  • Page 1 Super Smart Switch (Smart Knob Switch) Strip light Manual www.ltech-led.com...

  • Page 2: System Diagram

    System Diagram Wi-Fi/4G/5G CLOUD Phone user... Phone user 1 Scene Timing Automation Home appliances & accessories Router Amazon Echo Google Home appliance HVAC manage- Curtain module ment module motor Wi-Fi Ethernet Drycontactmodule Relay Musicplayer Bluetooth 4.2 Bluetooth Mesh Bluetooth speaker Super Panel 6S Wireless Bluetooth...

  • Page 3: Product Features

    ● Designed with a 86 type junction box. Available in 400+ combinations and installed ● in the unified mounting frames. Technical Specs Model SQ PRO Wireless Type Bluetooth 5.0 SIG Mesh Power Supply Null and live line powered Rated Parameter...

  • Page 4: Product Images

    Product Images LiveLine NullLine Screen Display Strip light Knob Product Size Unit: mm 40.0 14.0 60.8 60.0 62.8 86.0 62.8 86.0 10.5...
  • Page 5 Knob Instructions Double press Rotate Long press Single press Action Single press Double press Rotate Long press Device DIMlight ON/OFF No device action Adjust BRT BRT ± Switchmode Adjust current mode CTlight BRT ± ON/OFF (BRT/CT) (BRT/CT) Switchmode Adjust current mode RGBlight ON/OFF BRT ±...
  • Page 6 Double press Rotate Press and rotate Single press Action Single press Double press Rotate Press and rotate Device Left rotation Music (Previous song) Play music Pause music player Right rotation Right rotation (Volume+) (Next song) Adjust curtain fullness Bluetooth Open/Close Pause No device action (Left rotation:Open)

  • Page 7: Installation Steps

    Installation Steps ①Turn off the circuit breaker and remove any concrete or corrosion that are inside the 86 type wall box. Trim each wire in the wall box to about 10cm in length. Detach the switch plate from the switch with a flat head screwdriver. ②Attach the live line to L socket of the switch and the null line to N socket.
  • Page 8 ③Insert the screws into the holes on two sides of the switch and secure the screws to fit the switch to the wall with a screwdriver. ④ Slant the switch plate and snap it on the switch. Finally, turn on the circuit breaker and press the knob.

  • Page 9: Recommended Applications

    Recommended Applications 1. Work with a Bluetooth LED driver to wirelessly control the lamp. Lamp Smart switch Bluetooth driver 2. Work with a Bluetooth music player to play music freely. Smart switch Music player Bluetooth speaker 3. Work with a Bluetooth curtain motor to intelligently control the curtain. Smart switch Bluetooth curtain 4.
  • Page 10 App Operating Instructions 1. Register an account Scan the QR code below with you mobile phone and follow the prompts to complete the app installation. Then open the App and log in or register an account. 2. Connect to the network Create a home if you are a new App user.
  • Page 11 3.Bind a device In “Room” interface, click the smart switch you have added to access its control interface. Short press the knob on the screen and select bind object【  Device】 , then save your setting.
  • Page 12 4.Set up the display In the control interface, tap the switch screen or tap【  Screen display】 to set up the display, then save your setting.
  • Page 13 5.Automation Please be sure a smart gateway is added to your home, such as Super Panel 6S. Tap【Automation】 in “Intelligence” interface and click【  + 】 icon to create automa- tion. You can choose local or cloud execution option, then set the trigger conditions and executing action. When the conditions you set are met, a series of device actions will be automatically triggered to perform and remote linkage is achieved as well.
  • Page 14 FAQs 1. How to reset the device to factory defaults?  Long press the knob for 15s. When the screen shows “Tap the key 3 times in 3s to delete network”, follow the prompts to reset the device. When the screen shows “Net- work delete success”, it means the device has been reset to factory defaults and is into the state of being searched via Bluetooth.

  • Page 15: Warranty Agreement

    1. Repair or replacement provided is the only remedy for customers. LTECH is not liable for any incidental or consequential damage unless it is within the law. 2. LTECH has the right to amend or adjust the terms of this warranty, and release in written form shall prevail.

This manual is also suitable for:

Sq-pro-gy
