borehole version Copyright © 2019 congatec AG JCWLm10 22/55...
  • Page 23: Connector Description

    Connector Description Power Supply Connectors The conga-JC370 provides a 4-pin Mini-Fit connector. The power input is protected by a 15 A non-resettable fuse. Alternatively, the conga- JC370 can be powered by USB Type-C. Note The conga-JC370 turns on immediately power is supplied. To change this default setting, enter the BIOS setup menu under “Boot Settings Configuration”...
  • Page 24: Usb Type-C Port

    Power Status LEDs The LED D57 shows the power state of the conga-JC370 as described in the table below. Optionally, you can connect an LED to pins 9 and 10 of connector X4 for power state indication (see section 5.12 “Front Panel Header”).
  • Page 25: Cmos Battery Header

    5.1.5 CMOS Battery Header The conga-JC370 provides a CR2032 CMOS battery which is connected to pin header X36. The battery supplies power to maintain the CMOS settings and real time clock. Battery Table 14 X36 Pin Header Pin Description RTC power (+3V)
  • Page 26: Extension Sockets

    • M.2 key M, type 2280 (PCIe x4/SATA/Intel Optane ® ™ 5.2.1 Mini Card Socket The conga-JC370 provides a Mini Card socket (X26). The socket supports full or half size PCIe, SATA or USB 2.0 cards. Table 15 X26 Pinout Description Signal Signal WAKE# +3.3 V...
  • Page 27: M.2 Key B Socket

    X26: Standard Mini Card socket (full size or half size) 5.2.2 M.2 Key B Socket The conga-JC370 provides an M.2 key B, type 2242/3042 socket (X24) for connecting a PCIe or USB (WWAN) card. Table 16 X24 Pinout Description Pin Signal Pin Signal +3.3V...
  • Page 28 REFCLK+ COEX3 COEX2 COEX1 RESET# +3.3 V +3.3 V +3.3 V Note The micro-SIM card slot is connected to the UIM interface by default. Connector Type X24: Standard PCIe M.2 key B socket Copyright © 2019 congatec AG JCWLm10 28/55...
  • Page 29: M.2 Key E Socket

    5.2.3 M.2 Key E Socket The conga-JC370 provides an M.2 key E, type 2230 socket (X27) for connecting a PCIe, USB or Intel CNVi WLAN card. ® Table 17 X27 Pinout Description Pin Signal Pin Signal +3.3 V USB_D+ +3.3 V...
  • Page 30: M.2 Key M Socket

    Connector Type X27: Standard PCIe M.2 key E socket 5.2.4 M.2 Key M Socket The conga-JC370 provides an M.2 key M, type 2280 socket (X28) for connecting a PCIe x4 SSD (NVMe), SATA SSD or Intel ® Optane ™ Table 18...
  • Page 31 Pin Signal Pin Signal PET2+ PER1- PER1+ PET1- PET1+ SATA_DEVSLP PER0-/SATA_B+ PER0+/SATA_B- PET0-/SATA_A- PET0+/SATA_A+ PERST# CLKREQ# REFCLK- REFCLK+ PEDET +3.3 V +3.3 V +3.3 V Connector Type X28: Standard PCIe M.2 key M socket Copyright © 2019 congatec AG JCWLm10 31/55...
  • Page 32: Pci Express Routing

    X26—mini PCIe (PCIe x1) PCIe Lane 12 or SATA 1 USB 2.0 Signals X28—M.2 key M (PCIe x4 ) PCIe Lane 13 PCIe Lane 14 PCIe Lane 15 PCIe Lane 16 or SATA 2 Copyright © 2019 congatec AG JCWLm10 32/55...
  • Page 33: Display Interfaces

    • audio formats such as AC-3 Dolby Digital, Dolby Digital Plus, DTS-HD, LPCM, Dolby TrueHD, DTS-HD Master audio • HDMI and DVI with appropriate adapter Note The conga-JC370 supports resolutions up to 4k only if you populate both memory sockets with modules of same size and speed. Connector Type X17: Standard DisplayPort connector 5.3.2...
  • Page 34: Lvds/Edp Header

