  • Page 1 UPER ® SC217 Chassis Series SC217HQ-R1620B SC217HD-R1620B SC217HQ-R1400B USER’S MANUAL 1.0a...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: Manual Organization

    SC217 2U chassis. Installa- tion and maintenance should be performed by experienced technicians only. Supermicro's 2U Twin/Twin SC217 chassis is designed to optimize performance per watt and per dollar with two (SC217HD) or four (SC217HQ) independent hot- pluggable DP computing nodes efficiently organized into a 2U form factor.
  • Page 4 SC217 Chassis Manual Chapter 4 System Interface Refer to this chapter for details on the system interface, which includes the functions and information provided by the control panel on the chassis as well as other LEDs located throughout the system. Chapter 5 Chassis Setup and Maintenance Follow the procedures given in this chapter when installing or removing components, or reconfiguring your chassis.

  • Page 5: Table Of Contents

    Chapter 1 Introduction Overview ......................1-1 Shipping List ....................1-1 Part Numbers ....................1-1 Contacting Supermicro ..................1-2 Returning Merchandise for Service..............1-3 Chapter 2 Standardized Warning Statements for AC Systems About Standardized Warning Statements ............2-1 Warning Definition ................... 2-1 Installation Instructions ..................
  • Page 6 SC217 Chassis Manual Chapter 4 System Interface Overview ......................4-1 Control Panel Buttons ..................4-2 Control Panel LEDs ..................4-2 Drive Carrier LEDs ..................4-3 Chapter 5 Chassis Setup and Maintenance Overview ......................5-1 Removing the Power Cord ................5-1 Chassis Cover ....................
  • Page 7 Preface Mechanical Loading ..................6-3 Circuit Overloading ..................6-3 Reliable Ground ....................6-3 Rack Mounting Instructions ................6-4 Identifying the Sections of the Rack Rails ............6-4 Locking Tabs ....................6-5 Releasing the Inner Rail ................. 6-5 Installing The Inner Rails on the Chassis ............6-6 Installing the Outer Rails on the Rack ............
  • Page 8 SC217 Chassis Manual Notes viii...

  • Page 9: Chapter 1 Introduction

    Introduction Overview The Supermicro SC217 chassis is designed to optimize performance per watt and per dollar, efficiently organized into a 2U form factor. It can house either the Twin (HD models) with two independent hot-pluggable DP computing nodes, or the Twin (HQ models) with four independent hot-pluggable DP computing nodes.

  • Page 10: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 11: Returning Merchandise For Service

    For faster service, RMA authorizations may be requested online (http://www. supermicro.com/support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping.
  • Page 12 SC217 Chassis Manual Notes...

  • Page 13: Chapter 2 Standardized Warning Statements For Ac Systems

    Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Definition Warning! This warning symbol means danger.
  • Page 14 SC217 Chassis Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 15 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 16: Installation Instructions

    SC217 Chassis Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 17: Circuit Breaker

    Chapter 2: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 18: Power Disconnection Warning

    SC217 Chassis Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 19 Chapter 2: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 20: Equipment Installation

    SC217 Chassis Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 21: Restricted Area

    Chapter 2: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 22: Battery Handling

    SC217 Chassis Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬ ‫فقط‬ ‫محظورة‬...
  • Page 23 Chapter 2: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 24: Redundant Power Supplies

    SC217 Chassis Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 25: Backplane Voltage

    Chapter 2: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 26: Comply With Local And National Electrical Codes

    SC217 Chassis Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이...

  • Page 27: Product Disposal

    Chapter 2: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 28: Hot Swap Fan Warning

    SC217 Chassis Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 29 Chapter 2: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 30: Power Cable And Ac Adapter

    Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター 製品を設置する場合、 提供または指定された接続ケーブル、 電源コードとACアダプター...
  • Page 31 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 32 SC217 Chassis Manual Notes 2-20...

  • Page 33: Chapter 3 Chassis Components

    Some components listed may not be included or compatible with your particular chassis model. For more information, see the installation instructions detailed later in this manual or visit the Supermicro web site at www.supermicro.com. Component Descriptions The SC217HD models house two separate computing nodes, each containing its own motherboard.

