Industrial Electronic Devices
User Manual
Revision 1.000
English
IO-Link Slave / Modbus TCP Master - Converter
(Order Code: HD67963-B2-IA, HD67963-B2-IB)
For Website information:
www.adfweb.com?Product=HD67963-B2
For Price information:
www.adfweb.com?Price=HD67963-B2-IA
www.adfweb.com?Price=HD67963-B2-IB
Benefits and Main Features:
Very easy to configure
Power Supply 18...35V DC and 8...24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual IO-Link Slave / Modbus TCP Master
Document code: MN67963_ENG
For others IO-Link Slave products, see also the following links:
Converter IO-Link Slave to
www.adfweb.com?Product=HD67961
www.adfweb.com?Product=HD67962
www.adfweb.com?Product=HD67964
www.adfweb.com?Product=HD67965
www.adfweb.com?Product=HD67966
www.adfweb.com?Product=HD67967
www.adfweb.com?Product=HD67968
www.adfweb.com?Product=HD67969
www.adfweb.com?Product=HD67970
www.adfweb.com?Product=HD67971
www.adfweb.com?Product=HD67973
www.adfweb.com?Product=HD67974
www.adfweb.com?Product=HD67977
www.adfweb.com?Product=HD67978
www.adfweb.com?Product=HD67979
www.adfweb.com?Product=HD67980
www.adfweb.com?Product=HD67983
www.adfweb.com?Product=HD67984
www.adfweb.com?Product=HD67985
www.adfweb.com?Product=HD67986
www.adfweb.com?Product=HD67987
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.000
Page 1 of 30
(Modbus Master)
(Modbus Slave)
(Modbus TCP Slave)
(BACnet Master)
(BACnet Slave)
(CAN)
(CANopen)
(DeviceNet Master)
(DeviceNet Slave)
(EtherCAT Slave)
(EtherNet/IP Master)
(EtherNet/IP Slave)
(J1939)
(MQTT)
(NMEA0183)
(NMEA2000)
(PROFINET Master)
(PROFINET Slave)
(S7comm)
(SNMP Manager)
(SNMP Agent)
Advertisement
Table of Contents
Related Manuals for ADF Web HD67963-B2-IA
Summary of Contents for ADF Web HD67963-B2-IA
- Page 1 Industrial Electronic Devices User Manual Revision 1.000 English IO-Link Slave / Modbus TCP Master - Converter (Order Code: HD67963-B2-IA, HD67963-B2-IB) For Website information: www.adfweb.com?Product=HD67963-B2 For others IO-Link Slave products, see also the following links: For Price information: Converter IO-Link Slave to www.adfweb.com?Price=HD67963-B2-IA...
-
