Graco XM PFP Instructions-Parts List Manual

Hot water flush kit
Hide thumbs Also See for XM PFP:
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions-Parts
™
XM
PFP
Hot Water Flush Kit
For flushing the XM PFP system with hot water. For professional use only.
100 psi (0.7 MPa, 7 bar) Maximum Inlet Water Pressure to Float Valve
180°F (82°C) Maximum Outlet Fluid Temperature
Important Safety Instructions
Read all warnings and instructions in this manual and
the XM PFP Operation manual. Save all instructions.
See Models, page 2 for more information.
Get other manuals https://www.bkmanuals.com
332073C
EN

Advertisement

Table of Contents
loading

Related Manuals for Graco XM PFP

Summary of Contents for Graco XM PFP

  • Page 1 ™ Hot Water Flush Kit 332073C For flushing the XM PFP system with hot water. For professional use only. 100 psi (0.7 MPa, 7 bar) Maximum Inlet Water Pressure to Float Valve 180°F (82°C) Maximum Outlet Fluid Temperature Important Safety Instructions Read all warnings and instructions in this manual and the XM PFP Operation manual.

  • Page 2: Table Of Contents

    Technical Data ......10 Graco Standard Warranty ....12...
  • Page 3 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.

  • Page 4: Related Manuals

    Warnings BURN HAZARD Equipment surfaces and fluid that’s heated can become very hot during operation. To avoid severe burns: • Do not touch hot fluid or equipment. EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not operate the unit when fatigued or under the influence of drugs or alcohol. •...

  • Page 5: Component Identification

    Component Identification Key: 3/4 NFR Garden Hose Inlet Heater Pump Hot Water Outlet to Flush Pump Tank Suction Hose (see installation) Air Hose Hazardous Location XM PFP Non-Hazardous Location XM PFP . 2: Heater Power Cable 332073C Get other manuals https://www.bkmanuals.com...

  • Page 6: Installation

    Model 24Y132: With the heater ON/OFF toggle switch (H) OFF, connect power cable to the Optional Location 1 corded receptacle hanging below the junction box on the XM PFP sprayer. See F . 1 on page 5 and F . 3.
  • Page 7 (2, 6, 7). cable to the corded receptacle hanging below 2. Use four bolts (4 to install the bracket assembly (2) the junction box on the XM PFP sprayer. onto system frame. b. Model 24X113: With the heater ON/OFF toggle 3.

  • Page 8: Connect Air Supply

    Connect Air Supply Connect Air Supply 1. Disconnect air supply (AS) from Heated Fluid Circu- 5. Connect the air hose (8) to the nipple fitting (10). lation Pump (P) for hose bundle. See #2 in F . 5. Connect the air hose (8) to the hot water circulation pump (53).

  • Page 9: Priming The Heater

    2. Loosen needle valve on diaphragm pump to pump water through the heater. 3. Turn the heated water flush switch on the XM PFP sprayer to the ON position. The switch is located next to the main power switch above the dosing valves.

  • Page 10: Parts

    Parts Parts Hazardous Location Hot Water Flush Kit, 24X113 Non Hazardous Location Hot Water Flush Kit, 24Y132 NOTE: Use sealant on all pipe threads. 332073C Get other manuals https://www.bkmanuals.com...
  • Page 11 Parts Hazardous Hot Water Flush Kit, 24X113 Hazardous Water Heated Tank, 262937 Non Hazardous Hot Water Flush Kit, 24Y132 Non Hazardous Water Heated Tank, 262946 Ref Part Description Ref Part Description 262937 TANK, heated, water 51 17B562 TANK, heated, water 262946 TANK, heated water 52 245863 HEATER (262937 only) 17B717 BRACKET, mount...

  • Page 12: Technical Data

    Technical Data Technical Data PFP Hot Water Flush Kit Metric Maximum Water Inlet Pressure to Float Valve 100 psi 7 MPa, 7 bar Maximum Outlet Fluid Temperature 180°F 82°C Supply Voltage 220-250 Volts AC, 1 phase Power 4000 Watts Tank Size 10 gallon 37.8 liter Inlet Fitting...
  • Page 13 Technical Data 332073C Get other manuals https://www.bkmanuals.com...

  • Page 14: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