  • Page 34: Power Supply

    The air shroud differs for different motherboards. If using a motherboard which is not the default in the chassis, refer to the optional parts in Appendix A of this manual, or the Supermicro Web site at www.supermicro.com to puchase the proper air shroud. Mounting Rails The SC217 includes a set of quick-release rails, and can be placed in a rack for secure storage and use.

  • Page 35: Chapter 4 System Interface

    Chapter 4: System Interface Chapter 4 System Interface Overview There are LEDs on each control panel and on the drive carriers to keep you informed of the status of the system. The control panels are located on the front, outside edges of the chassis.

  • Page 36: Control Panel Buttons

    SC217 Chassis Manual Control Panel Buttons • Power: The main power button on each of the control panels is used to apply or remove power from the power supply to associated node Turning power to the system off with this button removes the main power, but keeps standby power supplied to the system.

  • Page 37: Drive Carrier Leds

    Chapter 4: System Interface • Alert: This LED is illuminated when an alert condition occurs. Informational LED Status Description An overheat condition has occured. Continuously on and red (This may be caused by cable congestion) Fan failure, check for an inoperative fan. Blinking red (1Hz) Power failure, check for a non-operational Blinking red (0.25Hz)
  • Page 38 SC217 Chassis Manual Notes...

  • Page 39: Chapter 5 Chassis Setup And Maintenance

    Chapter 5: Chassis Setup and Maintenance Chapter 5 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform mainte- nance on the chassis. The only tool you will need to install components and perform maintenance is a Phillips screwdriver.

  • Page 40: Chassis Cover

    SC217 Chassis Manual Chassis Cover Remove two screws Check Ventilation Openings Figure 5-1. Removing the Chassis Cover Before operating the SC217 chassis for the first time, it is important to remove the protective film over the cover of the chassis, in order to allow for proper ventilation and cooling.

  • Page 41: Sc217Hd Models

    Chapter 5: Chassis Setup and Maintenance Hard Drives The SC217 features hot-swappable hard drives which can be removed from the chassis without powering down the server. SC217HD Models The SC217HD chassis contains two separate computing node drawers, each with its own motherboard.

  • Page 42: Sc217Hq Models

    SC217 Chassis Manual SC217HQ Models The SC217HQ chassis contains four separate computing node drawers, each with its own motherboard. Each node controls a set of six hard drives. If a node drawer is pulled out of the chassis, the hard drives associated with that node will power down. Motherboard Drawer Locations in the Chassis for HQ Models Motherboard B controls HDDs Motherboard D controls HDDs...
  • Page 43 Chapter 5: Chassis Setup and Maintenance Figure 5-4. Removing a Hard Drive Carrier Removing Hard Drive Carriers from the Chassis 1. Press the release button on the drive carrier. This extends the handle of the drive carrier. 2. Use the handle to pull the drive out of the chassis.
  • Page 44 SC217 Chassis Manual Figure 5-5. Removing Dummy Drive from Carrier Installing a Drive into the Hard Drive Carrier 1. Remove the four screws securing the drive to the carrier. 2. Lift the drive up and out of the carrier.
  • Page 45 Chapter 5: Chassis Setup and Maintenance SAS/SATA Mounting Holes Hard Drive Drive Carrier Figure 5-6. Installing the Hard Drive 3. Install a new drive into the carrier with the printed circuit board side facing down so that the mounting holes in the drive align with those in the carrier. 4.

  • Page 46: Removing And Installing The Backplane

    SC217 Chassis Manual Removing and Installing the Backplane The backplane is located behind the hard drives and in front of the front system fans. In the rare event of a backplane failure, follow the instructions below. Removing the Backplane Removing the Backplane from the Chassis 1.
  • Page 47 Chapter 5: Chassis Setup and Maintenance 7. Loosen the three screws in the spring bar, located on the floor of the chassis, indicated by the arrows below. Figure 5-8. Loosening the Spring Bar Screws in the Floor of the Chassis 8.

