Before Your First Ride - Retrospec Valen REV+ Assembly Instructions Manual

List of E-Bike Component Names
22
16
19
20
21
18
Fig. 1 Electric Bicycle
1. Tires & Tubes
2. Rims
3. Spokes
4. Front Hub
5.
Fork
6. Front Mechanical Disk Brake
7.
Handlebar & Stem
8. Frame
9.
Pedal
10. Chainwheel/Crankset
11. Chain Cover
12. Seat Clamp
13. Seat Post
14. Saddle
1
29
27
25
26 09
08
28
10
14
23
30
32
15
13
07
12
11
17
15. Chain
16. Rear Derailleur
17. Rear Motor Hub
18. Freewheel
19. Kickstand
20. Battery
21. Grip
22. Shift Lever & Brake Lever
23. Throttle
24. Brake, Shift & Display Cables
25. Display
26. Front Light
27. Rear Light

Before your first ride

We strongly recommend taking your bike to a local bike shop after assembling
so a professional, reputable bike mechanic can check your work and perform all
necessary safety checks prior to the first ride. To find a Retrospec dealer near
you, please visit https:/ /retrospec.com/pages/storelocator. Please keep these
instructions for future use and reference. Do not discard.
Congratulations on your purchase of this Retrospec electric bike! We make sure
all our E-Bikes have beencarefully designed and manufactured to the latest
international quality standards.
Please read this instruction manual carefully and thoroughly before assembling
your new E-Bike.
05
06
04
03
02
01
