- Page 1 SC213 C haSSiS erieS SC213AC-R1K23LPB SC213AC-R1K23WB SC213AC-R920LPB SC213AC-R920WB SC213A-R740LPB SC213A-R740WB SC213A-R720LPB SC213A-R720UB SC213A-R900LPB SC213A-R900UB USer’S MaNUaL 1.0c...
- Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
- Page 3 This document lists compatible parts available when this document was published. Refer to the Supermicro web site for updates on supported parts and configurations. Warnings Special attention should be given to the following symbols used in this manual.
-
Page 4: Table Of Contents
SC213 Chassis Manual Contents Chapter 1 Introduction Overview ......................1-1 Shipping List ....................1-2 Chassis Features .................... 1-2 Motherboard Support ..................1-2 Drives ......................1-2 PCI Expansion Slots ..................1-2 Cooling ......................1-2 Control Panel ....................1-2 Cables ......................1-2 Returning Merchandise for Service.............. - Page 5 Preface Control Panel LEDs ..................3-2 Power ......................3-2 HDD ......................... 3-2 NIC2 ........................ 3-3 NIC1 ........................ 3-3 Information LED ....................3-3 Power Fail ....................... 3-3 Overheating ..................... 3-4 Drive Carrier LEDs ..................3-4 Power Supply LEDs ..................3-5 Chapter 4 Chassis Setup and Maintenance Overview ......................
-
Page 6: Contacting Supermicro
Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML... -
Page 7: Chapter 1 Introduction
Chapter 1 Introduction Overview The Supermicro SC213 chassis features a direct-attached SAS3 backplane supporting sixteen 2.5" SAS/SATA hard disk drives. It has dual highly efficient redundant power supplies, an optional DVD drive, two USB ports, three 80mm fans, and room for seven PCI Express expansion cards. -
Page 8: Shipping List
SC213 Chassis Manual Shipping List Visit the Supermicro web site for the latest shipping lists and part numbers for your particular chassis model at www.supermicro.com. Chassis Features The SC213 3U high-performance chassis includes the following features: Motherboard Support The chassis supports motherboard sizes of 13.68" x 13.0", E-ATX, ATX form factors. -
Page 9: Returning Merchandise For Service
For faster service, RMA authorizations may be requested online (http://www. supermicro.com/support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping. - Page 10 SC213 Chassis Manual Notes...
-
Page 11: Chapter 2 Rack Installation
Chapter 2 Rack Installation Chapter 2 Rack Installation This chapter provides instructions for preparing and mounting your chassis in a rack. Unpacking the System You should inspect the box the chassis was shipped in and note if it was damaged in any way. -
Page 12: Warnings And Precautions
SC213 Chassis Manual Warnings and Precautions Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. • In single rack installations, stabilizers should be attached to the rack. •... -
Page 13: Rack Mounting Considerations
Chapter 2 Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (TMRA). -
Page 14: Installing The System Into A Rack
SC213 Chassis Manual Installing the System into a Rack This section provides information on installing the server into a rack unit with the rack rails provided. There are a variety of rack units on the market, so the assembly procedure may differ slightly. Refer to the installation instructions that came with your rack. -
Page 15: Releasing The Inner Rail
Chapter 2 Rack Installation Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. Releasing Inner Rail from the Outer Rails 1. -
Page 16: Installing The Inner Rails On The Chassis
SC213 Chassis Manual Installing the Inner Rails on the Chassis Installing the Inner Rails 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail. -
Page 17: Installing The Outer Rails Onto The Rack
Chapter 2 Rack Installation Installing the Outer Rails onto the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3. -
Page 18: Sliding The Chassis Onto The Rack Rails
SC213 Chassis Manual Sliding the Chassis onto the Rack Rails Warning: Mounting the system into the rack requires at least two people to support the chassis during installation. Please follow safety recommendations printed on the rails. Installing the Chassis into a Rack 1. -
Page 19: Chapter 3 System Interface
Chapter 3: System Interface Chapter 3 System Interface Overview The server includes a control panel on the front that houses power buttons and status monitoring lights. The externally accessible hard drives display status lights. The power supply displays status lights visible from the back of the chassis. Figure 3-1. -
