4.7 Parameters of Bluetooth

Bluetooth
Antenna
Versions supported
Frequency Range
Bluetooth standards
Bluetooth Data Rates Supported
Bluetooth Modulation
Encryption support

4.8 System Configuration

Parameter
CPU
Flash memory
RAM
WLAN and Bluetooth share same LNA and an-
tenna
Bluetooth 2.1 + EDR and Bluetooth 5.1 (Class 1)
(Bluetooth Low Energy or BLE)
2.4 to 2.4835 GHz
Bluetooth version 2.1 with Enhanced Data Rate
Bluetooth 5.1 (Class 1) (Bluetooth Low Energy or
BLE)
1, 2, 3 Mbps
GFSK@ 1 Mbps
Pi/4-DQPSK@ 2 Mbps
8-DPSK@ 3 Mbps
AES
Table 18: Technical parameters of Bluetooth
Description
Cortex A8, 1 GHz
2 DMIPS per MHz
Available memory space 1 862 MB
• 2x 256 MB – FW
• 512 MB – User data storage
• 838 MB – Space for Router Apps
512 MB
Table 19: Other technical parameters
