The following functions can be done with a PC through either one of channel B, D or E.
Refer to VII. Cable Connection

1. BATCH COMMUNICATION

Set terminal address (PGM-172) to communicate with ECR. Refer to the programming manual for
the sequence. For details about PC batch communication, refer to PROTOCOL MANUAL UCP-101
and a separate appendix.
REMOTE MEMORY CHANGE
By remote memory change, the PC can modify the memory contents of the ECR. This function
consists of the following three types:
a) Memory Change
Alters the ECR's memory contents, by designating the memory address.
b) Memory Management
Alters the contents of the PLU, group and clerk memories.
c) Date/Time Change
Sets the date and time from the PC.
REMOTE MEMORY DUMP
By remote memory dump, the PC can read the memory contents of the ECR.
a) X/Z Report Dump
The X/Z report dump is similar to the X/Z report of the ECR. Using this function, the PC can collect or reset
an individual ECR's data.
b) Complete Memory Dump
Collects the ECR's complete memory data from the PC. This is used mainly for making a back-up file of the
ECR memory on the PC.

2. PROGRAM LOADER (PLM 2000)

Using the software PLM 2000, the ECR's data can be uploaded/edited on the PC and restored to the
ECR. Please follow the steps on the PLM 2000 to setup.
IV. PC COMMUNICATION
(page 24).