Page 20: Control Panel Buttons
SC213 Chassis Manual Control Panel Buttons The chassis includes two push-buttons that control power to the system. Power The main power switch applies or removes primary power from the power supply to the server but maintains standby power. To perform most maintenance tasks, unplug the system to remove all power.. -
Page 21: Nic2
Chapter 3: System Interface NIC2 Indicates network activity on GLAN2 when flashing. NIC1 Indicates network activity on GLAN1 when flashing. Information LED Alerts operator to several states, as noted in the table below. Information LED Status Description An overheat condition has occured. Continuously on and red (This may be caused by cable congestion.) Blinking red (1Hz) -
Page 22: Overheating
Some backplanes allow the overheat temperature to be set at 45, 50, or 55 by changing a jumper setting. For more information, consult the backplane user manual at www.supermicro.com. (Click Support, then the Manuals link.) Responses If the server overheats: 1. -
Page 23: Power Supply Leds
Chapter 3: System Interface Power Supply LEDs On the rear of the power supply module, an LED displays the status. • Solid Green: When illuminated, indicates that the power supply is on. • Solid Amber: When illuminated, indicates the power supply is plugged in and turned off, or the system is off but in an abnormal state. - Page 24 SC213 Chassis Manual Notes...
-
Page 25: Chapter 4 Chassis Setup And Maintenance
Chapter 4: Chassis Setup and Maintenance Chapter 4 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform maintenance on the chassis. The only tool required is a Phillips screwdriver. Review the warnings and precautions listed in the manual before setting up or servicing this chassis. -
Page 26: Removing Power From The System
SC213 Chassis Manual Removing Power from the System Before performing some setup or maintenance tasks, use the following procedure to ensure that power has been removed from the system. 1. Use the operating system to power down the node, following the on-screen prompts. -
Page 27: Removing The Chassis Cover
Chapter 4: Chassis Setup and Maintenance Removing the Chassis Cover Figure 4-4. Removing the Chassis Cover Removing the Chassis Cover 1. Press both release tabs at the same time to release the cover from the locked position. 2. Once the top cover has been released, slide the cover backwards, toward the rear of the chassis. -
Page 28: Installing Hard Drives
SC213 Chassis Manual Installing Hard Drives The chassis supports sixteen hot-swap hard drives. Only SAS or enterprise SATA HDDs are recommended. The drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airflow for the drive bays. - Page 29 Chapter 4: Chassis Setup and Maintenance Figure 4-6. Chassis Drive Carrier Installing a Hard Drive into a Drive Carrier 1. Insert a drive into the carrier with the PCB side facing down and the connector end toward the rear of the carrier. 2.
-
Page 30: Installing Expansion Cards
For the W models such as SC213AC-R920WB, and the U models such as SC213A-R720UB the chassis slots are horizontal. The U models allow a Supermicro universal I/O (UIO) card in addition to expansion cards. - Page 31 Chapter 4: Chassis Setup and Maintenance supports an additional three full-height expansion cards and three low profile expan- sion cards. If the serverboard does not support a UIO, then the W model chassis supports four full-height expansion cards and three low profile expansion cards. Installing a UIO Card 1.
- Page 32 SC213 Chassis Manual Shield Clamp for Full-Height Card This U model chassis is Shield Clamp for Low Profile Card pictured without the riser card bracket. Figure 4-10. Remove an Expansion Card Slot Shield 3. Attach the riser card(s) to the riser card bracket using screws. Note that there are different cards for the right and left side of the bracket.
-
Page 33: Installing The Air Shroud
Chapter 4: Chassis Setup and Maintenance Installing the Air Shroud Air shrouds concentrate airflow to maximize fan efficiency. It does not require screws for installation. UIO models require an additional air shroud that must be installed before the main shroud.. Figure 4-11. - Page 34 SC213 Chassis Manual Figure 4-12. Installing the UIO Model Air Shroud An additional air shroud is required for high-powered CPUs, to provide extra cooling. Install the additional air shroud if necessary. Installing the UIO Air Shroud 1. Remove the left side break-away piece of the main air shroud. 2.
