SET PDO ACCESS:

By pressing the "Set PDO Access" button from the main window for SW67968 (Fig. 2) the window "Set PDO Access" appears (Fig. 7a and
7b).
This window is made to create the Receive and the Transmit PDO in the CANopen side, and to indicate which bytes are associated to these
PDO.
It is divided in two parts, the " Receive PDO" and the " Transmit PDO ". The first part is used to receive PDO in the CANopen network and
copy the data in the internal memory array. The second part is used to transmit PDO in the CANopen network with the data of internal
memory array.
The data of the columns in the "Receive PDO" have the
following meanings:
In the Field "Cob-ID" the address for the PDO is
defined;
In the Field "Dimension" the dimension of the
PDO is defined (it can be between 1 and 8);
In the Field "Add B1" the first byte where the
data will be saved in the internal memory array is
defined;
In the Field "Add B2" the second byte where the
data will be saved in the internal memory array is
defined (only if Dimension
In the Field "Add B3" the third byte where the
data will be saved in the internal memory array is
defined (only if Dimension
In the Field "Add B4" the fourth byte where the data will be saved in the internal memory array is defined (only if
In the Field "Add B5" the fifth byte where the data will be saved in the internal memory array is defined (only if
In the Field "Add B6" the sixth byte where the data will be saved in the internal memory array is defined (only if
In the Field "Add B7" the seventh byte where the data will be saved in the internal memory array is defined (only if
6);
In the Field "Add B8" the eighth byte where the data will be saved in the internal memory array is defined (only if
ADFweb.com S.r.l.
> 1);
Figure 7a: "Set PDO Access – Receive PDO" window
> 2);
User Manual IO-Link Slave / CANopen
Document code: MN67968_ENG Revision 1.000 Page 25 of 33
Dimension > 3);
Dimension > 4);
Dimension > 5);
Dimension >
Dimension > 7);
