Step 7: Attach the Front Panel .

The Front Panel comes pre-assembled so first you will need to completely disassemble it by
removing all fasteners.
1
Then attach the
Front Radiator
Mount (K2) to the
case using 4x M4
12mm fasteners.
3
Then attach the
Front Radiator
Panel (K2) and
Front Button Cover
(N2) using 8x M4
12mm fasteners.
5
Attach the Front
Panel Cover (O)
using M4 6mm x3
for Spectre 4 or M4
14mm x3 for Spectre
4 Aevum.
.
Revision 1.0
Spectre 4 & Aevum Limited Edition Assembly Manual
2
Then attach the
Front Radiator
Spacer (M2) using
4x M4 8mm
fasteners.
4
Then attach the Top
Corner Panel (J2)
using 2x M4 16mm
fasteners.
