Oblong Implants
End Rings, oblong, with locking screw (convex)
Anterolateral end rings
Art. No. Dimensions
495.421 17 × 22 mm
495.423 17 × 22 mm
495.427 22 × 28 mm
495.429 22 × 28 mm
495.433 26 × 33 mm
495.435 26 × 33 mm
Lateral or anterior end rings
Art. No. Dimensions
495.422 17 × 22 mm
495.424 17 × 22 mm
495.428 22 × 28 mm
495.430 22 × 28 mm
495.434 26 × 33 mm
495.436 26 × 33 mm
Standard Rings
The standard rings fit inside the oblong mesh and are
secured using two M3 locking screws (495.491). They
are designed to provide added stability, particularly for
long implants.
Standard Rings
Art. No. Dimensions
495.405 17 × 22 mm
495.406 22 × 28 mm
495.407 26 × 33 mm
Angle
0°
5°
0°
5°
0°
5°
17 × 22 mm
Angle
0°
5°
0°
5°
0°
5°
17 × 22 mm
17 × 22 mm
22 × 28 mm
22 × 28 mm
22 × 28 mm