  • Page 48: Installing The Backplane

    SC217 Chassis Manual Installing the Backplane Installing the Backplane into the Chassis 1. Ensure that all of the hard drive carriers have been removed from the bays in the front of the chassis and that the spring bar has been loosened as directed in the previous section.

  • Page 49: Installing The Motherboard

    Chapter 5: Chassis Setup and Maintenance Installing the Motherboard Compatible Motherboards Most Supermicro wirelessTwin series motherboards are compatible with the SC217 chassis. For the most up-to-date information on compatible motherboards and other parts, visit the Supermicro Web site at www.supermicro.com.
  • Page 50 SC217 Chassis Manual Installing the Motherboard 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, cautions, and cable connections. 2. Remove the motherboard node from the back of the chassis. It is not neces- sary to power down the entire system.

  • Page 51: Installing An Adapter Card

    Chapter 5: Chassis Setup and Maintenance Installing an Adapter Card Adapter cards connect to the motherboard to the backplane and provide hot-swappable functionality to the node. Spacer Plate Adapter Card Motherboard Drawer Five Screws Figure 5-12. Adapter Card Installation Removing the Adapter Card 1.

  • Page 52: Adding An Expansion

    SC217 Chassis Manual Adding an Expansion Card The SC217 chassis supports expansion cards. Riser cards are used to mount the expansion cards. • The SC217HQ models accommodate one low-profile card per node, for a total of four in the chassis. •...

  • Page 53: Installing The Riser Card

    Chapter 5: Chassis Setup and Maintenance Figure 5-14. Installing the Riser Card (HQ model shown) Installing the Riser Card Installing the Riser Card 1. Use the control panel to power down the computing node, and pull the node drawer out of the chassis. 2.
  • Page 54 SC217 Chassis Manual Expansion Card PCI Slot Riser Card Shield Screw Riser Card Drawer (viewed with back to the left) Figure 5-15a. Installing the Expansion Card (HQ Model) Installing Expansion Cards 1. Use the control panel to power down the computing node, and pull the node drawer out of the chassis.
  • Page 55 Chapter 5: Chassis Setup and Maintenance Riser Card Screw Riser Card Expansion Card Motherboard PCI I/O slots Drawer (viewed with back to the right) Figure 5-15b. Installing the Expansion Card (HD Model) 5-17...

  • Page 56: Installing The Air Shrouds

    SC217 Chassis Manual Installing the Air Shrouds Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The SC217 chassis requires air shrouds for each motherboard node. Air shrouds vary depending upon the motherboard used. See the illustrations below. Installing an Air Shroud 1.

  • Page 57: Checking The Airflow

    Chapter 5: Chassis Setup and Maintenance Checking the Airflow Checking Airflow • Make sure there are no objects obstructing the airflow in and out of the chassis. In addition, if you are using a front bezel, make sure the bezel filter is replaced periodically.

  • Page 58: System Fans

    SC217 Chassis Manual System Fans Four fans provide cooling for the chassis. These fans circulate air through the chas- sis as a means of lowering the chassis internal temperature. The SC217 system fans are easy-to-change modules. There is no need to uninstall any other parts inside the system when replacing fans, and no tools are required for installation.
  • Page 59 Chapter 5: Chassis Setup and Maintenance Figure 5-18. Replacing a System Fan in the Fan Housing 7. Place the replacement fan into the vacant space in the housing while making sure the arrows on the top of the fan (indicating air direction) point in the same direction as the arrows on the other fans.

  • Page 60: Power Supply

    In the unlikely event that one power supply unit needs to be replaced, it can be removed, without powering down the system. Replacement units can be ordered directly from Supermicro (See the contact information in the preface of this manual). 1. Push the release tab on the back of the power supply as illustrated.

  • Page 61: Chapter 6 Rack Installation

    Chapter 6: Rack Installation Chapter 6 Rack Installation Overview This chapter provides instructions to install the chassis into a rack en- vironment. Following these steps in the order given should enable you to have the installation completed within a minimal amount of time. Note: This chassis requires a standard four post rack and is not approved for use in a two-post "Telco"...

