- Page 1 Super Smart Switch (1-Gang / 2-Gang / 3-Gang) Manual www.ltech-led.com...
-
Page 2: System Diagram
System Diagram Wi-Fi/4G/5G CLOUD Phone user... Phone user 1 Scene Timing Automation Home appliances & accessories Router Amazon Echo Google Home appliance Central air Curtain module conditioner module motor Wi-Fi Ethernet Wireless module Relay Musicplayer Bluetooth 4.2 Bluetooth Mesh Bluetooth Speaker Super Panel 6S Wireless Bluetooth... -
Page 3: Product Features
Product Features Act as a relay with Bluetooth 5.0 SIG Mesh, turning traditional lamps into smart ones. ● Support panel grouping that allows you to control multiple panels simultaneousl y. ● Work with a Bluetooth LED driver to turn lights on/off and change brightness or ●... -
Page 4: Product Images
Product Images Load Wire L3/L2/L1 Live Line Null Line Key 1 Key 2 Key 3 Product Size Unit: mm 60.8 28.7 60.0 86.0 62.8 62.8 86.0 40.0... -
Page 5: Installation Steps
Installation Steps ①Turn off the circuit breaker and remove any concrete or corrosion that are inside the 86 type wall box. Trim each power cord wire in the wall box to about 10cm in length. Pry the switch plate up with a flat head screwdriver. ② Attach the live line to L socket of the switch and the null line to N socket, and the load wire to L1/L2/L3 socket. - Page 6 ③ Insert the screws into the hole on two sides of the switch and secure the screws to fit the switch to the wall with a screwdriver. ④ Slant the switch plate and put it in place. Finally, turn on the circuit breaker and press any key of the switch.
-
Page 7: Recommended Applications
Recommended Applications 1. Connect to traditional lamps and turn them into smart ones. Smart switch Traditional lamp 2. Work with a Bluetooth LED driver to wirelessly control lamps. Smart switch Bluetoothdriver Lamp 3. Support local scenes that can still run without the Internet or a gateway. Home appliance Smart switch Bluetooth driver... - Page 8 App Operating Instructions 1. Register an account Scan the QR code below with you mobile phone and follow the prompts to complete the app installation. Then open the App and log in or register an account. 2. Connect to the network Create a home if you are a new App user.
- Page 9 3. Create a panel group Click【 +】 icon in the upper right corner of “Room” interface to access “Add device” list. Pick【 Group-Smart switch group】 . Create a smart switch group, then rename the group and set up the room it belongs to. Pick devices you want to add to the group.
- Page 10 4. Bind a device In “Room” interface, click the smart switch you have added to access its control interface. Long press the key on the screen you want to bind, or click the【 】 to access the settings and select the key. Click【 Bind object-Device】and set up short press and long press actions on this key, then save your setting.
- Page 11 5. Local scene Bind a local scene: In the switch’s control interface, long press the key you want to bind or click the 【 】 to access the settings and select the key. Click【 Bind object-Local scene】 and save your setting. Then, the local scene you bind can be performed by a short press on the key.
- Page 12 6. Cloud scene and automation Please be sure a smart gateway device is added to your home, such as Super Panel 6S. Cloud scene: Switch to “Intelligence” interface and click【 +】 icon in the upper right corner to add a cloud scene. After you set up the action performed in this cloud scene, the remote linkage can be achieved.
- Page 13 FAQs 1. How to reset a switch to factory defaults? Long press the rightmost key for 15s (S1=only key, S2=second key, S3=third key) and release it until all the indicator lights flash fast. Within 3s, short press the same key 3 times and the indicator light flashes slowly, which means the switch has been reset to factory defaults.
-
Page 14: Warranty Agreement
1. Repair or replacement provided is the only remedy for customers. LTECH is not liable for any incidental or consequential damage unless it is within the law. 2. LTECH has the right to amend or adjust the terms of this warranty, and release in written form shall prevail.