-
Page 35: Power Supply
The chassis has a redundant power supply. Redundant power supplies are hot- swappable, and can be changed without powering down the system. New units can be ordered directly from Supermicro. Replace a failed power module with the same model. This power supply is auto-switching capable. This enables it to automatically sense and operate at a 100v to 240v input voltage. -
Page 36: Installing The Power Distributor
SC213 Chassis Manual Installing the Power Distributor The power distributor provides failover and power supply redundancy and is pre-installed in the chassis. In the rare event that you have to replace the power distributor, follow the steps below. Figure 4-14. Installing the Power Distributor Changing the Power Distributor 1. -
Page 37: Removing The Backplane
Chapter 4: Chassis Setup and Maintenance Removing the Backplane The backplane is located behind the hard drives and in front of the front system fans. In order to change jumper settings on the backplane, it may be necessary to remove the backplane from the chassis. Removing the Backplane from the Chassis 1. - Page 38 SC213 Chassis Manual 5. Loosen but do not remove the three screws in the spring bar, located on the floor of the chassis, indicated by the arrows below. Figure 4-16. Loosening the Spring Bar Screws in the Floor of the Chassis 6.
-
Page 39: Appendix A Sc213 Power Supply Specifications
Appendix A: Power Supply Specifications Appendix A SC213 Power Supply Specifications This appendix lists power supply specifications for your chassis system. 920W (Redundant) MFR Part # PWS-920P-1R AC Input 100-240 V, 50-60 Hz, 11-4.5 Amp 4 Amp @ +5V standby DC Output 75 Amp @ +12V 740W (Redundant) - Page 40 SC213 Chassis Manual 900W (Redundant) MFR Part # PWS-902-1R AC Input 100 - 240V, 60-50Hz, 11-4.5 Amp +5V standby 4 Amp DC Output +12V 75 Amp +5V: 45 Amp DC Output +3.3V: 24 Amp with PDB -12V: 0.6 AmpVsb/4A 1200W (Redundant) MFR Part # PWS-1K23A-1R 100 - 127V, 60-50Hz, 15-12 Amps AC Input...
-
Page 41: Appendix B Standardized Warning Statements For Ac Systems
Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Definition Warning! This warning symbol means danger. - Page 42 SC213 Chassis Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
- Page 43 Appendix B: Warning Statements for AC Systems جسذٌة اصابة ًتتسبب ف حالة ٌوكي أى ًاًك ف خطز ًٌٌع هذا الزهز !تحذٌز الذوائز بالوخاطز الٌاجوة عي ي على علن ، ك هعذات تعول على أي قبل أى الكهزبائٍة حىادث أي وقىع وٌع...
-
Page 44: Installation Instructions
SC213 Chassis Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. -
Page 45: Circuit Breaker
Appendix B: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、... -
Page 46: Power Disconnection Warning
SC213 Chassis Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A. - Page 47 Appendix B: Warning Statements for AC Systems auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.
-
Page 48: Equipment Installation
SC213 Chassis Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden. -
Page 49: Restricted Area
Appendix B: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security. -
Page 50: Battery Handling
SC213 Chassis Manual אזור עם גישה מוגבלת !אזהרה יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת .)'כלי אבטחה בלבד (מפתח, מנעול וכד محظورة مناطق ٍنتركُبها ف هذه انىحذة تخصيص تم ،أداة خاصت من خالل استخذاو فقط محظورة... - Page 51 Appendix B: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.