    5.3.3 LVDS/eDP Header The conga-JC370 provides an LVDS interface on connector X15 . The interface is located on the top side of the SBC and supports the following: • 18 or 24 bit, single or dual channel • selectable panel voltage •...
  • Page 35: Panel Voltage Selection Jumper

    X15: 40-pin, 1 mm pitch header (JST BM40B-SRDS-G-TF) Possible Mating Connector: JST SHDR-40V-S-B 5.3.3.1 Panel Voltage Selection Jumper The conga-JC370 supports 3.3 V, 5 V and 12 V LCD panels. Use jumper JP1 to set the panel voltage. Table 20 JP1 Pinout Description Jumper...
  • Page 36: Backlight Control Voltage Selection Jumper

    5.3.3.2 Backlight Control Voltage Selection Jumper The conga-JC370 supports LCD backlight control signals with 3.3 V or 5 V. Use jumper JP3 to select the voltage level. Table 21 JP3 Pinout Description Pin 2 Jumper Backlight Control Voltage 5 V (default) Open 3.3 V...
  • Page 37: Usb Connectors

    The conga-JC370 provides two USB 3.1 Gen. 2 Type-A ports, two USB 2.0 ports and one USB Type-C port. 5.4.1 USB 3.1 Gen. 2 Port The conga-JC370 provides two USB 3.1 Gen. 2 ports on connector X20. Each port supports a maximum current of 1 A. Port 2 Port 1 Connector Type X20: Dual-stacked USB 3.0 type A connector...
  • Page 38: Usb Type-C Port

    5.4.3 USB Type-C Port The conga-JC370 provides one USB Type-C port on connector X19. The port supports USB 3.1 Gen. 2, DisplayPort 1.2 and power delivery up to 5 V @ 3 A. Connector Type X19: USB Type-C connector SATA Connectors The conga-JC370 provides a standard SATA 3.0 port, an mSATA/mPCIe socket, an M.2 key M socket and a SATA power header.
  • Page 39: Msata Socket

    X28 pinout description. 5.5.4 SATA Power Header The conga-JC370 provides a 2-pin SATA power header (X30) for 2.5” HDD or SSD. The header supplies 5 V with a maximum current of 1.5 A. Table 24 X30 Pinout Description. Pin Signal 5 V (maximum 1.5 A)
  • Page 40: Ethernet

    Ethernet The conga-JC370 provides two Gigabit Ethernet ports (X22 and X23). X22 interface is equipped with Intel i219-LM controller on i7 and i5 variants and with Intel i219-V controller on i3 and Celeron variants. X23 interface is equipped with Intel i255-LM controller by default but can be equipped with Intel i225-V by assembly option.
  • Page 41: Table 27 X32 Pinout Description

    Analog microphone input - right channel Connector Type X31: 9-pin, 1.25 mm pitch picoblade header (Molex 0532610971) X32: 8-pin, 1.25 mm pitch picoblade header (Molex 0533980871) Possible Mating Connector: Molex 0510210900 for X31 and Molex 0510210800 for X32 Copyright © 2019 congatec AG JCWLm10 41/55...
  • Page 42: Com Port Headers

    COM Port 1 and 2 Connectors The conga-JC370 provides COM port 1 on D-SUB9 connector X10 and COM port 2 on pin header X11. The ports support RS232, RS422 and RS485 I/O voltage levels. Select the COM port protocol in the BIOS setup menu.
  • Page 43: Com Port 3 And 4 Headers

    X11: 9-pin, 1.25 mm pitch picoblade header (Molex 0533980971) Possible Mating Connector: Molex 0510210900 5.8.2 COM Port 3 and 4 Headers The conga-JC370 provides COM port 3 on X12 and COM port 4 on X13. The ports support RS 232 voltage level. Table 30 X12/X13 Pinout Description X12/X13...
  • Page 44: Gpio Header