  • Page 62: Warnings And Precautions

    SC217 Chassis Manual • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). Warnings and Precautions Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them.

  • Page 63: Rack Mounting Considerations

    Chapter 6: Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (TMRA).

  • Page 64: Rack Mounting Instructions

    SC217 Chassis Manual Rack Mounting Instructions This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 65: Locking Tabs

    Chapter 6: Rack Installation Locking Tabs Each inner rail has a locking tab. This tab locks the chassis into place when installed and pushed fully into the rack. These tabs also lock the chassis in place when fully extended from the rack. This prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing.

  • Page 66: Installing The Inner Rails On The Chassis

    SC217 Chassis Manual Inner Rails Figure 6-3. Installing the Inner Rails Figure 6-4. Inner Rails Installed on the Chassis (The chassis pictured is a similar example.) Installing The Inner Rails on the Chassis Installing the Inner Rails 1. Identify the left and right inner rails as described in Figure 6-1.. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 67: Installing The Outer Rails On The Rack

    Chapter 6: Rack Installation L-min=676.00(26.61")(outer rail) 21D01 Figure 6-5. Extending and Releasing the Outer Rails Stability hazard. The rack stabilizing mechanism must be in place, or the rack must be bolted to the floor before you slide the unit out for servicing. Failure to stabilize the rack can cause the rack to tip over.

  • Page 68: Standard Chassis Installation

    SC217 Chassis Manual Ball-Bearing Shuttle Figure 6-6. Installing into a Rack Standard Chassis Installation Installing the Chassis into a Rack 1. Confirm that the inner rails are properly installed on the chassis. 2. Confirm that the outer rails are correctly installed on the rack. 3.

  • Page 69: Optional Quick Installation Method

    Chapter 6: Rack Installation Warning: Do not pick up the server by the front handles. They are designed to pull the system from a rack only. Optional Quick Installation Method The following quick installation method may be used to install the chassis onto a rack.
  • Page 70 SC217 Chassis Manual Notes 6-10...

  • Page 71: Appendix A Cables, Screws, And Other Accessories

    It only includes the most commonly used components and configurations. For more compatible cables, refer to the manufac- turer of the motherboard you are using and our web site at: www.supermicro.com. A-2 Compatibility and Optional Accessories Visit the Supermicro web site for an up-to-date list of optional accessories specific to each SC217 chassis model.

  • Page 72: Chassis Screws

    SC217 Chassis Manual A-3 Chassis Screws The chassis and accessory box includes all of the screws needed to setup your chassis. This section includes descriptions of the most common screws used. Your chassis may not require all of the parts listed. HARD DRIVE Flat head Pan head...

  • Page 73: Appendix B Sc217 Power Supply Specifications

    Appendix B: Power Supply Specifications Appendix B SC217 Power Supply Specifications This appendix lists power supply specifications for your chassis system. SC217HQ-R1400B 1400W MFR Part # PWS-1K41P-1R 1100W: 100 - 140V, 50 - 60Hz, 9.5 - 13.5 Amp AC Input 1400W: 180 - 240V, 50 - 60Hz, 7.0 - 9.5 Amp DC Output +5 4 Amp...
  • Page 74 SC217 Chassis Manual Notes...

  • Page 75: Appendix C Bpn-Sas-217Hq Backplane Specifications

    Appendix C: BPN-SAS-217HQ Backplane Specifications Appendix C BPN-SAS-217HQ Backplane Specifications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.
  • Page 76 This manual reflects BPN-SAS-217HQ Revision 1.00, the most current release avail- able at the time of publication. Always refer to the Supermicro Web site at www.su- permicro.com for the latest updates, compatible parts and supported configurations.

