- Page 1 XAS502 INSTRUCTION MANUAL If you have any questions along the way, just message to us. We’re ready to help! USA-C1...
- Page 2 CAUTION: PLEASE READ ENTIRE MANUAL PRIOR TO USE AND SAVE THESE INSTRUCTIONS. Before getting started, let’s check below lists to make sure it is just right for you! CAUTION: DO NOT exceed the maximum weight Does your No? Perfect – you may continue. indicated.
-
Page 3: Top View
Dimensions FRONT VIEW SIDE VIEW TOP VIEW SPEAKER ATTACHMENT UNIT FRONT VIEW... -
Page 4: Parts And Hardware
Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. - Page 5 Parts and Hardware for STEP 2 Bottom tube Base 2pcs 2pcs Adjusting tube 2pcs M6 Carpet Nut Speaker attachment 8 pcs unit 2pcs Velcro x6 Allen key...
- Page 6 STEP 1 Assemble Product 1-1 Insert bottom tube into base , then fasten bolt by using Allen key Option: If the stand is placed on carpet, spin to loosen and remove the rubber feet, install the carpet nail and screw to the end, then use the nut to tighten the nail.
- Page 7 1-2 Insert Adjusting tube into bottom tube and use Allen key to fasten bolt...
- Page 8 1-3 Attach the Speaker attachment unit to the Adjusting tube and fasten it with bolt Installation method of wires : Method 1: Pass the wire through the internal connection of the product; Method 2: Fix the wire directly on the surface of the product tube with Velcro.
- Page 9 Step 2 Attach speaker to assembled stand Option 1: According to your speaker's installation hole, choose bolt a/b,washer(e) and spacer (f) (as shown in Figure 1 and 2) to attach it.Then plug the wires. For inset hole: Use bolt (a/b), washer (e) and spacer (f) to attach the speaker.
- Page 10 Option 2: For speaker with a key hole,attach key hole bolt (c) to the speaker attachment unit with butterfly nut (d).
- Page 11 Place speaker on stand with key hole bolt (c) inserted in the key hole, then tighten the butterfly nut (d) and plug the wires.
-
Page 12: Height Adjustment
Step 3 Height Adjustment to desired height , then tighten the handle. Loosen the handle, and adjust the tube Tighten MAN:1024mm [40.3in] MIN:793mm [31.2in] Loosen...
