SOL PA501
Accessory
SOL PA501
Power Adapter
Quick Start Guide
Stylus
Overview
1. Front Camera (option)
7. Battery LED
2. FN Key
8. Wi-Fi LED
3. F1 Key
9. FN LED
4. F2 Key
10. Power LED
5. Touch Screen
11. Power Key
6. Barcode Trigger
12. Volume -
Note: To prevent damage or malfunction, always dry the touch screen when wet
17. Securing Holes
23. Stylus Holder
18. Rear Camera (option)
24. Kensington Lock
19. Hot-swap Battery
25. Pass-through (option)
20. Barcode Reader (option)
26. Docking Connector
21. NFC (option)
27. Micro SIM2 slot
22. Snap-on Connector
28. USB2.0 Type A*2
13. Volume +
14. Home Key
15. DC-IN jack
16. RS-232
(option USB 2.0)
29. USB3.1 Type C
30. Micro SIM1 slot
31. Micro SD slot
32. Audio jack
33. Ethernet
34. Tether Hole
Advertisement
Table of Contents
Related Manuals for RuggON RuggPad SOL PA501
Summary of Contents for RuggON RuggPad SOL PA501
- Page 1 Overview SOL PA501 Quick Start Guide 1. Front Camera (option) 7. Battery LED 13. Volume + 2. FN Key 8. Wi-Fi LED 14. Home Key 3. F1 Key 9. FN LED 15. DC-IN jack Accessory 4. F2 Key 10. Power LED 16.
- Page 2 Micro SD Card & SIM Card Installation Charging & Power On First Time Use SOL PA501 includes a SD slot for storage expansion and two SIM slots (one SOL PA501 is under “Battery Ship Mode” and will not power on to at the side and the other at the back) for cellular and wireless connection.
- Page 3 1. Ignition Monitor only works after DashON offers battery health conditions the device is connected to RuggON monitoring and button setting/button Vehicle Dock 06. lock/ touch lock/ touch setting/ ignition 2. Select turn-on or turn-off time in monitor/passthrough switch functions.