-
Page 52: Redundant Power Supplies
SC213 Chassis Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden. -
Page 53: Backplane Voltage
Appendix B: Warning Statements for AC Systems امداد الطاقة بوحدات عدة اتصاالت جهاز ال يكون لهذا قد الكهرباء عن وحدة ال لعسل كافة االتصاالت يجب إزالة 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을... -
Page 54: Comply With Local And National Electrical Codes
SC213 Chassis Manual מתח בפנל האחורי !הרה אז קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך .העבודה اللىحة أوالطاقة المىجىدة على التيار الكهزبائي مه خطز هناك هذا الجهاس خدمة كه حذرا عند يعمل النظام عندما يكىن 경고! 시스템이... -
Page 55: Product Disposal
Appendix B: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. תיאום חוקי החשמל הארצי !אזהרה הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים התקנת المتعلقة المحلية والىطىية قىاويه يجب أن يمتثل لل الكهربائية... -
Page 56: Hot Swap Fan Warning
SC213 Chassis Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. - Page 57 Appendix B: Warning Statements for AC Systems 警告 危險的可移動性零件。請務必與轉動的風扇葉片保持距離。 當您從機架移除風扇裝 置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他物品太靠近風扇。 Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
- Page 58 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind. B-18...
- Page 59 םילבכב שמתשהל רוסיא םייק ,תוחיטבה יקוחו למשחה ירישכמב שומישה יקוחל םאתהב -ב םיכמסומהUL -ב ואCSA (( לש דוק םהילע עיפומ רשאכUL/CSA ילמשח רצומ לכ רובע י"ע םאתוה רשא רצומב קר אלא ,רחאSupermicro .דבלב تالباكلا ءارشب مق وأ ةددحملا وأ ةرفوتملا تاليصوتلا مادختساب مق ،جتنملا بيكرت دنع...
- Page 60 Het gebruik van niet geschikte Kabels en/of Adapters kan een storing of brand veroorzaken. Wetgeving voor Elektrische apparatuur en Materiaalveiligheid verbied het gebruik van UL of CSA -gecertificeerde Kabels (met UL/CSA in de code) voor elke andere toepassing dan de door Supermicro hiervoor beoogde Producten. B-20...
-
Page 61: Appendix C Bpn-Sas-213A Backplane Specifications
Appendix C: SAS-213A Backplane Specifications Appendix C BPN-SAS-213A Backplane Specifications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully. - Page 62 This manual reflects BPN-SAS-213A Revision 1.00, the most current release avail- able at the time of publication. Always refer to the Supermicro Web site at www.su- permicro.com for the latest updates, compatible parts and supported configurations.
- Page 63 Appendix C: SAS-213A Backplane Specifications C-4 Rear Connectors and Jumpers The following connectors are on the side of the backplane that faces the rear of the chassis. They are marked by silkscreen labels. JP35 SAS IN#4 SAS IN#3 SAS IN#2 JSM4 JSM3 JSM2...
- Page 64 SC213 Chassis Manual C-5 Rear Connector and Pin Definitions 1. Upgrade Connectors The upgrade connectors are designated JP69, and JP78 are used for manufacturer's diagnos- tic purposes only. 2. - 5. I C Connectors C Connector Pin Definitions The I C Connectors, designated JP37, JP95, Pin# Definition JP52 and JP96 are used to monitor HDD ac-...
- Page 65 Appendix C: SAS-213A Backplane Specifications 11. - 12. ACT_IN: SAS Activity LED Header Pin Definitions The activity LED connectors, designated JP26, Pin# Definition Pin# Definition and JP27 are used to indicate the activity ACT IN#0 ACT IN#4 status of each SAS drive. The activity LED ACT IN#1 ACT IN#5 connector is located on the front panel.
- Page 66 SC213 Chassis Manual C-6 Rear Jumper Locations and Pin Definitions JP35 SAS IN#4 SAS IN#3 SAS IN#2 JSM4 JSM3 JSM2 9072#1 RST 1-2:RST JP69: UPGRADE#1 BAR CODE 2-3:NO RST C133 SAS IN#1 JP96 JP52 JP95 R125 JP37 R392 I2C#4 I2C#3 I2C#2 R624 I2C#1...
