IKORE transmitter
LED
1.
2.
Maneuver button
Start button
3.
Hoist selection
4.
5.
STOP button
6.
Removable EEPROM
R11 receiver
1. Fixing slots (fixed assembly or anti-vibration or anti-
vibration with magnets)
2. M25 cable gland
Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products
already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
All trademarks in this material are property of the respective companies. Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
©
2 |
Danfoss | September 2021
Hoist Selection
During the hoist selection, activating maneuvers is not allowed.
Hoist selection can only be done in working mode.
I /I+II /II
* Data sheet
Hoist button and LEDs
For more information, please consult the relevant User Manual.
I /I+II /II
I /I+II /II
Receiver User Manuals & Datasheets
* Data sheet
* Data sheet
Transmitter User Manuals & Datasheets
1
https://www.danfoss.com/en/products/dps/electronic-
controls/human-machine-interfaces-hmi/plus1-remote-
controls/
2
I
II
I
II
I
II
I
II