    GPIO Header The conga-JC370 provides eight GPIOs on connector X5, via the congatec Board Controller. The 3.3 V is provided through a 500 mA resetable fuse. Table 31 X5 Pinout Description Pin Signal Description GPIO_0 General Purpose Input Output 0...
  • Page 45: I²C Bus/Sm Bus Header

    + 3.3 V 3.3 V supply (standby) 5.11 I²C Bus/SM Bus Header The conga-JC370 provides header X7 for I²C/SM bus signals. The 3.3 V is provided through a 500 mA resetable fuse. Table 33 X7 Pinout Description Pin Signal Description...
  • Page 46: Front Panel Header

    5.12 Front Panel Header The conga-JC370 provides X4 for front panel features such as lid, sleep, reset and power buttons, as well as status LEDs. Table 34 X4 Pinout Description Signal Name Description LID_BTN# Active-low signal. Triggers sleep state, hibernation or shutdown (depends on OS...
  • Page 47: Cpu Fan Header

    5.12.1 CPU Fan Header The conga-JC370 provides pin header X9 for connecting a 3-pin or 4-pin 12 V CPU fan. The recommended maximum power rating for the fan is 4 W. Table 35 X9 Pinout Description Signal +12 VDC FAN_TACHOIN...
  • Page 48: Additional Features

    Additional Features Micro-SIM Card The conga-JC370 offers a micro-SIM slot on connector X25 for inserting SIM card. Table 36 X25 Pinout Description Signal Description Power Reset Clock Not available Ground Not connected Data Not available Connector Type X25: Micro-SIM card socket (Molex 78800 series) Note 1.
  • Page 49: Case-Open Intrusion Connector

    External BIOS Flash With pin header X37, the conga-JC370 can boot from an external 3.3 V SPI flash. For external BIOS flash, you need an SPI flash with a PCB adapter that connects to X37. For more information, contact congatec support.
  • Page 50: Congatec Board Controller (Cbc)

    The conga-JC370 is equipped with a Microchip MEC1705 microcontroller. This onboard microcontroller plays an important role for most of the congatec BIOS features. It fully isolates some of the embedded features such as system monitoring, I²C bus from the x86 core architecture. The isolation helps improve performance and reliability even when the x86 processor is in a low power mode.
  • Page 51: Oem Boot Logo

    OEM POST Logo This feature allows system designers to replace the congatec POST logo displayed in the upper left corner of the screen during BIOS POST with their own BIOS POST logo. Use the congatec system utility CGUTIL 1.5.4 or later to replace or add the OEM POST logo.
  • Page 52: Congatec Battery Management Interface

    The architecture of the CGOS API driver provides the ability to write application software that runs unmodified on all congatec CPU modules. All the hardware related code is contained within the congatec embedded BIOS on the module. See section 1.1 of the CGOS API software developers guide, available on the congatec website.
  • Page 53: Security Features

    Security Features The conga-JC370 features a firmware TPM (Intel PTT TPM 2.0) as well as a discrete Infineon SLB9670 TPM 2.0. Note To use the discrete TPM module, disable the firmware TPM (fTPM) in the Advanced ->Platform Trust Technology -> fTPM BIOS setup submenu.
  • Page 54: Bios Setup Description

    BIOS Setup Description The BIOS setup description of the conga-JC370 can be viewed without having access to the module. However, access to the restricted area of the congatec website is required in order to download the necessary tool (CgMlfViewer) and Menu Layout File (MLF).
  • Page 55: Updating The Bios

    BIOS updates are recommeded to correct platform issues or enhance the feature set of the module. The conga-JC370 features a congatec/AMI AptioEFI firmware on an onboard flash ROM chip. You can update the firmware with the congatec System Utility. The utility has five versions—...