- Page 67 Appendix C: SAS-213A Backplane Specifications C and SGPIO Modes and Jumper Settings This backplane can utilize I C or SGPIO. SGPIO is the default mode and can be used without making changes to your jumper. The following information details which jumper must be configured to use SGPIO mode or restore your backplane to I C mode.
- Page 68 SC213 Chassis Manual JP35 9072#1 RST 1-2:RST JP69: UPGRADE#1 Rear LED Indicators 2-3:NO RST C133 SAS IN#1 R125 JP37 R624 JSM1 I2C#1 R123 C132 R124 JP69 R131 JP35 JP84 C139 JP18 C380 JP84 MODE 1-2:SGPIO 2-3:I2C JP35 SAS IN#4 SAS IN#3 SAS IN#2 JSM4 JSM3...
- Page 69 Appendix C: SAS-213A Backplane Specifications C-7 Front Components, Connectors and LED Indicators R614 R250 R173 R251 R180 R428 R467 R468 R461 R175 R164 R213 R179 R435 R165 R178 R214 R465 D104 R174 R215 R253 R466 R463 D110 D111 D107 R460 D108 D109 D106...
- Page 70 SC213 Chassis Manual Front LED Indicators Hard Drive Activity Failure LED SAS #0 SAS #1 SAS #2 SAS #3 D102 D107 SAS #4 SAS #5 SAS #6 SAS #7 D104 D108 SAS #8 SAS #9 SAS #10 SAS #11 D106 D109 SAS #12 SAS #13...
-
Page 71: Appendix D Bpn-Sas3-213A Backplane Specifications
Appendix D: BPN-SAS3-213A Backplane Specifications Appendix D BPN-SAS3-213A Backplane Specifications This manual covers BPN-SAS3-213A connectors, jumpers and indicators. D-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent damage to your system, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. - Page 72 This manual reflects BPN-SAS3-213A Revision 1.00, the most current release available at the time of publication. Always refer to the Supermicro Web site at www.supermicro.com for the latest updates, compatible parts and supported...
-
Page 73: Front Connectors
Appendix D: BPN-SAS3-213A Backplane Specifications D-4 Rear Connectors The following connectors are on the side of the backplane that faces the rear of the chassis. They are marked by silkscreen labels. ATMEL#2 RESET UPGRADE #2 ATMEL#1 RESET UPGRADE #1 1-2:RESET 1-2:RESET 2-3:NO RESET 2-3:NO RESET... - Page 74 SC213 Chassis Manual D-5 Rear Connector and Pin Definitions 1. Backplane Main Power Connectors Backplane Main Power The 4-pin connectors, designated JP3, 4-Pin Connector JP4, JP5 and JP6 provide power to the Pin# Definition backplane. See the table on the right for +12V pin definitions.
-
Page 75: Jumper Settings
Appendix D: BPN-SAS3-213A Backplane Specifications D-6 Rear Jumper Locations and Pin Definitions ATMEL#2 RESET UPGRADE #2 UPGRADE #1 ATMEL#1 RESET 1-2:RESET 1-2:RESET 2-3:NO RESET 2-3:NO RESET BAR CODE C109 C110 C142 C111 C141 Figure D-2. Rear Jumpers Jumper Settings Jumper Description Chip reset, for manufacturing use only. - Page 76 SC213 Chassis Manual D-7 Front Connectors and LED Indicators FAIL#15 ACT#15 LED13 LED15 LED21 LED23 FAIL#12 FAIL#13 LED29 ACT#5 FAIL#1 ACT#1 FAIL#5 FAIL#9 ACT#9 FAIL#0 ACT#0 FAIL#2 ACT#2 FAIL#3 ACT#3 FAIL#4 ACT#4 LED31 FAIL#6 ACT#6 FAIL#7 ACT#7 FAIL#8 ACT#8 FAIL#10 ACT#10 FAIL#11 ACT#11...
- Page 77 Appendix D: BPN-SAS3-213A Backplane Specifications Notes...
- Page 78 SC213 Chassis Manual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
