MikroTik S53UG+5HaxD2HaxD-TC&EG18-EA Quick Manual

EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v7.7 or the latest stable version, to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be installed according to instructions.
This Quick Guide covers the model: S53UG+5HaxD2HaxD-TC&EG18-EA.
This is a wireless network device. You can find the product model name on the case label (ID).
Please visit the user manual page on
The most relevant technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, brochures, and more info about products are at
Configuration manual for software in your language with additional information can be found
If you need help with configuration, please seek a
First steps:
Please attach provided antennas to the device, before connecting to the power source;
Connect your computer to one of the Ethernet ports;
Configure your computer to obtain its IP address automatically through DHCP;
Insert a micro SIM card into the slot;
Connect the power adapter to the DC jack;
To initiate the configuration, access
The username is " admin" and there is no password
Update the device by clicking the (
card inserted;
For a manual update of the device, visit the products page at
the "Support&Downloads" menu;
Upload downloaded packages to the (
optimal performance, stability, and security updates;
In the ( QuickSet ) menu set up the following: Choose your country, to apply country regulation settings;
Set up your wireless network password in the left field;
Set up your router password in the bottom field.
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Exposure to Radio Frequency Radiation:
environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general public.
Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.
BG - Български. Бързо ръководство
https://mt.lv/um for the full up-to-date user manual. Or scan the QR code with your mobile phone.
consultant https://mikrotik.com/consultants
http://192.168.88.1 in your web browser;
(or, for some models, check user and wireless passwords on the sticker);
Check_for_updates ) on the right side and updating your RouterOS software to the latest version. Must have a valid SIM
https://mikrotik.com/products
WebFig Files ) ( ) menu and reboot the device. By upgrading your RouterOS software to the latest version, you can ensure
This MikroTik equipment complies with the European Union radiation exposure limits set forth for an uncontrolled
https://mikrotik.com/products
at https://mt.lv/help
to find your product. The required packages are accessible under
