Status LED
2.4G LED
5G LED
Mesh LED
The Internet LED of HA3515-DG keeps off when it is set to a child node in mesh networking. If the
Internet LED of the HS2310-16GH2GT1XS and the Mesh LED of HA3515-DG keep on, it means that
the internet connection of the HA3515-DG is normal.
Off
Solid Purple (Bi-color)
Blinking Purple (Bi-color)
Solid Orange
Blinking Orange
Solid Blue
Blinking Blue
Off
Blinking Orange
Solid Orange
Off
Blinking Blue
Solid Blue
Off
Blinking yellow green
Solid yellow green
3
Power supply is abnormal.
System is operating abnormally.
System is being initialized or booted.
The device works in router mode.
WPS is enabled in router mode.
The device works in AP mode.
WPS is enabled in AP mode.
The device doesn't work in 2.4 GHz.
Communication is in progress.
The device works in 2.4 GHz.
The device doesn't work in 5 GHz.
Communication is in progress.
The device works in 5 GHz.
Mesh is not formed.
Mesh is being formed.
Mesh is formed.