  • Page 77: Front Connectors

    Appendix C: BPN-SAS-217HQ Backplane Specifications C-5 Front Connectors D120 JP69 JPW4 JP56 FAN2 JP55 JP54 FAN1 FAN3 MB-D C272 C271 FAN4 MB-B JP57 C267 C266 C269 SAS217HQ JPW2 JPW3 REV 1.00 R365 R344 DESIGNED IN USA JP70 UPGRAD #1 JPW1 JP36 JP73 JP36...
  • Page 78 SC217 Chassis Manual 1. - 3. Motherboard Power Connectors These connectors, designated JPW1, JPW2, and JPW3 supply power the four motherboard nodes in the chassis. 4. - 7. Chassis Fan Connectors These connectors, designated JP54, JP55, JP56 and JP57 supply power to the chassis. cooling fans.
  • Page 79 Appendix C: BPN-SAS-217HQ Backplane Specifications 13. - 14. Backplane to Front Panel Headers These connectors are designated JF5 and JF6. They connect the backplane to the front LED panels on the chassis. JF5 con- nects to the LED display panel for mother- boards A and B.

  • Page 80: Front Jumpers And Pin Definitions

    SC217 Chassis Manual C-6 Front Jumpers and Pin Definitions JP69 D120 JP69 JPW4 JP56 FAN2 JP55 JP54 FAN1 FAN3 MB-D C272 C271 FAN4 MB-B JP57 C267 C266 C269 SAS217HQ JPW2 JPW3 REV 1.00 R365 R344 DESIGNED IN USA JPW1 JP70 UPGRAD #1 JP36 JP73...

  • Page 81: Front Led Indicator

    Appendix C: BPN-SAS-217HQ Backplane Specifications C-7 Front LED Indicator D120 D120 JPW4 JP69 JP56 FAN3 FAN2 JP55 JP54 FAN1 MB-D C272 C271 FAN4 MB-B JP57 C267 C266 C269 SAS217HQ JPW2 JPW3 REV 1.00 R365 R344 DESIGNED IN USA JP70 UPGRAD #1 JPW1 JP36 JP73...

  • Page 82: Rear Connectors And Led Indicators

    SC217 Chassis Manual C-8 Rear Connectors and LED Indicators A0 A1A2 A3A4 A5 B0 B1 B2B3 B4 B5 C0 C1 C2 C3 C4 C5 D0D1 D2 D3D4 A0 SAS-#A1 SAS-#A2 SAS-#A3 SAS-#A4 SAS-#A5 SAS-#B0 SAS-#B1 SAS-#B2 SAS-#B3 SAS-#B4 SAS-#B5 SAS-#C0 SAS-#C2 SAS-#C4 SAS-#C5...
  • Page 83 Appendix C: BPN-SAS-217HQ Backplane Specifications Rear LED Indicators Rear LED FAIL Rear LED FAIL SAS-#A0 SAS-#C0 SAS-#A1 SAS-#C1 SAS-#A2 SAS-#C2 SAS-#A3 SAS-#C3 SAS-#A4 SAS-#C4 SAS-#A5 SAS-#C5 SAS-#B0 SAS-#D0 SAS-#B1 SAS-#D1 SAS-#B2 SAS-#D2 SAS-#B3 SAS-#D3 SAS-#B4 SAS-#D4 SAS-#B5 SAS-#D5...

  • Page 84: Sas Ports

    SC217 Chassis Manual SAS Ports The SAS-217HQ backplane is designed with four separate nodes, which support from one to four motherboards indepentdently of each other. The SAS ports are used to connect the SAS drive cables. The 24 ports are designated A0, A1, A2, A3, A4, A5, B0, B1, B2, B3, B4, B5, C0, C1, C2, C3, C4, C5, D0, D1, D2, D3, D4, and D5.

  • Page 85: Esd Safety Guidelines

    Appendix D BPN-SAS-217HD Backplane Specifications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. D-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.

  • Page 86: An Important Note To Users

    This manual reflects BPN-SAS-217HD Revision 1.01, the most current release avail- able at the time of publication. Always refer to the Supermicro Web site at www.su- permicro.com for the latest updates, compatible parts and supported configurations.

