P R O 4 8 I N S T A L L A T I O N R E C O M M E N D A T I O N S
I N S TA L L AT I O N R E C O M M E N D AT I O N S
The importance of the Sub-Zero PRO 48
installation cannot be overemphasized. The
installation procedure should be completed by
a qualified installer.
Before you begin the installation process, it is
recommended that you read this entire Instal-
lation Instructions book. There are key details
that you should take special care to observe
during the installation. By reading these
instructions carefully, you will make the instal-
lation process easier, problem-free and, most
importantly, safe.
The installation process is identical for both
the Model 648PROG which features a glass
door on the upper refrigerator compartment
and Model 648PRO with a solid door.
Any questions or problems about the
installation should be directed to your
Sub-Zero dealer or the Sub-Zero Customer
Service Department at 800-222-7820. You may
also check the service center locator on our
website, subzero.com.
Dimensions in parentheses are in
millimeters unless otherwise specified.
T O O L S A N D M AT E R I A L S R E Q U I R E D
The following is a list of tools and materials
that should be available for proper installation
of the PRO 48.
Phillips screwdriver set
Slotted screwdriver set
Torx drive screwdriver set
1
4' (1.2 m) of / " copper tubing and saddle
4
valve for the water line—part #4200880
(do not use self-piercing valves)
Copper tubing cutter
Level—2' (.6 m) and 4' (1.2 m) recom-
mended
Appliance Dolly able to support 1000 lbs
(454 kg) and adequate manpower to
handle the weight of the unit
Various sized pliers
Wrench set
Allen wrench set
7
/ " hex bolt nut driver
16
Crescent wrenches
Cordless drill and assorted drill bits
1
Masonite, plywood, /
cardboard or other suitable material to
protect finished flooring
Appropriate materials to cover and protect
the home and its furnishings during instal-
lation
" pressed fiberboard,
8
Model 648PRO
Model 648PROG
with Glass Door
3
