Synthes SYNMESH Surgical Technique page 8

Round Implants
End Rings, round
• Two fastening mechanisms available: press fit or with
locking screw
• Angles of 0° or 2.5°
• Each end ring increases the overall height of the
implant by 1.5 mm (see step 3 of the Surgical technique)
End Rings, round, press fit*
Art. No.
B
495.384 10 mm
495.387 10 mm
495.385 12 mm
495.388 12 mm
495.386 15 mm
495.389 15 mm
End Rings, round, with locking screw (convex)
Art. No.
B
495.411 10 mm
495.414 10 mm
495.412 12 mm
495.415 12 mm
495.413 15 mm
495.416 15 mm
*No locking screw needed
6 DePuy Synthes Surgical Technique SYNMESH™
Angle
0°
2.5°
0°
2.5°
0°
2.5°
10 mm
Angle
0°
2.5°
0°
2.5°
0°
2.5°
10 mm
12 mm 15 mm
12 mm 15 mm
