Overview
• Product color and design may vary depending on the model.
• For more details on each part name, refer to the manual.
Front
1
Built-in Microphone
1
Rear
2 34 5 6
1
7
8
9
9 0
SD Memory Card Slot
1
ABF(Auto Back Focus)
2
Factory Reset Switch
3
Network LED
4
Network Port
5
Power LED
6
4
2
Image Sensor
2
!
Alarm I/O
7
RS485 Port
8
Audio I/O
9
IO Port
0
Power
!
Side
1
2
Protective Cover
1

Top, Bottom

1
Mount Hole (1/4-20 UNC)
1
Auto Iris Lens
2
Connector
1
1