  • Page 87: Front Connectors

    Appendix D: BPN-SAS-217HD Backplane Specifications D-5 Front Connectors D120 JPW4 JP69 JP54 JP56 FAN3 FAN2 JP55 FAN1 MB-D FAN4 MB-B JP57 C267 C266 SAS217HD JPW2 JPW3 REV 1.00 DESIGNED IN USA JP70 UPGRAD #1 JPW1 JP36 JP73 JP72 JP36 JP71 OPEN: DEFAULT UPGRAD #3 UPGRAD #2...
  • Page 88 SC217 Chassis Manual 1. - 3. Motherboard Power Connectors These connectors, designated JPW1, JPW2, and JPW3 supply power the four motherboard nodes in the chassis. 4. - 7. Chassis Fan Connectors These connectors, designated JP54, JP55, JP56 and JP57 supply power to the chassis. cooling fans.
  • Page 89 Appendix D: BPN-SAS-217HD Backplane Specifications 13. - 14. Backplane to Front Panel Headers These connectors are designated JF5 and JF6. They connect the backplane to the front LED panels on the chassis. JF5 con- nects to the LED display panel for mother- board A.

  • Page 90: Front Jumpers And Pin Definitions

    SC217 Chassis Manual D-6 Front Jumpers and Pin Definitions JP69 D120 JP69 JPW4 JP56 FAN2 JP55 JP54 FAN1 FAN3 MB-D FAN4 MB-B JP57 C267 C266 SAS217HD JPW2 JPW3 REV 1.00 DESIGNED IN USA JPW1 JP70 UPGRAD #1 JP36 JP73 JP36 JP72 JP71 OPEN: DEFAULT...

  • Page 91: Front Led Indicator

    Appendix D: BPN-SAS-217HD Backplane Specifications D-7 Front LED Indicator D120 D120 JPW4 JP69 JP54 JP56 FAN3 FAN2 JP55 FAN1 MB-D FAN4 MB-B JP57 C267 C266 SAS217HD JPW2 JPW3 REV 1.00 DESIGNED IN USA JP70 UPGRAD #1 JPW1 JP36 JP73 JP36 JP72 JP71 OPEN: DEFAULT...

  • Page 92: Rear Connectors And Led Indicators

    SC217 Chassis Manual D-8 Rear Connectors and LED Indicators A0 A1A2 A3A4 A5 B0 B1 B2B3 B4 B5 C0 C1 C2 C3 C4 C5 D0D1 D2 D3D4 A0 SAS-#A1 SAS-#A2 SAS-#A3 SAS-#A4 SAS-#A5 SAS-#B0 SAS-#B1 SAS-#B2 SAS-#B3 SAS-#B4 SAS-#B5 SAS-#C0 SAS-#C2 SAS-#C4 SAS-#C5...
  • Page 93 Appendix D: BPN-SAS-217HD Backplane Specifications Rear LED Indicators Rear LED FAIL Rear LED FAIL SAS-#A0 SAS-#C0 SAS-#A1 SAS-#C1 SAS-#A2 SAS-#C2 SAS-#A3 SAS-#C3 SAS-#A4 SAS-#C4 SAS-#A5 SAS-#C5 SAS-#B0 SAS-#D0 SAS-#B1 SAS-#D1 SAS-#B2 SAS-#D2 SAS-#B3 SAS-#D3 SAS-#B4 SAS-#D4 SAS-#B5 SAS-#D5...

  • Page 94: Sas Ports

    SC217 Chassis Manual D-9 SAS Ports The SAS-217HD backplane is designed with two separate nodes, which support from one to two motherboards indepentdently of each other. The SAS ports are used to connect the SAS drive cables. The twenty-four ports are designated A0, A1, A2, A3, A4, A5, B0, B1, B2, B3, B4, B5, C0, C1, C2, C3, C4, C5, D0, D1, D2, D3, D4, and D5.
  • Page 95 Appendix D: BPN-SAS-217HD Backplane Specifications Notes D-11...
  • Page 96 SC217 Chassis Manual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
