- Page 1 XTL006 INSTRUCTION MANUAL For 37-70" TV If you have any questions along the way, just give us a call 1-800-747-6558 or mail to customerservice@x-mount.com. We’re ready to help!
- Page 2 CAUTION: PLEASE READ ENTIRE MANUAL PRIOR TO USE AND SAVE THESE INSTRUCTIONS. Before getting started, let’s check below lists to make sure it is just right for you! MAX:600mm/23.6" (MIN:200mm/7.9") Check your TV No? This mount is NOT compatible. VESA is within MAX:400mm/15.7"...
- Page 3 TV INTERFACE WALL PLATE 650.5mm/25.6" MAX:600mm/23.6" MIN:200mm/7.9" 598mm/23.5" 509.5mm/20" 407.5mm/16" 305.5mm/12" 203.5mm/8" 102mm/4" MAX:400mm/15.7" 424mm/16.7" MIN:100mm/3.9" 158mm/6.2" 222mm/8.7" 16mm/0.6" 30mm/1.2" SIDE VIEW SIDE VIEW 38mm/1.5" 0°~ -8°...
- Page 4 Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
- Page 5 1-2 Need Spacer? 1-1 Select TV Screws No, go to PAGE 6 for detailed combination. Bracket Short Screw Washer TV back Yes, go to PAGE 6 for detailed combination. Long Screw Washer Spacer Bracket TV back Highly recommended to add spacers for more spacing between wall mount and wall.
- Page 6 1-3 Attach the TV Brackets Screw and washer Spacer(s), screw and washer Tips: If you need to combine M8(d/h) screw with 2.5mm spacer(n), you have to remove the inner circle.
- Page 7 For wood stud installation, follow STEP 2A on PAGE 9 For concrete installation, follow STEP 2B on PAGE 12 Parts and Hardware Allen Key Lag Bolt M8x60mm Wall plate(Left) M8 Washer M5x8mm Bolt Wall plate(Right) CAUTION: Do not use in drywall or wood Concrete Wall Anchor 4pcs...
- Page 8 Assemble Wall plate Wall plate unit...
- Page 9 Wood Stud Installation Min. Wood Stud Size: <16mm nominal 4"(102mm) (5/8") 609.6mm/24" actual 3 1/2"(89mm) 406mm/16" Min. Wood Stud Size: nominal 2"(51mm) actual 1 1/2"(38mm) Centre line...
- Page 10 Again, find another wood stud 24"(609.6mm) 16"(406mm) Centre line Wall plate unit...
- Page 11 CAUTION : To avoid potential personal injury or property damage: All 4 lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate assembly. Ensure the wall plate assembly is securely fastened to the wall before continuing on to the next step. 2.5"(64mm) 7/32"...
- Page 12 Solid Conrete Wall Installation Min. 8"(203mm) DANGER 2.5" (64mm) 3/8" 3/8" (10mm) (10mm) Wall plate unit...
- Page 13 CAUTION : To avoid potential personal injury or property damage: All 4 lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate assembly. Ensure the wall plate assembly is securely fastened to the wall before continuing on to the next step. Concrete Wall Anchor...
- Page 14 Before hanging TV, please conduct "wall plate installation integrity test" first. 132 LBS (60 kg)
- Page 15 Pull down...
- Page 16 Tilting angle adjustment (0°/-8°) ： Pull TV to your desired angle then fasten 2 tilting bolts with Allen key Tighten Loosen 0° -8°...
- Page 17 Pull down the straps...
