Specifications

Water-cooling Integration
Electronics Integration
Cables
LED strips
Motherboard Form Factor
Expansion Slots
Case Form Factor
Package Dimensions & Weight
Case Dimensions & Weight
Storage
Radiators
Maximum GPU Length
Revision 1.0
Spectre 4 & Aevum Limited Edition Assembly Manual
Reservoir, Pump Top, Pump Cover, Fill Port, Drain Port, Parts of water-cooling
loop. (+ Front distribution plate for Aevum)
Ports: x8 G1/4" BSPP. 1x Fill Port. 2x Drain Ports.
Pump: (Not included): Compatible with all D5 pumps.
Connectors: 24pin x1. PCIE 8pin x4. 12VHPWR x2. 8pin EPS x4. PCIE 6pin
Supplementary x1. (Equal inputs and outputs must be used).
Hubs: PWM Fan Hubs x2 each with x1 input and x3 outputs. With coolant
temperature-based RPM control or motherboard control Pump inputs and
outputs x2. Each fan hub and pump output have coolant temperature-based
RPM control or can be switched to motherboard RPM control.
Dedicated PWM header for 140mm fan which can be mounted behind the
motherboard.
PWM Control: 4x potentiometers to set the minimum PWM speed.
ARGB: x13 with one input.
Temperature sensor inputs: x2 for up to two loops. Compatible any water-
cooling brand plug temperature sensor or inline sensor.
LEDs: x28 Integrated ARGB 90-degree LEDs and x28 UV 90-degree LEDs
around the external perimeter of the PowerBoard. There are dip switches to
turn the ARGB and UV LEDs on or off separately and stand-by UV lighting can
be disabled.
Power and Reset Buttons.
PowerBoard direct mount 1 x 2.5" and 1 x 2.5"/3.5" SATA 3.0 6Gb/s accessible
from the back of the distribution plate.
4pin ATX header to power up to two pumps with custom cables from the
PowerBoard.
12pin header for future controller addon.
PSU jump-start switch to run the pump/s without booting so that you can run
only the pump for filling the loop.
Screen: 1920×480 60Hz IPS. (Aevum only)
PowerBoard Linking Cables Standard Set: 24pin x1. 8pin EPS x2. 8pin PCIE x3 or
12VHPWR (Based on selected option). 18AWG Black Headshrinkless Sleeve.
PWM Female to Female 50cm Black Sleeved x1.
ARGB Female to Female 50cm Black Sleeved x1.
Touch Power Button Cables: Power, Reset, Black 20cm. PowerBoard to Horten
Touch Module 60cm Black.
Screen cables: Black 1m Mini HDMI to HDMI, USB-A to USB Micro-B. (Aevum
only)
ARGB 5V 50cm x3.
XL-ATX (Up to: 285mm Wide & 350mm High;
Aevum: 290mm Wide & 350mm High).
E-ATX, ATX, M-ATX, Mini-DTX, Mini-ITX.
x8.
Full Tower Water-cooling Case.
L: 640mm W: 620mm H: 110mm (Case is flat packed). | 24kg.
L: 610mm x W: 245mm x H: 560mm. | 19kg.
x5 2.5" | x2 are on top of the PSU shroud and cannot be used when the GPUs
are vertically mounted. X1 are inside of the PSU Shroud. X2 are on the rear side
of the PowerBoard, x1 is optional 2.5" or 3.5".
420mm/360mm X2 with 100mm of thickness for radiators and fans.
445mm with 60mm front radiator and 25mm fans.
