Summary of Contents for Uniwell SX-6600
- Page 1 USER'S MANUAL SX-6600/6600F SX-6700/6700F SX-6750/6750F 05 type Oct. 24. 2002 [SX6K-05] USR-003...
- Page 2 -- Consult the dealer or an experienced radio/TV technician for help. ===== Notes ===================================== 1. The contents of this manual are subject to change without notice. 2. Uniwell cannot be held responsible if other products, which are not approved by Uniwell, are used for options or expendable supplies.
-
Page 3: Table Of Contents
CONTENTS ATTENTION..........................1 I. INTRODUCTION ....................... 2 PART NAMES ........................3 SPECIFICATIONS......................4 II. INSTALLATION ....................... 6 REPLACING PAPER ROLLS..................7 REPLACING INK RIBBON ................... 9 DAILY MAINTENANCE ....................10 III. DISPLAY......................... 12 IV. KEY LAYOUT........................ 13... -
Page 4: Attention
ATTENTION Thank you very much for purchasing Uniwell Electronic Cash Registers. This ECR has many programmable features, hardware combinations and options. Please consult your dealer as to your particular requirements, as this ECR can be configured, through both hardware and software (programming) to suit a variety of different applications. -
Page 5: Introduction
I. INTRODUCTION SX-6000-05 series is a POS terminal for retail (scanning) market, grocery convenient stores, variety, specialty, supermarkets, etc. SX-6600 2-station dot matrix printer model (44.5 mm, 3.0 lines/sec., 24 char.) SX-6700 2-station thermal printer model (44.5 mm, 14 lines/sec., 24 char.) SX-6750 1-station thermal printer model (80 mm, 21.5 lines/sec., 46 char.) -
Page 6: Part Names
PART NAMES printer cover journal window receipt outlet 1-line rear display (tower type) 12 digits numeric (standard) 16 digits alphanumeric (option) printer cover lock 2-line front display Upper: 16 digits alphanumeric Lower: 12 digits numeric power switch control lock cashier iButton SX-6600F (option) (flat keyboard type) -
Page 7: Specifications
AC 120V ± 10%, 50/60Hz POWER SUPPLY AC 230V ± 10%, 50/60Hz AC 120V: 1A POWER CONSUMPTION AC 230V: 0.3A for SX-6600, 0.4A for SX-6700/6750 Operation: 0° ~ 40°C (32° ~ 104°F) TEMPERATURE Storage: -20° ~ 60°C (-4° ~ 140°F) DIMENSIONS 378 x 440 x 200.5 to 260 mm (changed by screen angle) - Page 8 INTERFACE CHANNEL USED FOR - IRC : up to 32 units plus an ECR master or PC as IRC master (Tensai2000) via NA-720 - Real-time communications with PC (Tensai2000) --- not available - 8 slip printers TP-620 : Epson M290 impact dot matrix printer TP-420 : Epson M267 shuttle impact dot matrix printer without auto cutter A RS485 TP-422 : Epson M267 shuttle impact dot matrix printer with auto cutter...
-
Page 9: Installation
3) The control key is turned to the appropriate position. 4) Proper number of paper roll(s) is (are) fitted. Other Notes 1) Validation Cover In order to issue a validation by SX-6600, cut a rib to make a slot for validation. validation cover - Open the journal window. -
Page 10: Replacing Paper Rolls
REPLACING PAPER ROLLS SX-6600 (Epson M-U420) SX-6700 (Epson M-T245) SX-6750 (Citizen LT-1320) Thermal roll Thermal roll Fine quality paper roll TF50KS-E (Nihon Seishi) TF50KS-E2C (Nihon Seishi) 44.5 mm x ø83 mm 44.5 mm x ø83 mm 80 mm x ø80 mm Regarding terminal printers, refer to the respective printer's User's Manual. - Page 11 SX-6750 (LT-1320) < When paper jammed inside the printer > SX-6600 (M-U420) Raise the paper guide by lifting both paper release levers. Remove the jammed paper by hand. Close the paper guide. Then, with both hands, gently press down both sides of the paper guide.
-
Page 12: Replacing Ink Ribbon
REPLACING INK RIBBON Regarding terminal printers, refer to the respective printer's User's Manual. SX-6600 (M-U420) Ink ribbon: ERC-32 Lift the printer cover and remove the old ribbon. Turn the ribbon feed knob to stretch tight. While tilting the ribbon cassette forward slightly, insert the ribbon between the print head and the paper;... -
Page 13: Daily Maintenance
DAILY MAINTENANCE 1. Cleaning of ECR In order to keep ECR clean, please wipe the cabinet, display or keyboard with a soft piece of cloth regularly. In order to remove heavy dirt, please wipe them using a soft piece of cloth which is dipped in a neutral detergent with water and is tightly squeezed. - Page 14 3. In Case that the Auto-Cutter on SX-6750 Printer Does Not Return If the auto-cutter is locked by a paper jam or if something come into the auto-cutter and locked, please follow the sequences below: a) Turn the power switch off. Open the printer cover. b) Pull the cutter lock lever forward and pull the auto-cutter unit.
-
Page 15: Display
III. DISPLAY FRONT DISPLAY Upper line: 16 digits alphanumeric (7 x 5 dots) Lower line : 12 digits numeric (7 segments) ! REG TOTAL PRICE MENU MENU REAR DISPLAY (STANDARD): 12 digits numeric REAR DISPLAY (OPTION): 16 digits alphanumeric -- only one line is used. LAMP CONDITION MEANING... -
Page 16: Key Layout
IV. KEY LAYOUT M key Control key position range: " " MISC RECEIPT BUFFER ARNG. There are three standard control keys (M, Z, X) Z key VALID. VALID. PRINT and one optional control key (R). X key Ä Ö Ü R key ARNG. - Page 17 M key Ä Ö Ü (BACK SP) (SPACE) (DOUBLE) " " Z key Control key position range: RECEIPT BUFFER OFF COM- There are three standard control keys (M, Z, X) PRINT PULSORY X key and one optional control key (R). R key Σ...
