- Page 1 XAS002-1 INSTRUCTION MANUAL If you have any questions along the way, just give us a call 1-800-460-0956 or mail to customerservice@x-mount.com. We’re ready to help! USA-A0...
- Page 2 Before getting started, let’s check below lists to make sure it is just right for you! CAUTION: DO NOT exceed the maximum weight Does your soundbar No? Perfect – you may continue. indicated. This mounting system is intended for use only (including accessories) with the maximum weights indicated.
- Page 3 FRONT VIEW MAX:600mm [23.62in] MIN:150mm [5.91in] MAX:600mm[23.62in] MIN:110mm[4.33in] WALL PLATE RIGHT VIEW - Hook RIGHT VIEW - Hook 406mm [16.00in] [0.31in] 88mm 154mm [3.46in] [6.06in] 203mm [8.00in] 610mm [24.00in] FRONT VIEW 464mm [18.27in] 48mm 30mm [1.89in] 59mm [1.18in] [2.31in] 87mm [3.43in] 691mm [27.19in]...
- Page 4 WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
- Page 5 Hardware for Soundbar Installation Spacers Washers Screws 8x10mm M6x16mm M6x25mm 2.5mm M8x20mm M8x30mm M5x8mm...
- Page 6 Tighten Wall plate 1 Disassemble Your TV from the Mount Ⅰ Remove all cables Ⅱ Take off the TV Ⅲ Remove the TV from the mount brackets from your TV...
- Page 7 2 Attach Brackets to Wall Plate Horizontal distance Tighten of TV mounting holes (Depend on your TV VESA) Wall plate Tips: Check the horizontal distance of the TV before connecting the wall plate unit to the brackets.
- Page 8 3 Attach the Assembled Soundbar and Brackets Unit to Your TV Tips: No need to use washer (g) when using M8 screw (b/d). Tips: Before attach the TV, check the vertical distance of TV and wall plate.
- Page 9 4 Hang the Whole Assembled Unit to the Mount 5 Hang the Hooks Tighten...
- Page 10 6 Put on the Soundbar If the width of your soundbar bottom is more than 88mm ( 3.46 in ), please follow with below step. Otherwise, put soundbar on the hook directly. Loosen Option 1 Back Screw Hole Soundbar Option 2 Bottom Screw Hole Tighten...
- Page 11 CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) ●...
- Page 12 3. Drill pilot holes using a 5/32 in. (4 mm) diameter drill bit. IMPORTANT: Pilot holes must be drilled to a depth of 2.36 in. (60 mm). Be sure to drill into the center of the studs. 4. Install wall plate using two lag bolts. Tighten the lag bolts only until they are pulled firmly against the wall plate.
- Page 13 CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate assembly directly onto the concrete surface ● Minimum solid concrete thickness: 8 in. (203 mm) 1. Position the wall plate on the wall at your desired height. Level the wall plate and mark the hole locations.
- Page 14 3. Insert two anchors. CAUTION: Be sure the anchors are seated flush with the concrete surface. 4. Insert wall plate using two lag bolts. Tighten the lag bolts only until they are pulled firmly against the wall plate. CAUTION: Improper use could reduce the holding power of the lag bolt. DO NOT over-tighten the lag bolts.
- Page 15 Before putting soundbar, please try to pull the wall plate to make sure that it has been assembled on the wall tightly.
- Page 16 Hang the books and tighten the bolts. Tighten...
- Page 17 If the width of your soundbar bottom is more than 88mm ( 3.46 in ), please follow with below step. Otherwise, put soundbar on the hook directly. Loosen Option 2 Bottom Option 1 Back Screw Hole Soundbar Screw Hole Tighten...
