Installation Guide for the
EasyIP PCC and PCC Mini
Four-Camera Joystick Controllers
Overview
This guide provides information about:
EasyIP PCC four-camera joystick controller, 999-57755-000 (worldwide)
n
n
PCC Mini four-camera joystick controller, 999-57750-000 (worldwide)
About this guide
This guide covers:
n
Controls and connections
Tips for a successful installation
n
Connection diagram
n
Equipment power-on
n
Complete product information is available in the Complete Manual
for the EasyIP PCCFour-Camera Joystick Controller.
Features
Simple control of up to four cameras:
n
EasyIP PCC for EasyIP cameras
o
PCC Mini for other Vaddio cameras
o
n
Three-axis Hall effect joystick
Illuminated pushbuttons for camera selection
n
Web interface for operation and administrative control
n
Use with the Vaddio Device Controller or manage from your PC
n
n
Your EasyIP Switch powers the EasyIP PCC; a PoE+ mid-span power injector powers the PCC Mini
Document Number 411-0068-31 Rev B – October 2023
Advertisement
Table of Contents
Related Manuals for LEGRAND EasyIP VADDIO PCC
Summary of Contents for LEGRAND EasyIP VADDIO PCC
- Page 1 Installation Guide for the EasyIP PCC and PCC Mini Four-Camera Joystick Controllers Overview This guide provides information about: EasyIP PCC four-camera joystick controller, 999-57755-000 (worldwide) PCC Mini four-camera joystick controller, 999-57750-000 (worldwide) About this guide This guide covers: Controls and connections Tips for a successful installation Connection diagram Equipment power-on...
- Page 2 Installation Guide for the EasyIP PCC Four-Camera Joystick Controller A quick look at the camera controller The EasyIP PCC and PCC Mini look identical except for the model information. Camera buttons (lower row) – Select the camera to use for the next shot (the preview camera). The buttons are only illuminated if they are assigned to cameras.
- Page 3 Installation Guide for the EasyIP PCC Four-Camera Joystick Controller Installation This section covers how to install and connect the product. It also provides safety information and other guidance related to installing the product. Note This product is intended for installation and use only in environments where all RS-232 and PoE/PoE+ connections originate within the building.
- Page 4 Installation Guide for the EasyIP PCC Four-Camera Joystick Controller Basic connections Because the EasyIP PCC and PCC Mini are for different environments, the connections are different. Connecting the EasyIP PCC controller The EasyIP PCC connects to the EasyIP Switch that powers the rest of the EasyIP installation. A Vaddio Device Controller provides access to the web interfaces of all the EasyIP products connected to the switch.
- Page 5 Installation Guide for the EasyIP PCC Four-Camera Joystick Controller Connecting the PCC Mini controller The PCC Mini connects to the network via a PoE+ mid-span power injector. A Vaddio Device Controller provides access to Vaddio products on the same subnet. Ensuring compatibility The controller may be unable to communicate with Vaddio cameras if their firmware is out of date.
- Page 6 · All other regions: av.vaddio.techsupport@legrand.com Vaddio is a registered trademark of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.
